Included schema eExam_v3.xsd
Namespace http://www.nemsis.org
Properties
attribute form default unqualified
element form default qualified
Element eExam / eExam.01
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.01</number>
  <name>Estimated Body Weight in Kilograms</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The patient's body weight in kilograms either measured or estimated.</definition>
  <v2Number>E16_01</v2Number>
  <usage>Recommended</usage>
  <performanceMeasuresGroup>
    <performanceMeasure>Pediatric</performanceMeasure>
  </performanceMeasuresGroup>
  <PNNil>Yes</PNNil>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#EstimatedBodyWeighteExam_v3_xsd.tmp#eExam_eExam_eExam.01_NVeExam_v3_xsd.tmp#eExam_eExam_eExam.01_PN
Type extension of EstimatedBodyWeight
Type hierarchy
Properties
content complex
minOccurs 0
nillable true
Attributes
QName Type Use
NV union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting) optional
PN union of(PN.UnableToComplete) optional
Source
<xs:element name="eExam.01" nillable="true" id="eExam.EstimatedBodyWeightinKilograms" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.01</number>
        <name>Estimated Body Weight in Kilograms</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The patient's body weight in kilograms either measured or estimated.</definition>
        <v2Number>E16_01</v2Number>
        <usage>Recommended</usage>
        <performanceMeasuresGroup>
          <performanceMeasure>Pediatric</performanceMeasure>
        </performanceMeasuresGroup>
        <PNNil>Yes</PNNil>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="EstimatedBodyWeight">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.UnableToComplete"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.02
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.02</number>
  <name>Length Based Tape Measure</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The length-based color as taken from the tape.</definition>
  <v2Number>E16_02</v2Number>
  <usage>Recommended</usage>
  <performanceMeasuresGroup>
    <performanceMeasure>Pediatric</performanceMeasure>
  </performanceMeasuresGroup>
  <PNNil>Yes</PNNil>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#BroselowLutenColoreExam_v3_xsd.tmp#eExam_eExam_eExam.02_NVeExam_v3_xsd.tmp#eExam_eExam_eExam.02_PN
Type extension of BroselowLutenColor
Type hierarchy
Properties
content complex
minOccurs 0
nillable true
Attributes
QName Type Use
NV union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting) optional
PN union of(PN.Refused, PN.UnableToComplete) optional
Source
<xs:element name="eExam.02" nillable="true" id="eExam.LengthBasedTapeMeasure" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.02</number>
        <name>Length Based Tape Measure</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The length-based color as taken from the tape.</definition>
        <v2Number>E16_02</v2Number>
        <usage>Recommended</usage>
        <performanceMeasuresGroup>
          <performanceMeasure>Pediatric</performanceMeasure>
        </performanceMeasuresGroup>
        <PNNil>Yes</PNNil>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="BroselowLutenColor">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.Refused PN.UnableToComplete"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup
Namespace http://www.nemsis.org
Annotations
Group Tag to hold assessment information
Diagram
DiagrameExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.03eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.04eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.05eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.06eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.07eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.09eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.AbdomenGroupeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.12eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.SpineGroupeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.ExtremityGroupeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.EyeGroupeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.LungGroupeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.ChestGroupeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.19eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam.20
Properties
content complex
minOccurs 0
maxOccurs unbounded
Model
Children eExam.03, eExam.04, eExam.05, eExam.06, eExam.07, eExam.09, eExam.12, eExam.19, eExam.20, eExam.AbdomenGroup, eExam.ChestGroup, eExam.ExtremityGroup, eExam.EyeGroup, eExam.LungGroup, eExam.SpineGroup
Instance
<eExam.AssessmentGroup CorrelationID="" xmlns="http://www.nemsis.org">
  <eExam.03>{0,1}</eExam.03>
  <eExam.04 CorrelationID="" PN="">{0,unbounded}</eExam.04>
  <eExam.05 CorrelationID="" PN="">{0,unbounded}</eExam.05>
  <eExam.06 CorrelationID="" PN="">{0,unbounded}</eExam.06>
  <eExam.07 CorrelationID="" PN="">{0,unbounded}</eExam.07>
  <eExam.09 CorrelationID="" PN="">{0,unbounded}</eExam.09>
  <eExam.AbdomenGroup CorrelationID="">{0,unbounded}</eExam.AbdomenGroup>
  <eExam.12 CorrelationID="" PN="">{0,unbounded}</eExam.12>
  <eExam.SpineGroup CorrelationID="">{0,unbounded}</eExam.SpineGroup>
  <eExam.ExtremityGroup CorrelationID="">{0,unbounded}</eExam.ExtremityGroup>
  <eExam.EyeGroup CorrelationID="">{0,unbounded}</eExam.EyeGroup>
  <eExam.LungGroup CorrelationID="">{0,unbounded}</eExam.LungGroup>
  <eExam.ChestGroup CorrelationID="">{0,unbounded}</eExam.ChestGroup>
  <eExam.19 CorrelationID="" PN="">{0,unbounded}</eExam.19>
  <eExam.20 CorrelationID="" PN="">{0,unbounded}</eExam.20>
</eExam.AssessmentGroup>
Attributes
QName Type Use
CorrelationID CorrelationID optional
Source
<xs:element name="eExam.AssessmentGroup" id="eExam.AssessmentGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group Tag to hold assessment information</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="eExam.03" id="eExam.DateTimeofAssessment" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.03</number>
              <name>Date/Time of Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The date/time of the assessment.</definition>
              <v2Number>E16_03</v2Number>
              <usage>Optional</usage>
              <performanceMeasuresGroup>
                <performanceMeasure>Airway</performanceMeasure>
                <performanceMeasure>Stroke</performanceMeasure>
                <performanceMeasure>Cardiac Arrest</performanceMeasure>
              </performanceMeasuresGroup>
              <comment>DateTime consists of finite-length characters of the form: yyyy '-' mm '-' dd 'T' hh ':' mm ':' ss ('.' s+)? (zzzzzz) <table cellspacing="2"><tr><td> <table border="1px" cellpadding="3px" cellspacing="0"> <tr><td align="center">yyyy</td><td>a four-digit numeral that represents the year</td></tr> <tr><td align="center">'-'</td><td>separators between parts of the date portion</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the month</td></tr> <tr><td align="center">dd</td><td>a two-digit numeral that represents the day</td></tr> <tr><td align="center">T</td><td>separator that indicates time-of-day follows</td></tr> <tr><td align="center">hh</td><td>a two-digit numeral that represents the hour</td></tr> <tr><td align="center">':'</td><td>a separator between parts of the time-of-day portion</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the minute</td></tr> <tr><td align="center">ss</td><td>a two-integer-digit numeral that represents the whole seconds</td></tr> <tr><td align="center">'.' s+</td><td>(not required) represents the fractional seconds</td></tr> <tr><td align="center">zzzzzz</td><td>(required) represents the timezone (as described below)</td></tr> </table> </td></tr></table> <br/>Timezones, required, are durations with (integer-valued) hour and minute properties in the form: ('+' | '-') hh ':' mm <table cellspacing="2"><tr><td> <table border="1px" cellpadding="3px" cellspacing="0"> <tr><td align="center">hh</td><td>a two-digit numeral (with leading zeros as required) that represents the hours</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the minutes</td></tr> <tr><td align="center">'+'</td><td>a nonnegative duration</td></tr> <tr><td align="center">'-'</td><td>a nonpositive duration</td></tr> </table> </td></tr></table></comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="DateTimeType"/>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.04" id="eExam.SkinAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.04</number>
              <name>Skin Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's skin.</definition>
              <v2Number>E16_04</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.04 - Skin Assessment represents Version 2.2.1 elements E15_01 NHTSA Injury Matrix External/Skin and E16_04 Skin Assessment. The element value choices have been combined and expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="SkinAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.05" id="eExam.HeadAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.05</number>
              <name>Head Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's head.</definition>
              <v2Number>E16_05</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.05 - Head Assessment represents Version 2.2.1 elements E15_02 NHTSA Injury Matrix Head and E16_05 Head/Face Assessment. The element value choices have been combined and expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="HeadAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.06" id="eExam.FaceAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.06</number>
              <name>Face Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's face.</definition>
              <usage>Optional</usage>
              <comment>Element eExam.06 - Face Assessment represents Version 2.2.1 element E15_03 NHTSA Injury Matrix Face The element value choices have been expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="FaceAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.07" id="eExam.NeckAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.07</number>
              <name>Neck Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's neck.</definition>
              <v2Number>E16_06</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.07 - Neck Assessment represents Version 2.2.1 elements E15_04 NHTSA Injury Matrix Neck and E16_06 Neck Assessment. The element value choices have been combined and expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="NeckAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.09" id="eExam.HeartAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.09</number>
              <name>Heart Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's heart.</definition>
              <v2Number>E16_08</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.09 - Heart Assessment represents Version 2.2.1 element E16_08 Heart Assessment. The element value choices have been expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="HeartAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.AbdomenGroup" id="eExam.AbdomenGroup" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>Group Tag to hold abdomen assessment findings information</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="eExam.10" type="AbdominalExamFindingLocation" id="eExam.AbdominalAssessmentFindingLocation" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.10</number>
                    <name>Abdominal Assessment Finding Location</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The location of the patient's abdomen assessment findings.</definition>
                    <usage>Optional</usage>
                    <comment>"Element eExam.10 - Abdominal Assessment Finding Location represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="eExam.11" id="eExam.AbdomenAssessment" minOccurs="0" maxOccurs="unbounded">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.11</number>
                    <name>Abdomen Assessment</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The assessment findings associated with the patient's abdomen.</definition>
                    <v2Number>E16_09</v2Number>
                    <usage>Optional</usage>
                    <comment>"Element eExam.11 - Abdomen Assessment represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="AbdomenAssessment">
                    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                    <xs:attribute name="PN" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
          </xs:sequence>
          <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.12" id="eExam.PelvisGenitourinaryAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.12</number>
              <name>Pelvis/Genitourinary Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's pelvis/genitourinary.</definition>
              <v2Number>E16_13</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.12 - Pelvis/Genitourinary Assessment represents Version 2.2.1 elements E15_09 NHTSA Injury Matrix Pelvis and E16_13 GU Assessment. The element value choices have been combined and expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="GUAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.SpineGroup" id="eExam.SpineGroup" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>Group Tag to hold spine assessment findings information</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="eExam.13" type="BackAndSpineAssessmentLocation" id="eExam.BackandSpineAssessmentFindingLocation" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.13</number>
                    <name>Back and Spine Assessment Finding Location</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The location of the patient's back and spine assessment findings.</definition>
                    <usage>Optional</usage>
                    <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="eExam.14" id="eExam.BackandSpineAssessment" minOccurs="0" maxOccurs="unbounded">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.14</number>
                    <name>Back and Spine Assessment</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The assessment findings associated with the patient's spine (Cervical, Thoracic, Lumbar, and Sacral) and back exam.</definition>
                    <v2Number>E16_14</v2Number>
                    <usage>Optional</usage>
                    <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="BackAndSpineAssessment">
                    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                    <xs:attribute name="PN" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
          </xs:sequence>
          <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.ExtremityGroup" id="eExam.ExtremityGroup" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>Group Tag to hold extremity assessment findings information</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="eExam.15" type="ExtremityAssessmentLocation" id="eExam.ExtremityAssessmentFindingLocation" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.15</number>
                    <name>Extremity Assessment Finding Location</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The location of the patient's extremity assessment findings.</definition>
                    <usage>Optional</usage>
                    <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="eExam.16" id="eExam.ExtremitiesAssessment" minOccurs="0" maxOccurs="unbounded">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.16</number>
                    <name>Extremities Assessment</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The assessment findings associated with the patient's extremities.</definition>
                    <v2Number>E16_17</v2Number>
                    <usage>Optional</usage>
                    <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="ExtremitiesAssessment">
                    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                    <xs:attribute name="PN" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
          </xs:sequence>
          <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.EyeGroup" id="eExam.EyeGroup" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>Group Tag to hold eye assessment findings information</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="eExam.17" type="EyesAssessmentLocation" id="eExam.EyeAssessmentFindingLocation" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.17</number>
                    <name>Eye Assessment Finding Location</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The location of the patient's eye assessment findings.</definition>
                    <usage>Optional</usage>
                    <comment>Element eExam.17 - Eye Assessment Finding Location represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye location value choices have been expanded.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="eExam.18" id="eExam.EyeAssessment" minOccurs="0" maxOccurs="unbounded">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.18</number>
                    <name>Eye Assessment</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The assessment findings of the patient's eye examination.</definition>
                    <v2Number>E16_21</v2Number>
                    <usage>Optional</usage>
                    <comment>Element eExam.18 - Eye Assessment represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye assessment value choices have been combined and expanded.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="EyesAssessment">
                    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                    <xs:attribute name="PN" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
          </xs:sequence>
          <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.LungGroup" id="eExam.LungGroup" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>Group Tag to hold lung assessment findings information</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="eExam.22" type="LungAssessmentLocation" id="eExam.LungAssessmentFindingLocation" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.22</number>
                    <name>Lung Assessment Finding Location</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The location of the patient's lung assessment findings.</definition>
                    <v2Number/>
                    <usage>Optional</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="eExam.23" id="eExam.LungAssessment" minOccurs="0" maxOccurs="unbounded">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.23</number>
                    <name>Lung Assessment</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The assessment findings associated with the patient's lungs.</definition>
                    <v2Number/>
                    <usage>Optional</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="LungAssessment">
                    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                    <xs:attribute name="PN" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
          </xs:sequence>
          <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.ChestGroup" id="eExam.ChestGroup" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>Group Tag to hold chest assessment findings information</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="eExam.24" type="ChestAssessmentLocation" id="eExam.ChestAssessmentFindingLocation" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.24</number>
                    <name>Chest Assessment Finding Location</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The location of the patient's chest assessment findings.</definition>
                    <v2Number/>
                    <usage>Optional</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="eExam.25" id="eExam.ChestAssessment" minOccurs="0" maxOccurs="unbounded">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>eExam.25</number>
                    <name>Chest Assessment</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The assessment findings associated with the patient's chest.</definition>
                    <v2Number/>
                    <usage>Optional</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="ChestAssessment">
                    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                    <xs:attribute name="PN" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
          </xs:sequence>
          <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.19" id="eExam.MentalStatusAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.19</number>
              <name>Mental Status Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings of the patient's mental status examination.</definition>
              <v2Number>E16_23</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.19 - Mental Status Assessment represents Version 2.2.1 element E16_23 Mental Status Assessment. The element value choices have been expanded.</comment>
              <performanceMeasuresGroup>
                <performanceMeasure>Cardiac Arrest</performanceMeasure>
                <performanceMeasure>Stroke</performanceMeasure>
              </performanceMeasuresGroup>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="MentalStatusAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="eExam.20" id="eExam.NeurologicalAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.20</number>
              <name>Neurological Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings of the patient's neurological examination.</definition>
              <v2Number>E16_24</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.20 - Neurological Assessment represents Version 2.2.1 element E16_24 Neurological Assessment. The element value choices have been expanded.</comment>
              <performanceMeasuresGroup>
                <performanceMeasure>Cardiac Arrest</performanceMeasure>
                <performanceMeasure>Stroke</performanceMeasure>
              </performanceMeasuresGroup>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="NeurologicalAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.03
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.03</number>
  <name>Date/Time of Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The date/time of the assessment.</definition>
  <v2Number>E16_03</v2Number>
  <usage>Optional</usage>
  <performanceMeasuresGroup>
    <performanceMeasure>Airway</performanceMeasure>
    <performanceMeasure>Stroke</performanceMeasure>
    <performanceMeasure>Cardiac Arrest</performanceMeasure>
  </performanceMeasuresGroup>
  <comment>DateTime consists of finite-length characters of the form: yyyy '-' mm '-' dd 'T' hh ':' mm ':' ss ('.' s+)? (zzzzzz) <table cellspacing="2"><tr><td> <table border="1px" cellpadding="3px" cellspacing="0"> <tr><td align="center">yyyy</td><td>a four-digit numeral that represents the year</td></tr> <tr><td align="center">'-'</td><td>separators between parts of the date portion</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the month</td></tr> <tr><td align="center">dd</td><td>a two-digit numeral that represents the day</td></tr> <tr><td align="center">T</td><td>separator that indicates time-of-day follows</td></tr> <tr><td align="center">hh</td><td>a two-digit numeral that represents the hour</td></tr> <tr><td align="center">':'</td><td>a separator between parts of the time-of-day portion</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the minute</td></tr> <tr><td align="center">ss</td><td>a two-integer-digit numeral that represents the whole seconds</td></tr> <tr><td align="center">'.' s+</td><td>(not required) represents the fractional seconds</td></tr> <tr><td align="center">zzzzzz</td><td>(required) represents the timezone (as described below)</td></tr> </table> </td></tr></table> <br/>Timezones, required, are durations with (integer-valued) hour and minute properties in the form: ('+' | '-') hh ':' mm <table cellspacing="2"><tr><td> <table border="1px" cellpadding="3px" cellspacing="0"> <tr><td align="center">hh</td><td>a two-digit numeral (with leading zeros as required) that represents the hours</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the minutes</td></tr> <tr><td align="center">'+'</td><td>a nonnegative duration</td></tr> <tr><td align="center">'-'</td><td>a nonpositive duration</td></tr> </table> </td></tr></table></comment>
</nemsisTacDoc>
Diagram
DiagramcommonTypes_v3_xsd.tmp#DateTimeType
Type extension of DateTimeType
Type hierarchy
Properties
content complex
minOccurs 0
Source
<xs:element name="eExam.03" id="eExam.DateTimeofAssessment" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.03</number>
        <name>Date/Time of Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The date/time of the assessment.</definition>
        <v2Number>E16_03</v2Number>
        <usage>Optional</usage>
        <performanceMeasuresGroup>
          <performanceMeasure>Airway</performanceMeasure>
          <performanceMeasure>Stroke</performanceMeasure>
          <performanceMeasure>Cardiac Arrest</performanceMeasure>
        </performanceMeasuresGroup>
        <comment>DateTime consists of finite-length characters of the form: yyyy '-' mm '-' dd 'T' hh ':' mm ':' ss ('.' s+)? (zzzzzz) <table cellspacing="2"><tr><td> <table border="1px" cellpadding="3px" cellspacing="0"> <tr><td align="center">yyyy</td><td>a four-digit numeral that represents the year</td></tr> <tr><td align="center">'-'</td><td>separators between parts of the date portion</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the month</td></tr> <tr><td align="center">dd</td><td>a two-digit numeral that represents the day</td></tr> <tr><td align="center">T</td><td>separator that indicates time-of-day follows</td></tr> <tr><td align="center">hh</td><td>a two-digit numeral that represents the hour</td></tr> <tr><td align="center">':'</td><td>a separator between parts of the time-of-day portion</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the minute</td></tr> <tr><td align="center">ss</td><td>a two-integer-digit numeral that represents the whole seconds</td></tr> <tr><td align="center">'.' s+</td><td>(not required) represents the fractional seconds</td></tr> <tr><td align="center">zzzzzz</td><td>(required) represents the timezone (as described below)</td></tr> </table> </td></tr></table> <br/>Timezones, required, are durations with (integer-valued) hour and minute properties in the form: ('+' | '-') hh ':' mm <table cellspacing="2"><tr><td> <table border="1px" cellpadding="3px" cellspacing="0"> <tr><td align="center">hh</td><td>a two-digit numeral (with leading zeros as required) that represents the hours</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the minutes</td></tr> <tr><td align="center">'+'</td><td>a nonnegative duration</td></tr> <tr><td align="center">'-'</td><td>a nonpositive duration</td></tr> </table> </td></tr></table></comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="DateTimeType"/>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.04
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.04</number>
  <name>Skin Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's skin.</definition>
  <v2Number>E16_04</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.04 - Skin Assessment represents Version 2.2.1 elements E15_01 NHTSA Injury Matrix External/Skin and E16_04 Skin Assessment. The element value choices have been combined and expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#SkinAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.04_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.04_PN
Type extension of SkinAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.04" id="eExam.SkinAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.04</number>
        <name>Skin Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's skin.</definition>
        <v2Number>E16_04</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.04 - Skin Assessment represents Version 2.2.1 elements E15_01 NHTSA Injury Matrix External/Skin and E16_04 Skin Assessment. The element value choices have been combined and expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="SkinAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.05
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.05</number>
  <name>Head Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's head.</definition>
  <v2Number>E16_05</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.05 - Head Assessment represents Version 2.2.1 elements E15_02 NHTSA Injury Matrix Head and E16_05 Head/Face Assessment. The element value choices have been combined and expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#HeadAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.05_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.05_PN
Type extension of HeadAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.05" id="eExam.HeadAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.05</number>
        <name>Head Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's head.</definition>
        <v2Number>E16_05</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.05 - Head Assessment represents Version 2.2.1 elements E15_02 NHTSA Injury Matrix Head and E16_05 Head/Face Assessment. The element value choices have been combined and expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="HeadAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.06
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.06</number>
  <name>Face Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's face.</definition>
  <usage>Optional</usage>
  <comment>Element eExam.06 - Face Assessment represents Version 2.2.1 element E15_03 NHTSA Injury Matrix Face The element value choices have been expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#FaceAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.06_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.06_PN
Type extension of FaceAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.06" id="eExam.FaceAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.06</number>
        <name>Face Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's face.</definition>
        <usage>Optional</usage>
        <comment>Element eExam.06 - Face Assessment represents Version 2.2.1 element E15_03 NHTSA Injury Matrix Face The element value choices have been expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="FaceAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.07
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.07</number>
  <name>Neck Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's neck.</definition>
  <v2Number>E16_06</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.07 - Neck Assessment represents Version 2.2.1 elements E15_04 NHTSA Injury Matrix Neck and E16_06 Neck Assessment. The element value choices have been combined and expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#NeckAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.07_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.07_PN
Type extension of NeckAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.07" id="eExam.NeckAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.07</number>
        <name>Neck Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's neck.</definition>
        <v2Number>E16_06</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.07 - Neck Assessment represents Version 2.2.1 elements E15_04 NHTSA Injury Matrix Neck and E16_06 Neck Assessment. The element value choices have been combined and expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="NeckAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.09
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.09</number>
  <name>Heart Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's heart.</definition>
  <v2Number>E16_08</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.09 - Heart Assessment represents Version 2.2.1 element E16_08 Heart Assessment. The element value choices have been expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#HeartAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.09_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.09_PN
Type extension of HeartAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.09" id="eExam.HeartAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.09</number>
        <name>Heart Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's heart.</definition>
        <v2Number>E16_08</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.09 - Heart Assessment represents Version 2.2.1 element E16_08 Heart Assessment. The element value choices have been expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="HeartAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.AbdomenGroup
Namespace http://www.nemsis.org
Annotations
Group Tag to hold abdomen assessment findings information
Diagram
DiagrameExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.AbdomenGroup_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.AbdomenGroup_eExam.10eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.AbdomenGroup_eExam.11
Properties
content complex
minOccurs 0
maxOccurs unbounded
Model
Children eExam.10, eExam.11
Instance
<eExam.AbdomenGroup CorrelationID="" xmlns="http://www.nemsis.org">
  <eExam.10>{0,1}</eExam.10>
  <eExam.11 CorrelationID="" PN="">{0,unbounded}</eExam.11>
</eExam.AbdomenGroup>
Attributes
QName Type Use
CorrelationID CorrelationID optional
Source
<xs:element name="eExam.AbdomenGroup" id="eExam.AbdomenGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group Tag to hold abdomen assessment findings information</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="eExam.10" type="AbdominalExamFindingLocation" id="eExam.AbdominalAssessmentFindingLocation" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.10</number>
              <name>Abdominal Assessment Finding Location</name>
              <national>No</national>
              <state>No</state>
              <definition>The location of the patient's abdomen assessment findings.</definition>
              <usage>Optional</usage>
              <comment>"Element eExam.10 - Abdominal Assessment Finding Location represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="eExam.11" id="eExam.AbdomenAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.11</number>
              <name>Abdomen Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's abdomen.</definition>
              <v2Number>E16_09</v2Number>
              <usage>Optional</usage>
              <comment>"Element eExam.11 - Abdomen Assessment represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="AbdomenAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.AbdomenGroup / eExam.10
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.10</number>
  <name>Abdominal Assessment Finding Location</name>
  <national>No</national>
  <state>No</state>
  <definition>The location of the patient's abdomen assessment findings.</definition>
  <usage>Optional</usage>
  <comment>"Element eExam.10 - Abdominal Assessment Finding Location represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#AbdominalExamFindingLocation
Type AbdominalExamFindingLocation
Properties
content simple
minOccurs 0
Facets
enumeration 3510001
Generalized
enumeration 3510003
Left Lower Quadrant
enumeration 3510005
Left Upper Quadrant
enumeration 3510007
Periumbilical
enumeration 3510009
Right Lower Quadrant
enumeration 3510011
Right Upper Quadrant
enumeration 3510013
Epigastric
Source
<xs:element name="eExam.10" type="AbdominalExamFindingLocation" id="eExam.AbdominalAssessmentFindingLocation" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.10</number>
        <name>Abdominal Assessment Finding Location</name>
        <national>No</national>
        <state>No</state>
        <definition>The location of the patient's abdomen assessment findings.</definition>
        <usage>Optional</usage>
        <comment>"Element eExam.10 - Abdominal Assessment Finding Location represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.AbdomenGroup / eExam.11
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.11</number>
  <name>Abdomen Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's abdomen.</definition>
  <v2Number>E16_09</v2Number>
  <usage>Optional</usage>
  <comment>"Element eExam.11 - Abdomen Assessment represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#AbdomenAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.AbdomenGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.AbdomenGroup_eExam.11_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.AbdomenGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.AbdomenGroup_eExam.11_PN
Type extension of AbdomenAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.11" id="eExam.AbdomenAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.11</number>
        <name>Abdomen Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's abdomen.</definition>
        <v2Number>E16_09</v2Number>
        <usage>Optional</usage>
        <comment>"Element eExam.11 - Abdomen Assessment represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="AbdomenAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.12
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.12</number>
  <name>Pelvis/Genitourinary Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's pelvis/genitourinary.</definition>
  <v2Number>E16_13</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.12 - Pelvis/Genitourinary Assessment represents Version 2.2.1 elements E15_09 NHTSA Injury Matrix Pelvis and E16_13 GU Assessment. The element value choices have been combined and expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#GUAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.12_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.12_PN
Type extension of GUAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.12" id="eExam.PelvisGenitourinaryAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.12</number>
        <name>Pelvis/Genitourinary Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's pelvis/genitourinary.</definition>
        <v2Number>E16_13</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.12 - Pelvis/Genitourinary Assessment represents Version 2.2.1 elements E15_09 NHTSA Injury Matrix Pelvis and E16_13 GU Assessment. The element value choices have been combined and expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="GUAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.SpineGroup
Namespace http://www.nemsis.org
Annotations
Group Tag to hold spine assessment findings information
Diagram
DiagrameExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.SpineGroup_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.SpineGroup_eExam.13eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.SpineGroup_eExam.14
Properties
content complex
minOccurs 0
maxOccurs unbounded
Model
Children eExam.13, eExam.14
Instance
<eExam.SpineGroup CorrelationID="" xmlns="http://www.nemsis.org">
  <eExam.13>{0,1}</eExam.13>
  <eExam.14 CorrelationID="" PN="">{0,unbounded}</eExam.14>
</eExam.SpineGroup>
Attributes
QName Type Use
CorrelationID CorrelationID optional
Source
<xs:element name="eExam.SpineGroup" id="eExam.SpineGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group Tag to hold spine assessment findings information</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="eExam.13" type="BackAndSpineAssessmentLocation" id="eExam.BackandSpineAssessmentFindingLocation" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.13</number>
              <name>Back and Spine Assessment Finding Location</name>
              <national>No</national>
              <state>No</state>
              <definition>The location of the patient's back and spine assessment findings.</definition>
              <usage>Optional</usage>
              <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="eExam.14" id="eExam.BackandSpineAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.14</number>
              <name>Back and Spine Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's spine (Cervical, Thoracic, Lumbar, and Sacral) and back exam.</definition>
              <v2Number>E16_14</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="BackAndSpineAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.SpineGroup / eExam.13
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.13</number>
  <name>Back and Spine Assessment Finding Location</name>
  <national>No</national>
  <state>No</state>
  <definition>The location of the patient's back and spine assessment findings.</definition>
  <usage>Optional</usage>
  <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#BackAndSpineAssessmentLocation
Type BackAndSpineAssessmentLocation
Properties
content simple
minOccurs 0
Facets
enumeration 3513001
Back-General
enumeration 3513003
Cervical-Left
enumeration 3513005
Cervical-Midline
enumeration 3513007
Cervical-Right
enumeration 3513009
Lumbar-Left
enumeration 3513011
Lumbar-Midline
enumeration 3513013
Lumbar-Right
enumeration 3513015
Thoracic-Left
enumeration 3513017
Thoracic-Midline
enumeration 3513019
Thoracic-Right
enumeration 3513021
Sacral-Left
enumeration 3513023
Sacral-Midline
enumeration 3513025
Sacral-Right
Source
<xs:element name="eExam.13" type="BackAndSpineAssessmentLocation" id="eExam.BackandSpineAssessmentFindingLocation" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.13</number>
        <name>Back and Spine Assessment Finding Location</name>
        <national>No</national>
        <state>No</state>
        <definition>The location of the patient's back and spine assessment findings.</definition>
        <usage>Optional</usage>
        <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.SpineGroup / eExam.14
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.14</number>
  <name>Back and Spine Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's spine (Cervical, Thoracic, Lumbar, and Sacral) and back exam.</definition>
  <v2Number>E16_14</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#BackAndSpineAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.SpineGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.SpineGroup_eExam.14_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.SpineGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.SpineGroup_eExam.14_PN
Type extension of BackAndSpineAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.14" id="eExam.BackandSpineAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.14</number>
        <name>Back and Spine Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's spine (Cervical, Thoracic, Lumbar, and Sacral) and back exam.</definition>
        <v2Number>E16_14</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="BackAndSpineAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.ExtremityGroup
Namespace http://www.nemsis.org
Annotations
Group Tag to hold extremity assessment findings information
Diagram
DiagrameExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ExtremityGroup_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ExtremityGroup_eExam.15eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ExtremityGroup_eExam.16
Properties
content complex
minOccurs 0
maxOccurs unbounded
Model
Children eExam.15, eExam.16
Instance
<eExam.ExtremityGroup CorrelationID="" xmlns="http://www.nemsis.org">
  <eExam.15>{0,1}</eExam.15>
  <eExam.16 CorrelationID="" PN="">{0,unbounded}</eExam.16>
</eExam.ExtremityGroup>
Attributes
QName Type Use
CorrelationID CorrelationID optional
Source
<xs:element name="eExam.ExtremityGroup" id="eExam.ExtremityGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group Tag to hold extremity assessment findings information</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="eExam.15" type="ExtremityAssessmentLocation" id="eExam.ExtremityAssessmentFindingLocation" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.15</number>
              <name>Extremity Assessment Finding Location</name>
              <national>No</national>
              <state>No</state>
              <definition>The location of the patient's extremity assessment findings.</definition>
              <usage>Optional</usage>
              <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="eExam.16" id="eExam.ExtremitiesAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.16</number>
              <name>Extremities Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's extremities.</definition>
              <v2Number>E16_17</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="ExtremitiesAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.ExtremityGroup / eExam.15
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.15</number>
  <name>Extremity Assessment Finding Location</name>
  <national>No</national>
  <state>No</state>
  <definition>The location of the patient's extremity assessment findings.</definition>
  <usage>Optional</usage>
  <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#ExtremityAssessmentLocation
Type ExtremityAssessmentLocation
Properties
content simple
minOccurs 0
Facets
enumeration 3515001
Ankle-Left
enumeration 3515003
Ankle-Right
enumeration 3515005
Arm-Upper-Left
enumeration 3515007
Arm-Upper-Right
enumeration 3515009
Elbow-Left
enumeration 3515011
Elbow-Right
enumeration 3515013
Finger-2nd (Index)-Left
enumeration 3515015
Finger-2nd (Index)-Right
enumeration 3515017
Finger-3rd (Middle)-Left
enumeration 3515019
Finger-3rd (Middle)-Right
enumeration 3515021
Finger-4th (Ring)-Left
enumeration 3515023
Finger-4th (Ring)-Right
enumeration 3515025
Finger-5th (Smallest)-Left
enumeration 3515027
Finger-5th (Smallest)-Right
enumeration 3515029
Foot-Dorsal-Left
enumeration 3515031
Foot-Dorsal-Right
enumeration 3515033
Foot-Plantar-Left
enumeration 3515035
Foot-Plantar-Right
enumeration 3515037
Arm-Lower-Left
enumeration 3515039
Arm-Lower-Right
enumeration 3515041
Hand-Dorsal-Left
enumeration 3515043
Hand-Dorsal-Right
enumeration 3515045
Hand-Palm-Left
enumeration 3515047
Hand-Palm-Right
enumeration 3515049
Hip-Left
enumeration 3515051
Hip-Right
enumeration 3515053
Knee-Left
enumeration 3515055
Knee-Right
enumeration 3515057
Leg-Lower-Left
enumeration 3515059
Leg-Lower-Right
enumeration 3515061
Leg-Upper-Left
enumeration 3515063
Leg-Upper-Right
enumeration 3515065
Shoulder-Left
enumeration 3515067
Shoulder-Right
enumeration 3515069
Thumb-Left
enumeration 3515071
Thumb-Right
enumeration 3515073
Toe-1st (Big)-Left
enumeration 3515075
Toe-1st (Big)-Right
enumeration 3515077
Toe-2nd-Left
enumeration 3515079
Toe-2nd-Right
enumeration 3515081
Toe-3rd-Left
enumeration 3515083
Toe-3rd-Right
enumeration 3515085
Toe-4th-Left
enumeration 3515087
Toe-4th-Right
enumeration 3515089
Toe-5th (Smallest)-Left
enumeration 3515091
Toe-5th (Smallest)-Right
enumeration 3515093
Wrist-Left
enumeration 3515095
Wrist-Right
enumeration 3515097
Arm-Whole Arm and Hand-Left
enumeration 3515099
Arm-Whole Arm and Hand-Right
enumeration 3515101
Hand-Whole Hand-Left
enumeration 3515103
Hand-Whole Hand-Right
enumeration 3515105
Leg-Whole Leg-Left
enumeration 3515107
Leg-Whole Leg-Right
enumeration 3515109
Foot-Whole Foot-Left
enumeration 3515111
Foot-Whole Foot-Right
Source
<xs:element name="eExam.15" type="ExtremityAssessmentLocation" id="eExam.ExtremityAssessmentFindingLocation" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.15</number>
        <name>Extremity Assessment Finding Location</name>
        <national>No</national>
        <state>No</state>
        <definition>The location of the patient's extremity assessment findings.</definition>
        <usage>Optional</usage>
        <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.ExtremityGroup / eExam.16
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.16</number>
  <name>Extremities Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's extremities.</definition>
  <v2Number>E16_17</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#ExtremitiesAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ExtremityGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ExtremityGroup_eExam.16_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ExtremityGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ExtremityGroup_eExam.16_PN
Type extension of ExtremitiesAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.16" id="eExam.ExtremitiesAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.16</number>
        <name>Extremities Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's extremities.</definition>
        <v2Number>E16_17</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="ExtremitiesAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.EyeGroup
Namespace http://www.nemsis.org
Annotations
Group Tag to hold eye assessment findings information
Diagram
DiagrameExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.EyeGroup_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.EyeGroup_eExam.17eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.EyeGroup_eExam.18
Properties
content complex
minOccurs 0
maxOccurs unbounded
Model
Children eExam.17, eExam.18
Instance
<eExam.EyeGroup CorrelationID="" xmlns="http://www.nemsis.org">
  <eExam.17>{0,1}</eExam.17>
  <eExam.18 CorrelationID="" PN="">{0,unbounded}</eExam.18>
</eExam.EyeGroup>
Attributes
QName Type Use
CorrelationID CorrelationID optional
Source
<xs:element name="eExam.EyeGroup" id="eExam.EyeGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group Tag to hold eye assessment findings information</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="eExam.17" type="EyesAssessmentLocation" id="eExam.EyeAssessmentFindingLocation" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.17</number>
              <name>Eye Assessment Finding Location</name>
              <national>No</national>
              <state>No</state>
              <definition>The location of the patient's eye assessment findings.</definition>
              <usage>Optional</usage>
              <comment>Element eExam.17 - Eye Assessment Finding Location represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye location value choices have been expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="eExam.18" id="eExam.EyeAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.18</number>
              <name>Eye Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings of the patient's eye examination.</definition>
              <v2Number>E16_21</v2Number>
              <usage>Optional</usage>
              <comment>Element eExam.18 - Eye Assessment represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye assessment value choices have been combined and expanded.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="EyesAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.EyeGroup / eExam.17
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.17</number>
  <name>Eye Assessment Finding Location</name>
  <national>No</national>
  <state>No</state>
  <definition>The location of the patient's eye assessment findings.</definition>
  <usage>Optional</usage>
  <comment>Element eExam.17 - Eye Assessment Finding Location represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye location value choices have been expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#EyesAssessmentLocation
Type EyesAssessmentLocation
Properties
content simple
minOccurs 0
Facets
enumeration 3517001
Bilateral
enumeration 3517003
Left
enumeration 3517005
Right
Source
<xs:element name="eExam.17" type="EyesAssessmentLocation" id="eExam.EyeAssessmentFindingLocation" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.17</number>
        <name>Eye Assessment Finding Location</name>
        <national>No</national>
        <state>No</state>
        <definition>The location of the patient's eye assessment findings.</definition>
        <usage>Optional</usage>
        <comment>Element eExam.17 - Eye Assessment Finding Location represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye location value choices have been expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.EyeGroup / eExam.18
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.18</number>
  <name>Eye Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings of the patient's eye examination.</definition>
  <v2Number>E16_21</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.18 - Eye Assessment represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye assessment value choices have been combined and expanded.</comment>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#EyesAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.EyeGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.EyeGroup_eExam.18_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.EyeGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.EyeGroup_eExam.18_PN
Type extension of EyesAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.18" id="eExam.EyeAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.18</number>
        <name>Eye Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings of the patient's eye examination.</definition>
        <v2Number>E16_21</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.18 - Eye Assessment represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye assessment value choices have been combined and expanded.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="EyesAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.LungGroup
Namespace http://www.nemsis.org
Annotations
Group Tag to hold lung assessment findings information
Diagram
DiagrameExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.LungGroup_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.LungGroup_eExam.22eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.LungGroup_eExam.23
Properties
content complex
minOccurs 0
maxOccurs unbounded
Model
Children eExam.22, eExam.23
Instance
<eExam.LungGroup CorrelationID="" xmlns="http://www.nemsis.org">
  <eExam.22>{0,1}</eExam.22>
  <eExam.23 CorrelationID="" PN="">{0,unbounded}</eExam.23>
</eExam.LungGroup>
Attributes
QName Type Use
CorrelationID CorrelationID optional
Source
<xs:element name="eExam.LungGroup" id="eExam.LungGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group Tag to hold lung assessment findings information</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="eExam.22" type="LungAssessmentLocation" id="eExam.LungAssessmentFindingLocation" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.22</number>
              <name>Lung Assessment Finding Location</name>
              <national>No</national>
              <state>No</state>
              <definition>The location of the patient's lung assessment findings.</definition>
              <v2Number/>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="eExam.23" id="eExam.LungAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.23</number>
              <name>Lung Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's lungs.</definition>
              <v2Number/>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="LungAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.LungGroup / eExam.22
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.22</number>
  <name>Lung Assessment Finding Location</name>
  <national>No</national>
  <state>No</state>
  <definition>The location of the patient's lung assessment findings.</definition>
  <v2Number/>
  <usage>Optional</usage>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#LungAssessmentLocation
Type LungAssessmentLocation
Properties
content simple
minOccurs 0
Facets
enumeration 3522001
Left
enumeration 3522003
Right
enumeration 3522005
Bilateral
Source
<xs:element name="eExam.22" type="LungAssessmentLocation" id="eExam.LungAssessmentFindingLocation" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.22</number>
        <name>Lung Assessment Finding Location</name>
        <national>No</national>
        <state>No</state>
        <definition>The location of the patient's lung assessment findings.</definition>
        <v2Number/>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.LungGroup / eExam.23
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.23</number>
  <name>Lung Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's lungs.</definition>
  <v2Number/>
  <usage>Optional</usage>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#LungAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.LungGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.LungGroup_eExam.23_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.LungGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.LungGroup_eExam.23_PN
Type extension of LungAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.23" id="eExam.LungAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.23</number>
        <name>Lung Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's lungs.</definition>
        <v2Number/>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="LungAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.ChestGroup
Namespace http://www.nemsis.org
Annotations
Group Tag to hold chest assessment findings information
Diagram
DiagrameExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ChestGroup_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ChestGroup_eExam.24eExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ChestGroup_eExam.25
Properties
content complex
minOccurs 0
maxOccurs unbounded
Model
Children eExam.24, eExam.25
Instance
<eExam.ChestGroup CorrelationID="" xmlns="http://www.nemsis.org">
  <eExam.24>{0,1}</eExam.24>
  <eExam.25 CorrelationID="" PN="">{0,unbounded}</eExam.25>
</eExam.ChestGroup>
Attributes
QName Type Use
CorrelationID CorrelationID optional
Source
<xs:element name="eExam.ChestGroup" id="eExam.ChestGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group Tag to hold chest assessment findings information</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="eExam.24" type="ChestAssessmentLocation" id="eExam.ChestAssessmentFindingLocation" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.24</number>
              <name>Chest Assessment Finding Location</name>
              <national>No</national>
              <state>No</state>
              <definition>The location of the patient's chest assessment findings.</definition>
              <v2Number/>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="eExam.25" id="eExam.ChestAssessment" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>eExam.25</number>
              <name>Chest Assessment</name>
              <national>No</national>
              <state>No</state>
              <definition>The assessment findings associated with the patient's chest.</definition>
              <v2Number/>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="ChestAssessment">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="PN" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.ChestGroup / eExam.24
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.24</number>
  <name>Chest Assessment Finding Location</name>
  <national>No</national>
  <state>No</state>
  <definition>The location of the patient's chest assessment findings.</definition>
  <v2Number/>
  <usage>Optional</usage>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#ChestAssessmentLocation
Type ChestAssessmentLocation
Properties
content simple
minOccurs 0
Facets
enumeration 3524001
Left - Anterior
enumeration 3524003
Left - Posterior
enumeration 3524005
Right - Anterior
enumeration 3524007
Right - Posterior
enumeration 3524009
General - Anterior
enumeration 3524011
General - Posterior
enumeration 3524013
Left - Side
enumeration 3524015
Right - Side
Source
<xs:element name="eExam.24" type="ChestAssessmentLocation" id="eExam.ChestAssessmentFindingLocation" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.24</number>
        <name>Chest Assessment Finding Location</name>
        <national>No</national>
        <state>No</state>
        <definition>The location of the patient's chest assessment findings.</definition>
        <v2Number/>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.ChestGroup / eExam.25
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.25</number>
  <name>Chest Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings associated with the patient's chest.</definition>
  <v2Number/>
  <usage>Optional</usage>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#ChestAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ChestGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ChestGroup_eExam.25_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ChestGroup_eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.ChestGroup_eExam.25_PN
Type extension of ChestAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.25" id="eExam.ChestAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.25</number>
        <name>Chest Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings associated with the patient's chest.</definition>
        <v2Number/>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="ChestAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.19
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.19</number>
  <name>Mental Status Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings of the patient's mental status examination.</definition>
  <v2Number>E16_23</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.19 - Mental Status Assessment represents Version 2.2.1 element E16_23 Mental Status Assessment. The element value choices have been expanded.</comment>
  <performanceMeasuresGroup>
    <performanceMeasure>Cardiac Arrest</performanceMeasure>
    <performanceMeasure>Stroke</performanceMeasure>
  </performanceMeasuresGroup>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#MentalStatusAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.19_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.19_PN
Type extension of MentalStatusAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.19" id="eExam.MentalStatusAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.19</number>
        <name>Mental Status Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings of the patient's mental status examination.</definition>
        <v2Number>E16_23</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.19 - Mental Status Assessment represents Version 2.2.1 element E16_23 Mental Status Assessment. The element value choices have been expanded.</comment>
        <performanceMeasuresGroup>
          <performanceMeasure>Cardiac Arrest</performanceMeasure>
          <performanceMeasure>Stroke</performanceMeasure>
        </performanceMeasuresGroup>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="MentalStatusAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.AssessmentGroup / eExam.20
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.20</number>
  <name>Neurological Assessment</name>
  <national>No</national>
  <state>No</state>
  <definition>The assessment findings of the patient's neurological examination.</definition>
  <v2Number>E16_24</v2Number>
  <usage>Optional</usage>
  <comment>Element eExam.20 - Neurological Assessment represents Version 2.2.1 element E16_24 Neurological Assessment. The element value choices have been expanded.</comment>
  <performanceMeasuresGroup>
    <performanceMeasure>Cardiac Arrest</performanceMeasure>
    <performanceMeasure>Stroke</performanceMeasure>
  </performanceMeasuresGroup>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#NeurologicalAssessmenteExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.20_CorrelationIDeExam_v3_xsd.tmp#eExam_eExam_eExam.AssessmentGroup_eExam_eExam_eExam.AssessmentGroup_eExam.20_PN
Type extension of NeurologicalAssessment
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs unbounded
Attributes
QName Type Use
CorrelationID CorrelationID optional
PN union of(PN.ExamFindingNotPresent) optional
Source
<xs:element name="eExam.20" id="eExam.NeurologicalAssessment" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.20</number>
        <name>Neurological Assessment</name>
        <national>No</national>
        <state>No</state>
        <definition>The assessment findings of the patient's neurological examination.</definition>
        <v2Number>E16_24</v2Number>
        <usage>Optional</usage>
        <comment>Element eExam.20 - Neurological Assessment represents Version 2.2.1 element E16_24 Neurological Assessment. The element value choices have been expanded.</comment>
        <performanceMeasuresGroup>
          <performanceMeasure>Cardiac Arrest</performanceMeasure>
          <performanceMeasure>Stroke</performanceMeasure>
        </performanceMeasuresGroup>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="NeurologicalAssessment">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Element eExam / eExam.21
Namespace http://www.nemsis.org
Annotations
<nemsisTacDoc>
  <number>eExam.21</number>
  <name>Stroke/CVA Symptoms Resolved</name>
  <national>No</national>
  <state>Yes</state>
  <definition>Indication if the Stroke/CVA Symptoms resolved and when.</definition>
  <v2Number/>
  <usage>Recommended</usage>
  <comment/>
  <performanceMeasuresGroup>
    <performanceMeasure>Stroke</performanceMeasure>
  </performanceMeasuresGroup>
  <PNNil>Yes</PNNil>
</nemsisTacDoc>
Diagram
DiagrameExam_v3_xsd.tmp#StrokeCVASymptomsResolvedeExam_v3_xsd.tmp#eExam_eExam_eExam.21_PNeExam_v3_xsd.tmp#eExam_eExam_eExam.21_NV
Type extension of StrokeCVASymptomsResolved
Type hierarchy
Properties
content complex
minOccurs 0
maxOccurs 1
nillable true
Attributes
QName Type Use
NV union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting) optional
PN union of(PN.UnableToComplete) optional
Source
<xs:element name="eExam.21" nillable="true" id="eExam.StrokeCVASymptomsResolved" minOccurs="0" maxOccurs="1">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>eExam.21</number>
        <name>Stroke/CVA Symptoms Resolved</name>
        <national>No</national>
        <state>Yes</state>
        <definition>Indication if the Stroke/CVA Symptoms resolved and when.</definition>
        <v2Number/>
        <usage>Recommended</usage>
        <comment/>
        <performanceMeasuresGroup>
          <performanceMeasure>Stroke</performanceMeasure>
        </performanceMeasuresGroup>
        <PNNil>Yes</PNNil>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="StrokeCVASymptomsResolved">
        <xs:attribute name="PN" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="PN.UnableToComplete"/>
          </xs:simpleType>
        </xs:attribute>
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>
Complex Type eExam
Namespace http://www.nemsis.org
Diagram
DiagrameExam_v3_xsd.tmp#eExam_eExam.01eExam_v3_xsd.tmp#eExam_eExam.02eExam_v3_xsd.tmp#eExam_eExam.AssessmentGroupeExam_v3_xsd.tmp#eExam_eExam.21
Used by
Model
Children eExam.01, eExam.02, eExam.21, eExam.AssessmentGroup
Source
<xs:complexType name="eExam">
  <xs:sequence>
    <xs:element name="eExam.01" nillable="true" id="eExam.EstimatedBodyWeightinKilograms" minOccurs="0">
      <xs:annotation>
        <xs:documentation>
          <nemsisTacDoc>
            <number>eExam.01</number>
            <name>Estimated Body Weight in Kilograms</name>
            <national>No</national>
            <state>Yes</state>
            <definition>The patient's body weight in kilograms either measured or estimated.</definition>
            <v2Number>E16_01</v2Number>
            <usage>Recommended</usage>
            <performanceMeasuresGroup>
              <performanceMeasure>Pediatric</performanceMeasure>
            </performanceMeasuresGroup>
            <PNNil>Yes</PNNil>
          </nemsisTacDoc>
        </xs:documentation>
      </xs:annotation>
      <xs:complexType>
        <xs:simpleContent>
          <xs:extension base="EstimatedBodyWeight">
            <xs:attribute name="NV" use="optional">
              <xs:simpleType>
                <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
              </xs:simpleType>
            </xs:attribute>
            <xs:attribute name="PN" use="optional">
              <xs:simpleType>
                <xs:union memberTypes="PN.UnableToComplete"/>
              </xs:simpleType>
            </xs:attribute>
          </xs:extension>
        </xs:simpleContent>
      </xs:complexType>
    </xs:element>
    <xs:element name="eExam.02" nillable="true" id="eExam.LengthBasedTapeMeasure" minOccurs="0">
      <xs:annotation>
        <xs:documentation>
          <nemsisTacDoc>
            <number>eExam.02</number>
            <name>Length Based Tape Measure</name>
            <national>No</national>
            <state>Yes</state>
            <definition>The length-based color as taken from the tape.</definition>
            <v2Number>E16_02</v2Number>
            <usage>Recommended</usage>
            <performanceMeasuresGroup>
              <performanceMeasure>Pediatric</performanceMeasure>
            </performanceMeasuresGroup>
            <PNNil>Yes</PNNil>
          </nemsisTacDoc>
        </xs:documentation>
      </xs:annotation>
      <xs:complexType>
        <xs:simpleContent>
          <xs:extension base="BroselowLutenColor">
            <xs:attribute name="NV" use="optional">
              <xs:simpleType>
                <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
              </xs:simpleType>
            </xs:attribute>
            <xs:attribute name="PN" use="optional">
              <xs:simpleType>
                <xs:union memberTypes="PN.Refused PN.UnableToComplete"/>
              </xs:simpleType>
            </xs:attribute>
          </xs:extension>
        </xs:simpleContent>
      </xs:complexType>
    </xs:element>
    <xs:element name="eExam.AssessmentGroup" id="eExam.AssessmentGroup" minOccurs="0" maxOccurs="unbounded">
      <xs:annotation>
        <xs:documentation>Group Tag to hold assessment information</xs:documentation>
      </xs:annotation>
      <xs:complexType>
        <xs:sequence>
          <xs:element name="eExam.03" id="eExam.DateTimeofAssessment" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>eExam.03</number>
                  <name>Date/Time of Assessment</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The date/time of the assessment.</definition>
                  <v2Number>E16_03</v2Number>
                  <usage>Optional</usage>
                  <performanceMeasuresGroup>
                    <performanceMeasure>Airway</performanceMeasure>
                    <performanceMeasure>Stroke</performanceMeasure>
                    <performanceMeasure>Cardiac Arrest</performanceMeasure>
                  </performanceMeasuresGroup>
                  <comment>DateTime consists of finite-length characters of the form: yyyy '-' mm '-' dd 'T' hh ':' mm ':' ss ('.' s+)? (zzzzzz) <table cellspacing="2"><tr><td> <table border="1px" cellpadding="3px" cellspacing="0"> <tr><td align="center">yyyy</td><td>a four-digit numeral that represents the year</td></tr> <tr><td align="center">'-'</td><td>separators between parts of the date portion</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the month</td></tr> <tr><td align="center">dd</td><td>a two-digit numeral that represents the day</td></tr> <tr><td align="center">T</td><td>separator that indicates time-of-day follows</td></tr> <tr><td align="center">hh</td><td>a two-digit numeral that represents the hour</td></tr> <tr><td align="center">':'</td><td>a separator between parts of the time-of-day portion</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the minute</td></tr> <tr><td align="center">ss</td><td>a two-integer-digit numeral that represents the whole seconds</td></tr> <tr><td align="center">'.' s+</td><td>(not required) represents the fractional seconds</td></tr> <tr><td align="center">zzzzzz</td><td>(required) represents the timezone (as described below)</td></tr> </table> </td></tr></table> <br/>Timezones, required, are durations with (integer-valued) hour and minute properties in the form: ('+' | '-') hh ':' mm <table cellspacing="2"><tr><td> <table border="1px" cellpadding="3px" cellspacing="0"> <tr><td align="center">hh</td><td>a two-digit numeral (with leading zeros as required) that represents the hours</td></tr> <tr><td align="center">mm</td><td>a two-digit numeral that represents the minutes</td></tr> <tr><td align="center">'+'</td><td>a nonnegative duration</td></tr> <tr><td align="center">'-'</td><td>a nonpositive duration</td></tr> </table> </td></tr></table></comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="DateTimeType"/>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.04" id="eExam.SkinAssessment" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>eExam.04</number>
                  <name>Skin Assessment</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The assessment findings associated with the patient's skin.</definition>
                  <v2Number>E16_04</v2Number>
                  <usage>Optional</usage>
                  <comment>Element eExam.04 - Skin Assessment represents Version 2.2.1 elements E15_01 NHTSA Injury Matrix External/Skin and E16_04 Skin Assessment. The element value choices have been combined and expanded.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="SkinAssessment">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                  <xs:attribute name="PN" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.05" id="eExam.HeadAssessment" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>eExam.05</number>
                  <name>Head Assessment</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The assessment findings associated with the patient's head.</definition>
                  <v2Number>E16_05</v2Number>
                  <usage>Optional</usage>
                  <comment>Element eExam.05 - Head Assessment represents Version 2.2.1 elements E15_02 NHTSA Injury Matrix Head and E16_05 Head/Face Assessment. The element value choices have been combined and expanded.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="HeadAssessment">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                  <xs:attribute name="PN" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.06" id="eExam.FaceAssessment" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>eExam.06</number>
                  <name>Face Assessment</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The assessment findings associated with the patient's face.</definition>
                  <usage>Optional</usage>
                  <comment>Element eExam.06 - Face Assessment represents Version 2.2.1 element E15_03 NHTSA Injury Matrix Face The element value choices have been expanded.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="FaceAssessment">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                  <xs:attribute name="PN" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.07" id="eExam.NeckAssessment" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>eExam.07</number>
                  <name>Neck Assessment</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The assessment findings associated with the patient's neck.</definition>
                  <v2Number>E16_06</v2Number>
                  <usage>Optional</usage>
                  <comment>Element eExam.07 - Neck Assessment represents Version 2.2.1 elements E15_04 NHTSA Injury Matrix Neck and E16_06 Neck Assessment. The element value choices have been combined and expanded.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="NeckAssessment">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                  <xs:attribute name="PN" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.09" id="eExam.HeartAssessment" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>eExam.09</number>
                  <name>Heart Assessment</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The assessment findings associated with the patient's heart.</definition>
                  <v2Number>E16_08</v2Number>
                  <usage>Optional</usage>
                  <comment>Element eExam.09 - Heart Assessment represents Version 2.2.1 element E16_08 Heart Assessment. The element value choices have been expanded.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="HeartAssessment">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                  <xs:attribute name="PN" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.AbdomenGroup" id="eExam.AbdomenGroup" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>Group Tag to hold abdomen assessment findings information</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="eExam.10" type="AbdominalExamFindingLocation" id="eExam.AbdominalAssessmentFindingLocation" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.10</number>
                        <name>Abdominal Assessment Finding Location</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The location of the patient's abdomen assessment findings.</definition>
                        <usage>Optional</usage>
                        <comment>"Element eExam.10 - Abdominal Assessment Finding Location represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="eExam.11" id="eExam.AbdomenAssessment" minOccurs="0" maxOccurs="unbounded">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.11</number>
                        <name>Abdomen Assessment</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The assessment findings associated with the patient's abdomen.</definition>
                        <v2Number>E16_09</v2Number>
                        <usage>Optional</usage>
                        <comment>"Element eExam.11 - Abdomen Assessment represents Version 2.2.1 elements E15_06 NHTSA Injury Matrix Abdomen AND E16_09 Abdomen Left Upper Assessment, E16_10 Abdomen Left Lower Assessment,E16_11 Abdomen Right Upper Assessment, and E16_12 Abdomen Right Lower Assessment. The element value choices have been combined and expanded."</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="AbdomenAssessment">
                        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                        <xs:attribute name="PN" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
              </xs:sequence>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.12" id="eExam.PelvisGenitourinaryAssessment" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>eExam.12</number>
                  <name>Pelvis/Genitourinary Assessment</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The assessment findings associated with the patient's pelvis/genitourinary.</definition>
                  <v2Number>E16_13</v2Number>
                  <usage>Optional</usage>
                  <comment>Element eExam.12 - Pelvis/Genitourinary Assessment represents Version 2.2.1 elements E15_09 NHTSA Injury Matrix Pelvis and E16_13 GU Assessment. The element value choices have been combined and expanded.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="GUAssessment">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                  <xs:attribute name="PN" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.SpineGroup" id="eExam.SpineGroup" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>Group Tag to hold spine assessment findings information</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="eExam.13" type="BackAndSpineAssessmentLocation" id="eExam.BackandSpineAssessmentFindingLocation" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.13</number>
                        <name>Back and Spine Assessment Finding Location</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The location of the patient's back and spine assessment findings.</definition>
                        <usage>Optional</usage>
                        <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="eExam.14" id="eExam.BackandSpineAssessment" minOccurs="0" maxOccurs="unbounded">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.14</number>
                        <name>Back and Spine Assessment</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The assessment findings associated with the patient's spine (Cervical, Thoracic, Lumbar, and Sacral) and back exam.</definition>
                        <v2Number>E16_14</v2Number>
                        <usage>Optional</usage>
                        <comment>Element eExam.14 - Back and Spine Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_07 Spine and E15_05 Thorax AND E16_14 Back Cervical Assessment, E16_15 Back Thoracic Assessment, and E16_16 Back Lumbar/Sacral Assessment. The element value choices have been combined and expanded.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="BackAndSpineAssessment">
                        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                        <xs:attribute name="PN" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
              </xs:sequence>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.ExtremityGroup" id="eExam.ExtremityGroup" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>Group Tag to hold extremity assessment findings information</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="eExam.15" type="ExtremityAssessmentLocation" id="eExam.ExtremityAssessmentFindingLocation" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.15</number>
                        <name>Extremity Assessment Finding Location</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The location of the patient's extremity assessment findings.</definition>
                        <usage>Optional</usage>
                        <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="eExam.16" id="eExam.ExtremitiesAssessment" minOccurs="0" maxOccurs="unbounded">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.16</number>
                        <name>Extremities Assessment</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The assessment findings associated with the patient's extremities.</definition>
                        <v2Number>E16_17</v2Number>
                        <usage>Optional</usage>
                        <comment>Element eExam.16 - Extremities Assessment represents Version 2.2.1 NHTSA Injury Matrix elements E15_08 Upper Extremities and E15_10 Lower Extremities AND E16_17 Extremities-Right Upper Assessment, E16_18 Extremities-Right Lower Assessment, E16_19 Extremities-Left Upper Assessment, and E16_20 Extremities-Left Lower Assessment. The element value choices have been combined and expanded.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="ExtremitiesAssessment">
                        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                        <xs:attribute name="PN" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
              </xs:sequence>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.EyeGroup" id="eExam.EyeGroup" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>Group Tag to hold eye assessment findings information</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="eExam.17" type="EyesAssessmentLocation" id="eExam.EyeAssessmentFindingLocation" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.17</number>
                        <name>Eye Assessment Finding Location</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The location of the patient's eye assessment findings.</definition>
                        <usage>Optional</usage>
                        <comment>Element eExam.17 - Eye Assessment Finding Location represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye location value choices have been expanded.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="eExam.18" id="eExam.EyeAssessment" minOccurs="0" maxOccurs="unbounded">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.18</number>
                        <name>Eye Assessment</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The assessment findings of the patient's eye examination.</definition>
                        <v2Number>E16_21</v2Number>
                        <usage>Optional</usage>
                        <comment>Element eExam.18 - Eye Assessment represents Version 2.2.1 elements E16_21 Eyes-Left Assessment and E16_22 Eyes-Right Assessment. The eye assessment value choices have been combined and expanded.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="EyesAssessment">
                        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                        <xs:attribute name="PN" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
              </xs:sequence>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.LungGroup" id="eExam.LungGroup" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>Group Tag to hold lung assessment findings information</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="eExam.22" type="LungAssessmentLocation" id="eExam.LungAssessmentFindingLocation" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.22</number>
                        <name>Lung Assessment Finding Location</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The location of the patient's lung assessment findings.</definition>
                        <v2Number/>
                        <usage>Optional</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="eExam.23" id="eExam.LungAssessment" minOccurs="0" maxOccurs="unbounded">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.23</number>
                        <name>Lung Assessment</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The assessment findings associated with the patient's lungs.</definition>
                        <v2Number/>
                        <usage>Optional</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="LungAssessment">
                        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                        <xs:attribute name="PN" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
              </xs:sequence>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.ChestGroup" id="eExam.ChestGroup" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>Group Tag to hold chest assessment findings information</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="eExam.24" type="ChestAssessmentLocation" id="eExam.ChestAssessmentFindingLocation" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.24</number>
                        <name>Chest Assessment Finding Location</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The location of the patient's chest assessment findings.</definition>
                        <v2Number/>
                        <usage>Optional</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="eExam.25" id="eExam.ChestAssessment" minOccurs="0" maxOccurs="unbounded">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>eExam.25</number>
                        <name>Chest Assessment</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The assessment findings associated with the patient's chest.</definition>
                        <v2Number/>
                        <usage>Optional</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="ChestAssessment">
                        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                        <xs:attribute name="PN" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
              </xs:sequence>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.19" id="eExam.MentalStatusAssessment" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>eExam.19</number>
                  <name>Mental Status Assessment</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The assessment findings of the patient's mental status examination.</definition>
                  <v2Number>E16_23</v2Number>
                  <usage>Optional</usage>
                  <comment>Element eExam.19 - Mental Status Assessment represents Version 2.2.1 element E16_23 Mental Status Assessment. The element value choices have been expanded.</comment>
                  <performanceMeasuresGroup>
                    <performanceMeasure>Cardiac Arrest</performanceMeasure>
                    <performanceMeasure>Stroke</performanceMeasure>
                  </performanceMeasuresGroup>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="MentalStatusAssessment">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                  <xs:attribute name="PN" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="eExam.20" id="eExam.NeurologicalAssessment" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>eExam.20</number>
                  <name>Neurological Assessment</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The assessment findings of the patient's neurological examination.</definition>
                  <v2Number>E16_24</v2Number>
                  <usage>Optional</usage>
                  <comment>Element eExam.20 - Neurological Assessment represents Version 2.2.1 element E16_24 Neurological Assessment. The element value choices have been expanded.</comment>
                  <performanceMeasuresGroup>
                    <performanceMeasure>Cardiac Arrest</performanceMeasure>
                    <performanceMeasure>Stroke</performanceMeasure>
                  </performanceMeasuresGroup>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="NeurologicalAssessment">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                  <xs:attribute name="PN" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="PN.ExamFindingNotPresent"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
        </xs:sequence>
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
      </xs:complexType>
    </xs:element>
    <xs:element name="eExam.21" nillable="true" id="eExam.StrokeCVASymptomsResolved" minOccurs="0" maxOccurs="1">
      <xs:annotation>
        <xs:documentation>
          <nemsisTacDoc>
            <number>eExam.21</number>
            <name>Stroke/CVA Symptoms Resolved</name>
            <national>No</national>
            <state>Yes</state>
            <definition>Indication if the Stroke/CVA Symptoms resolved and when.</definition>
            <v2Number/>
            <usage>Recommended</usage>
            <comment/>
            <performanceMeasuresGroup>
              <performanceMeasure>Stroke</performanceMeasure>
            </performanceMeasuresGroup>
            <PNNil>Yes</PNNil>
          </nemsisTacDoc>
        </xs:documentation>
      </xs:annotation>
      <xs:complexType>
        <xs:simpleContent>
          <xs:extension base="StrokeCVASymptomsResolved">
            <xs:attribute name="PN" use="optional">
              <xs:simpleType>
                <xs:union memberTypes="PN.UnableToComplete"/>
              </xs:simpleType>
            </xs:attribute>
            <xs:attribute name="NV" use="optional">
              <xs:simpleType>
                <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
              </xs:simpleType>
            </xs:attribute>
          </xs:extension>
        </xs:simpleContent>
      </xs:complexType>
    </xs:element>
  </xs:sequence>
</xs:complexType>
Simple Type EstimatedBodyWeight
Namespace http://www.nemsis.org
Annotations
The patient's body weight in kilograms either measured or estimated
Diagram
Diagram
Type restriction of xs:decimal
Facets
totalDigits 4
fractionDigits 1
maxInclusive 999.9
minInclusive 0.1
Used by
Element eExam/eExam.01
Source
<xs:simpleType name="EstimatedBodyWeight">
  <xs:annotation>
    <xs:documentation>The patient's body weight in kilograms either measured or estimated</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:decimal">
    <xs:totalDigits value="4"/>
    <xs:fractionDigits value="1"/>
    <xs:minInclusive value="0.1"/>
    <xs:maxInclusive value="999.9"/>
  </xs:restriction>
</xs:simpleType>
Simple Type BroselowLutenColor
Namespace http://www.nemsis.org
Annotations
The length-based color as taken from the tape.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3502001
Blue
enumeration 3502003
Green
enumeration 3502005
Grey
enumeration 3502007
Orange
enumeration 3502009
Pink
enumeration 3502011
Purple
enumeration 3502013
Red
enumeration 3502015
White
enumeration 3502017
Yellow
Used by
Element eExam/eExam.02
Source
<xs:simpleType name="BroselowLutenColor">
  <xs:annotation>
    <xs:documentation>The length-based color as taken from the tape.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3502001">
      <xs:annotation>
        <xs:documentation>Blue</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3502003">
      <xs:annotation>
        <xs:documentation>Green</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3502005">
      <xs:annotation>
        <xs:documentation>Grey</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3502007">
      <xs:annotation>
        <xs:documentation>Orange</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3502009">
      <xs:annotation>
        <xs:documentation>Pink</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3502011">
      <xs:annotation>
        <xs:documentation>Purple</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3502013">
      <xs:annotation>
        <xs:documentation>Red</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3502015">
      <xs:annotation>
        <xs:documentation>White</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3502017">
      <xs:annotation>
        <xs:documentation>Yellow</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type SkinAssessment
Namespace http://www.nemsis.org
Annotations
The assessment of the patient's skin on examination
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3504001
Clammy
enumeration 3504003
Cold
enumeration 3504005
Cyanotic
enumeration 3504007
Diaphoretic
enumeration 3504009
Dry
enumeration 3504011
Flushed
enumeration 3504013
Hot
enumeration 3504015
Jaundiced
enumeration 3504017
Lividity
enumeration 3504019
Mottled
enumeration 3504021
Normal
enumeration 3504023
Not Done
enumeration 3504025
Pale
enumeration 3504027
Poor Turgor
enumeration 3504029
Red (Erythematous)
enumeration 3504031
Tenting
enumeration 3504033
Warm
enumeration 3504035
Capillary Nail Bed Refill less than 2 seconds
enumeration 3504037
Capillary Nail Bed Refill 2-4 seconds
enumeration 3504039
Capillary Nail Bed Refill more than 4 seconds
Used by
Source
<xs:simpleType name="SkinAssessment">
  <xs:annotation>
    <xs:documentation>The assessment of the patient's skin on examination</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3504001">
      <xs:annotation>
        <xs:documentation>Clammy</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504003">
      <xs:annotation>
        <xs:documentation>Cold</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504005">
      <xs:annotation>
        <xs:documentation>Cyanotic</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504007">
      <xs:annotation>
        <xs:documentation>Diaphoretic</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504009">
      <xs:annotation>
        <xs:documentation>Dry</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504011">
      <xs:annotation>
        <xs:documentation>Flushed</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504013">
      <xs:annotation>
        <xs:documentation>Hot</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504015">
      <xs:annotation>
        <xs:documentation>Jaundiced</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504017">
      <xs:annotation>
        <xs:documentation>Lividity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504019">
      <xs:annotation>
        <xs:documentation>Mottled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504021">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504023">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504025">
      <xs:annotation>
        <xs:documentation>Pale</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504027">
      <xs:annotation>
        <xs:documentation>Poor Turgor</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504029">
      <xs:annotation>
        <xs:documentation>Red (Erythematous)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504031">
      <xs:annotation>
        <xs:documentation>Tenting</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504033">
      <xs:annotation>
        <xs:documentation>Warm</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504035">
      <xs:annotation>
        <xs:documentation>Capillary Nail Bed Refill less than 2 seconds</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504037">
      <xs:annotation>
        <xs:documentation>Capillary Nail Bed Refill 2-4 seconds</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3504039">
      <xs:annotation>
        <xs:documentation>Capillary Nail Bed Refill more than 4 seconds</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type HeadAssessment
Namespace http://www.nemsis.org
Annotations
The assessment findings associated with the patient's head.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3505001
Abrasion
enumeration 3505003
Avulsion
enumeration 3505005
Bleeding Controlled
enumeration 3505007
Bleeding Uncontrolled
enumeration 3505009
Burn-Blistering
enumeration 3505011
Burn-Charring
enumeration 3505013
Burn-Redness
enumeration 3505015
Burn-White/Waxy
enumeration 3505017
Decapitation
enumeration 3505019
Deformity
enumeration 3505021
Drainage
enumeration 3505023
Foreign Body
enumeration 3505029
Laceration
enumeration 3505031
Mass/Lesion
enumeration 3505033
Normal
enumeration 3505035
Not Done
enumeration 3505037
Pain
enumeration 3505039
Puncture/Stab Wound
enumeration 3505045
Gunshot Wound
enumeration 3505047
Crush Injury
enumeration 3505049
Swelling
enumeration 3505051
Contusion
enumeration 3505053
Tenderness
Used by
Source
<xs:simpleType name="HeadAssessment">
  <xs:annotation>
    <xs:documentation>The assessment findings associated with the patient's head.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3505001">
      <xs:annotation>
        <xs:documentation>Abrasion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505003">
      <xs:annotation>
        <xs:documentation>Avulsion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505005">
      <xs:annotation>
        <xs:documentation>Bleeding Controlled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505007">
      <xs:annotation>
        <xs:documentation>Bleeding Uncontrolled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505009">
      <xs:annotation>
        <xs:documentation>Burn-Blistering</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505011">
      <xs:annotation>
        <xs:documentation>Burn-Charring</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505013">
      <xs:annotation>
        <xs:documentation>Burn-Redness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505015">
      <xs:annotation>
        <xs:documentation>Burn-White/Waxy</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505017">
      <xs:annotation>
        <xs:documentation>Decapitation</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505019">
      <xs:annotation>
        <xs:documentation>Deformity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505021">
      <xs:annotation>
        <xs:documentation>Drainage</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505023">
      <xs:annotation>
        <xs:documentation>Foreign Body</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505029">
      <xs:annotation>
        <xs:documentation>Laceration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505031">
      <xs:annotation>
        <xs:documentation>Mass/Lesion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505033">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505035">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505037">
      <xs:annotation>
        <xs:documentation>Pain</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505039">
      <xs:annotation>
        <xs:documentation>Puncture/Stab Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505045">
      <xs:annotation>
        <xs:documentation>Gunshot Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505047">
      <xs:annotation>
        <xs:documentation>Crush Injury</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505049">
      <xs:annotation>
        <xs:documentation>Swelling</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505051">
      <xs:annotation>
        <xs:documentation>Contusion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3505053">
      <xs:annotation>
        <xs:documentation>Tenderness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type FaceAssessment
Namespace http://www.nemsis.org
Annotations
The assessment findings associated with the patient's face.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3506001
Abrasion
enumeration 3506003
Asymmetric Smile or Droop
enumeration 3506005
Avulsion
enumeration 3506007
Bleeding Controlled
enumeration 3506009
Bleeding Uncontrolled
enumeration 3506011
Burn-Blistering
enumeration 3506013
Burn-Charring
enumeration 3506015
Burn-Redness
enumeration 3506017
Burn-White/Waxy
enumeration 3506021
Deformity
enumeration 3506023
Drainage
enumeration 3506025
Foreign Body
enumeration 3506031
Laceration
enumeration 3506033
Mass/Lesion
enumeration 3506035
Normal
enumeration 3506037
Not Done
enumeration 3506039
Pain
enumeration 3506041
Puncture/Stab Wound
enumeration 3506047
Gunshot Wound
enumeration 3506049
Crush Injury
enumeration 3506051
Tenderness
enumeration 3506053
Swelling
enumeration 3506055
Contusion
Used by
Source
<xs:simpleType name="FaceAssessment">
  <xs:annotation>
    <xs:documentation>The assessment findings associated with the patient's face.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3506001">
      <xs:annotation>
        <xs:documentation>Abrasion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506003">
      <xs:annotation>
        <xs:documentation>Asymmetric Smile or Droop</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506005">
      <xs:annotation>
        <xs:documentation>Avulsion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506007">
      <xs:annotation>
        <xs:documentation>Bleeding Controlled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506009">
      <xs:annotation>
        <xs:documentation>Bleeding Uncontrolled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506011">
      <xs:annotation>
        <xs:documentation>Burn-Blistering</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506013">
      <xs:annotation>
        <xs:documentation>Burn-Charring</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506015">
      <xs:annotation>
        <xs:documentation>Burn-Redness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506017">
      <xs:annotation>
        <xs:documentation>Burn-White/Waxy</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506021">
      <xs:annotation>
        <xs:documentation>Deformity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506023">
      <xs:annotation>
        <xs:documentation>Drainage</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506025">
      <xs:annotation>
        <xs:documentation>Foreign Body</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506031">
      <xs:annotation>
        <xs:documentation>Laceration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506033">
      <xs:annotation>
        <xs:documentation>Mass/Lesion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506035">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506037">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506039">
      <xs:annotation>
        <xs:documentation>Pain</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506041">
      <xs:annotation>
        <xs:documentation>Puncture/Stab Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506047">
      <xs:annotation>
        <xs:documentation>Gunshot Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506049">
      <xs:annotation>
        <xs:documentation>Crush Injury</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506051">
      <xs:annotation>
        <xs:documentation>Tenderness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506053">
      <xs:annotation>
        <xs:documentation>Swelling</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3506055">
      <xs:annotation>
        <xs:documentation>Contusion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type NeckAssessment
Namespace http://www.nemsis.org
Annotations
The assessment of the patient's head and neck area on examination
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3507001
Abrasion
enumeration 3507003
Avulsion
enumeration 3507005
Bleeding Controlled
enumeration 3507007
Bleeding Uncontrolled
enumeration 3507009
Burn-Blistering
enumeration 3507011
Burn-Charring
enumeration 3507013
Burn-Redness
enumeration 3507015
Burn-White/Waxy
enumeration 3507017
Decapitation
enumeration 3507019
Foreign Body
enumeration 3507025
JVD
enumeration 3507027
Laceration
enumeration 3507029
Normal
enumeration 3507031
Not Done
enumeration 3507033
Pain
enumeration 3507035
Puncture/Stab Wound
enumeration 3507037
Stridor
enumeration 3507039
Subcutaneous Air
enumeration 3507045
Tracheal Deviation-Left
enumeration 3507047
Tracheal Deviation-Right
enumeration 3507049
Gunshot Wound
enumeration 3507051
Crush Injury
enumeration 3507053
Swelling
enumeration 3507055
Contusion
enumeration 3507057
Deformity
enumeration 3507059
Tenderness
Used by
Source
<xs:simpleType name="NeckAssessment">
  <xs:annotation>
    <xs:documentation>The assessment of the patient's head and neck area on examination</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3507001">
      <xs:annotation>
        <xs:documentation>Abrasion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507003">
      <xs:annotation>
        <xs:documentation>Avulsion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507005">
      <xs:annotation>
        <xs:documentation>Bleeding Controlled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507007">
      <xs:annotation>
        <xs:documentation>Bleeding Uncontrolled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507009">
      <xs:annotation>
        <xs:documentation>Burn-Blistering</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507011">
      <xs:annotation>
        <xs:documentation>Burn-Charring</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507013">
      <xs:annotation>
        <xs:documentation>Burn-Redness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507015">
      <xs:annotation>
        <xs:documentation>Burn-White/Waxy</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507017">
      <xs:annotation>
        <xs:documentation>Decapitation</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507019">
      <xs:annotation>
        <xs:documentation>Foreign Body</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507025">
      <xs:annotation>
        <xs:documentation>JVD</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507027">
      <xs:annotation>
        <xs:documentation>Laceration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507029">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507031">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507033">
      <xs:annotation>
        <xs:documentation>Pain</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507035">
      <xs:annotation>
        <xs:documentation>Puncture/Stab Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507037">
      <xs:annotation>
        <xs:documentation>Stridor</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507039">
      <xs:annotation>
        <xs:documentation>Subcutaneous Air</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507045">
      <xs:annotation>
        <xs:documentation>Tracheal Deviation-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507047">
      <xs:annotation>
        <xs:documentation>Tracheal Deviation-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507049">
      <xs:annotation>
        <xs:documentation>Gunshot Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507051">
      <xs:annotation>
        <xs:documentation>Crush Injury</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507053">
      <xs:annotation>
        <xs:documentation>Swelling</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507055">
      <xs:annotation>
        <xs:documentation>Contusion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507057">
      <xs:annotation>
        <xs:documentation>Deformity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3507059">
      <xs:annotation>
        <xs:documentation>Tenderness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type HeartAssessment
Namespace http://www.nemsis.org
Annotations
The assessment of the patient's heart on examination
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3509001
Clicks
enumeration 3509003
Heart Sounds Decreased
enumeration 3509005
Murmur-Diastolic
enumeration 3509007
Murmur-Systolic
enumeration 3509009
Normal
enumeration 3509011
Not Done
enumeration 3509013
Rubs
enumeration 3509015
S1
enumeration 3509017
S2
enumeration 3509019
S3
enumeration 3509021
S4
Used by
Source
<xs:simpleType name="HeartAssessment">
  <xs:annotation>
    <xs:documentation>The assessment of the patient's heart on examination</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3509001">
      <xs:annotation>
        <xs:documentation>Clicks</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509003">
      <xs:annotation>
        <xs:documentation>Heart Sounds Decreased</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509005">
      <xs:annotation>
        <xs:documentation>Murmur-Diastolic</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509007">
      <xs:annotation>
        <xs:documentation>Murmur-Systolic</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509009">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509011">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509013">
      <xs:annotation>
        <xs:documentation>Rubs</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509015">
      <xs:annotation>
        <xs:documentation>S1</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509017">
      <xs:annotation>
        <xs:documentation>S2</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509019">
      <xs:annotation>
        <xs:documentation>S3</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3509021">
      <xs:annotation>
        <xs:documentation>S4</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type AbdominalExamFindingLocation
Namespace http://www.nemsis.org
Annotations
The location of the Abdominal Exam Finding.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3510001
Generalized
enumeration 3510003
Left Lower Quadrant
enumeration 3510005
Left Upper Quadrant
enumeration 3510007
Periumbilical
enumeration 3510009
Right Lower Quadrant
enumeration 3510011
Right Upper Quadrant
enumeration 3510013
Epigastric
Used by
Source
<xs:simpleType name="AbdominalExamFindingLocation">
  <xs:annotation>
    <xs:documentation>The location of the Abdominal Exam Finding.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3510001">
      <xs:annotation>
        <xs:documentation>Generalized</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3510003">
      <xs:annotation>
        <xs:documentation>Left Lower Quadrant</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3510005">
      <xs:annotation>
        <xs:documentation>Left Upper Quadrant</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3510007">
      <xs:annotation>
        <xs:documentation>Periumbilical</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3510009">
      <xs:annotation>
        <xs:documentation>Right Lower Quadrant</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3510011">
      <xs:annotation>
        <xs:documentation>Right Upper Quadrant</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3510013">
      <xs:annotation>
        <xs:documentation>Epigastric</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type AbdomenAssessment
Namespace http://www.nemsis.org
Annotations
The assessment findings associated with the patient's abdomen.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3511001
Abrasion
enumeration 3511003
Avulsion
enumeration 3511005
Bleeding Controlled
enumeration 3511007
Bleeding Uncontrolled
enumeration 3511009
Bowel Sounds-Absent
enumeration 3511011
Bowel Sounds-Present
enumeration 3511013
Burn-Blistering
enumeration 3511015
Burn-Charring
enumeration 3511017
Burn-Redness
enumeration 3511019
Burn-White/Waxy
enumeration 3511021
Distention
enumeration 3511023
Foreign Body
enumeration 3511025
Guarding
enumeration 3511031
Laceration
enumeration 3511033
Mass/Lesion
enumeration 3511035
Mass-Pulsating
enumeration 3511037
Normal
enumeration 3511039
Not Done
enumeration 3511041
Pain
enumeration 3511043
Pregnant-Palpable Uterus
enumeration 3511045
Puncture/Stab Wound
enumeration 3511051
Tenderness
enumeration 3511053
Gunshot Wound
enumeration 3511055
Crush Injury
enumeration 3511057
Swelling
enumeration 3511059
Contusion
enumeration 3511061
Deformity
enumeration 3511063
Rebound Tenderness
enumeration 3511065
Rigidity
Used by
Source
<xs:simpleType name="AbdomenAssessment">
  <xs:annotation>
    <xs:documentation>The assessment findings associated with the patient's abdomen.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3511001">
      <xs:annotation>
        <xs:documentation>Abrasion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511003">
      <xs:annotation>
        <xs:documentation>Avulsion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511005">
      <xs:annotation>
        <xs:documentation>Bleeding Controlled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511007">
      <xs:annotation>
        <xs:documentation>Bleeding Uncontrolled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511009">
      <xs:annotation>
        <xs:documentation>Bowel Sounds-Absent</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511011">
      <xs:annotation>
        <xs:documentation>Bowel Sounds-Present</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511013">
      <xs:annotation>
        <xs:documentation>Burn-Blistering</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511015">
      <xs:annotation>
        <xs:documentation>Burn-Charring</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511017">
      <xs:annotation>
        <xs:documentation>Burn-Redness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511019">
      <xs:annotation>
        <xs:documentation>Burn-White/Waxy</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511021">
      <xs:annotation>
        <xs:documentation>Distention</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511023">
      <xs:annotation>
        <xs:documentation>Foreign Body</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511025">
      <xs:annotation>
        <xs:documentation>Guarding</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511031">
      <xs:annotation>
        <xs:documentation>Laceration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511033">
      <xs:annotation>
        <xs:documentation>Mass/Lesion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511035">
      <xs:annotation>
        <xs:documentation>Mass-Pulsating</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511037">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511039">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511041">
      <xs:annotation>
        <xs:documentation>Pain</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511043">
      <xs:annotation>
        <xs:documentation>Pregnant-Palpable Uterus</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511045">
      <xs:annotation>
        <xs:documentation>Puncture/Stab Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511051">
      <xs:annotation>
        <xs:documentation>Tenderness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511053">
      <xs:annotation>
        <xs:documentation>Gunshot Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511055">
      <xs:annotation>
        <xs:documentation>Crush Injury</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511057">
      <xs:annotation>
        <xs:documentation>Swelling</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511059">
      <xs:annotation>
        <xs:documentation>Contusion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511061">
      <xs:annotation>
        <xs:documentation>Deformity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511063">
      <xs:annotation>
        <xs:documentation>Rebound Tenderness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3511065">
      <xs:annotation>
        <xs:documentation>Rigidity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type GUAssessment
Namespace http://www.nemsis.org
Annotations
The assessment of the patient's GU area on examination
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3512001
Abrasion
enumeration 3512003
Avulsion
enumeration 3512005
Bleeding Controlled
enumeration 3512007
Bleeding Uncontrolled
enumeration 3512009
Bleeding-Rectal
enumeration 3512011
Bleeding-Urethral
enumeration 3512013
Bleeding-Vaginal
enumeration 3512015
Burn-Blistering
enumeration 3512017
Burn-Charring
enumeration 3512019
Burn-Redness
enumeration 3512021
Burn-White/Waxy
enumeration 3512023
Deformity
enumeration 3512025
Foreign Body
enumeration 3512027
Genital Injury
enumeration 3512033
Laceration
enumeration 3512035
Mass/Lesion
enumeration 3512037
Normal
enumeration 3512039
Not Done
enumeration 3512041
Pain
enumeration 3512043
Pelvic Fracture
enumeration 3512045
Pelvic Instability
enumeration 3512047
Penile Priapism/Erection
enumeration 3512049
Pregnant-Crowning
enumeration 3512051
Puncture/Stab Wound
enumeration 3512057
Tenderness
enumeration 3512059
Gunshot Wound
enumeration 3512061
Crush Injury
enumeration 3512063
Swelling
enumeration 3512065
Contusion
Used by
Source
<xs:simpleType name="GUAssessment">
  <xs:annotation>
    <xs:documentation>The assessment of the patient's GU area on examination</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3512001">
      <xs:annotation>
        <xs:documentation>Abrasion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512003">
      <xs:annotation>
        <xs:documentation>Avulsion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512005">
      <xs:annotation>
        <xs:documentation>Bleeding Controlled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512007">
      <xs:annotation>
        <xs:documentation>Bleeding Uncontrolled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512009">
      <xs:annotation>
        <xs:documentation>Bleeding-Rectal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512011">
      <xs:annotation>
        <xs:documentation>Bleeding-Urethral</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512013">
      <xs:annotation>
        <xs:documentation>Bleeding-Vaginal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512015">
      <xs:annotation>
        <xs:documentation>Burn-Blistering</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512017">
      <xs:annotation>
        <xs:documentation>Burn-Charring</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512019">
      <xs:annotation>
        <xs:documentation>Burn-Redness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512021">
      <xs:annotation>
        <xs:documentation>Burn-White/Waxy</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512023">
      <xs:annotation>
        <xs:documentation>Deformity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512025">
      <xs:annotation>
        <xs:documentation>Foreign Body</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512027">
      <xs:annotation>
        <xs:documentation>Genital Injury</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512033">
      <xs:annotation>
        <xs:documentation>Laceration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512035">
      <xs:annotation>
        <xs:documentation>Mass/Lesion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512037">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512039">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512041">
      <xs:annotation>
        <xs:documentation>Pain</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512043">
      <xs:annotation>
        <xs:documentation>Pelvic Fracture</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512045">
      <xs:annotation>
        <xs:documentation>Pelvic Instability</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512047">
      <xs:annotation>
        <xs:documentation>Penile Priapism/Erection</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512049">
      <xs:annotation>
        <xs:documentation>Pregnant-Crowning</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512051">
      <xs:annotation>
        <xs:documentation>Puncture/Stab Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512057">
      <xs:annotation>
        <xs:documentation>Tenderness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512059">
      <xs:annotation>
        <xs:documentation>Gunshot Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512061">
      <xs:annotation>
        <xs:documentation>Crush Injury</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512063">
      <xs:annotation>
        <xs:documentation>Swelling</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3512065">
      <xs:annotation>
        <xs:documentation>Contusion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type BackAndSpineAssessmentLocation
Namespace http://www.nemsis.org
Annotations
The location where Back and Spine assessment finding was located.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3513001
Back-General
enumeration 3513003
Cervical-Left
enumeration 3513005
Cervical-Midline
enumeration 3513007
Cervical-Right
enumeration 3513009
Lumbar-Left
enumeration 3513011
Lumbar-Midline
enumeration 3513013
Lumbar-Right
enumeration 3513015
Thoracic-Left
enumeration 3513017
Thoracic-Midline
enumeration 3513019
Thoracic-Right
enumeration 3513021
Sacral-Left
enumeration 3513023
Sacral-Midline
enumeration 3513025
Sacral-Right
Used by
Source
<xs:simpleType name="BackAndSpineAssessmentLocation">
  <xs:annotation>
    <xs:documentation>The location where Back and Spine assessment finding was located.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3513001">
      <xs:annotation>
        <xs:documentation>Back-General</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513003">
      <xs:annotation>
        <xs:documentation>Cervical-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513005">
      <xs:annotation>
        <xs:documentation>Cervical-Midline</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513007">
      <xs:annotation>
        <xs:documentation>Cervical-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513009">
      <xs:annotation>
        <xs:documentation>Lumbar-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513011">
      <xs:annotation>
        <xs:documentation>Lumbar-Midline</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513013">
      <xs:annotation>
        <xs:documentation>Lumbar-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513015">
      <xs:annotation>
        <xs:documentation>Thoracic-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513017">
      <xs:annotation>
        <xs:documentation>Thoracic-Midline</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513019">
      <xs:annotation>
        <xs:documentation>Thoracic-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513021">
      <xs:annotation>
        <xs:documentation>Sacral-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513023">
      <xs:annotation>
        <xs:documentation>Sacral-Midline</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3513025">
      <xs:annotation>
        <xs:documentation>Sacral-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type BackAndSpineAssessment
Namespace http://www.nemsis.org
Annotations
The assessment findings associated with the patient's spine (Cervical, Thoracic, Lumbar, and Sacral) and back exam.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3514001
Abrasion
enumeration 3514003
Avulsion
enumeration 3514005
Bleeding Controlled
enumeration 3514007
Bleeding Uncontrolled
enumeration 3514009
Burn-Blistering
enumeration 3514011
Burn-Charring
enumeration 3514013
Burn-Redness
enumeration 3514015
Burn-White/Waxy
enumeration 3514017
Deformity
enumeration 3514019
Foreign Body
enumeration 3514025
Laceration
enumeration 3514027
Normal
enumeration 3514029
Not Done
enumeration 3514031
Pain
enumeration 3514033
Pain with Range of Motion
enumeration 3514035
Puncture/Stab Wound
enumeration 3514041
Tenderness Costovertebral Angle
enumeration 3514043
Tenderness Midline Spinous Process
enumeration 3514045
Tenderness Paraspinous
enumeration 3514047
Gunshot Wound
enumeration 3514049
Crush Injury
enumeration 3514051
Swelling
enumeration 3514053
Contusion
enumeration 3514055
Tenderness
Used by
Source
<xs:simpleType name="BackAndSpineAssessment">
  <xs:annotation>
    <xs:documentation>The assessment findings associated with the patient's spine (Cervical, Thoracic, Lumbar, and Sacral) and back exam.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3514001">
      <xs:annotation>
        <xs:documentation>Abrasion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514003">
      <xs:annotation>
        <xs:documentation>Avulsion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514005">
      <xs:annotation>
        <xs:documentation>Bleeding Controlled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514007">
      <xs:annotation>
        <xs:documentation>Bleeding Uncontrolled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514009">
      <xs:annotation>
        <xs:documentation>Burn-Blistering</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514011">
      <xs:annotation>
        <xs:documentation>Burn-Charring</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514013">
      <xs:annotation>
        <xs:documentation>Burn-Redness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514015">
      <xs:annotation>
        <xs:documentation>Burn-White/Waxy</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514017">
      <xs:annotation>
        <xs:documentation>Deformity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514019">
      <xs:annotation>
        <xs:documentation>Foreign Body</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514025">
      <xs:annotation>
        <xs:documentation>Laceration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514027">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514029">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514031">
      <xs:annotation>
        <xs:documentation>Pain</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514033">
      <xs:annotation>
        <xs:documentation>Pain with Range of Motion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514035">
      <xs:annotation>
        <xs:documentation>Puncture/Stab Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514041">
      <xs:annotation>
        <xs:documentation>Tenderness Costovertebral Angle</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514043">
      <xs:annotation>
        <xs:documentation>Tenderness Midline Spinous Process</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514045">
      <xs:annotation>
        <xs:documentation>Tenderness Paraspinous</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514047">
      <xs:annotation>
        <xs:documentation>Gunshot Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514049">
      <xs:annotation>
        <xs:documentation>Crush Injury</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514051">
      <xs:annotation>
        <xs:documentation>Swelling</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514053">
      <xs:annotation>
        <xs:documentation>Contusion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3514055">
      <xs:annotation>
        <xs:documentation>Tenderness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type ExtremityAssessmentLocation
Namespace http://www.nemsis.org
Annotations
The physical location of the Extremity Assessment finding
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3515001
Ankle-Left
enumeration 3515003
Ankle-Right
enumeration 3515005
Arm-Upper-Left
enumeration 3515007
Arm-Upper-Right
enumeration 3515009
Elbow-Left
enumeration 3515011
Elbow-Right
enumeration 3515013
Finger-2nd (Index)-Left
enumeration 3515015
Finger-2nd (Index)-Right
enumeration 3515017
Finger-3rd (Middle)-Left
enumeration 3515019
Finger-3rd (Middle)-Right
enumeration 3515021
Finger-4th (Ring)-Left
enumeration 3515023
Finger-4th (Ring)-Right
enumeration 3515025
Finger-5th (Smallest)-Left
enumeration 3515027
Finger-5th (Smallest)-Right
enumeration 3515029
Foot-Dorsal-Left
enumeration 3515031
Foot-Dorsal-Right
enumeration 3515033
Foot-Plantar-Left
enumeration 3515035
Foot-Plantar-Right
enumeration 3515037
Arm-Lower-Left
enumeration 3515039
Arm-Lower-Right
enumeration 3515041
Hand-Dorsal-Left
enumeration 3515043
Hand-Dorsal-Right
enumeration 3515045
Hand-Palm-Left
enumeration 3515047
Hand-Palm-Right
enumeration 3515049
Hip-Left
enumeration 3515051
Hip-Right
enumeration 3515053
Knee-Left
enumeration 3515055
Knee-Right
enumeration 3515057
Leg-Lower-Left
enumeration 3515059
Leg-Lower-Right
enumeration 3515061
Leg-Upper-Left
enumeration 3515063
Leg-Upper-Right
enumeration 3515065
Shoulder-Left
enumeration 3515067
Shoulder-Right
enumeration 3515069
Thumb-Left
enumeration 3515071
Thumb-Right
enumeration 3515073
Toe-1st (Big)-Left
enumeration 3515075
Toe-1st (Big)-Right
enumeration 3515077
Toe-2nd-Left
enumeration 3515079
Toe-2nd-Right
enumeration 3515081
Toe-3rd-Left
enumeration 3515083
Toe-3rd-Right
enumeration 3515085
Toe-4th-Left
enumeration 3515087
Toe-4th-Right
enumeration 3515089
Toe-5th (Smallest)-Left
enumeration 3515091
Toe-5th (Smallest)-Right
enumeration 3515093
Wrist-Left
enumeration 3515095
Wrist-Right
enumeration 3515097
Arm-Whole Arm and Hand-Left
enumeration 3515099
Arm-Whole Arm and Hand-Right
enumeration 3515101
Hand-Whole Hand-Left
enumeration 3515103
Hand-Whole Hand-Right
enumeration 3515105
Leg-Whole Leg-Left
enumeration 3515107
Leg-Whole Leg-Right
enumeration 3515109
Foot-Whole Foot-Left
enumeration 3515111
Foot-Whole Foot-Right
Used by
Source
<xs:simpleType name="ExtremityAssessmentLocation">
  <xs:annotation>
    <xs:documentation>The physical location of the Extremity Assessment finding</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3515001">
      <xs:annotation>
        <xs:documentation>Ankle-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515003">
      <xs:annotation>
        <xs:documentation>Ankle-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515005">
      <xs:annotation>
        <xs:documentation>Arm-Upper-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515007">
      <xs:annotation>
        <xs:documentation>Arm-Upper-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515009">
      <xs:annotation>
        <xs:documentation>Elbow-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515011">
      <xs:annotation>
        <xs:documentation>Elbow-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515013">
      <xs:annotation>
        <xs:documentation>Finger-2nd (Index)-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515015">
      <xs:annotation>
        <xs:documentation>Finger-2nd (Index)-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515017">
      <xs:annotation>
        <xs:documentation>Finger-3rd (Middle)-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515019">
      <xs:annotation>
        <xs:documentation>Finger-3rd (Middle)-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515021">
      <xs:annotation>
        <xs:documentation>Finger-4th (Ring)-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515023">
      <xs:annotation>
        <xs:documentation>Finger-4th (Ring)-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515025">
      <xs:annotation>
        <xs:documentation>Finger-5th (Smallest)-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515027">
      <xs:annotation>
        <xs:documentation>Finger-5th (Smallest)-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515029">
      <xs:annotation>
        <xs:documentation>Foot-Dorsal-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515031">
      <xs:annotation>
        <xs:documentation>Foot-Dorsal-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515033">
      <xs:annotation>
        <xs:documentation>Foot-Plantar-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515035">
      <xs:annotation>
        <xs:documentation>Foot-Plantar-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515037">
      <xs:annotation>
        <xs:documentation>Arm-Lower-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515039">
      <xs:annotation>
        <xs:documentation>Arm-Lower-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515041">
      <xs:annotation>
        <xs:documentation>Hand-Dorsal-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515043">
      <xs:annotation>
        <xs:documentation>Hand-Dorsal-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515045">
      <xs:annotation>
        <xs:documentation>Hand-Palm-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515047">
      <xs:annotation>
        <xs:documentation>Hand-Palm-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515049">
      <xs:annotation>
        <xs:documentation>Hip-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515051">
      <xs:annotation>
        <xs:documentation>Hip-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515053">
      <xs:annotation>
        <xs:documentation>Knee-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515055">
      <xs:annotation>
        <xs:documentation>Knee-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515057">
      <xs:annotation>
        <xs:documentation>Leg-Lower-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515059">
      <xs:annotation>
        <xs:documentation>Leg-Lower-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515061">
      <xs:annotation>
        <xs:documentation>Leg-Upper-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515063">
      <xs:annotation>
        <xs:documentation>Leg-Upper-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515065">
      <xs:annotation>
        <xs:documentation>Shoulder-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515067">
      <xs:annotation>
        <xs:documentation>Shoulder-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515069">
      <xs:annotation>
        <xs:documentation>Thumb-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515071">
      <xs:annotation>
        <xs:documentation>Thumb-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515073">
      <xs:annotation>
        <xs:documentation>Toe-1st (Big)-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515075">
      <xs:annotation>
        <xs:documentation>Toe-1st (Big)-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515077">
      <xs:annotation>
        <xs:documentation>Toe-2nd-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515079">
      <xs:annotation>
        <xs:documentation>Toe-2nd-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515081">
      <xs:annotation>
        <xs:documentation>Toe-3rd-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515083">
      <xs:annotation>
        <xs:documentation>Toe-3rd-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515085">
      <xs:annotation>
        <xs:documentation>Toe-4th-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515087">
      <xs:annotation>
        <xs:documentation>Toe-4th-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515089">
      <xs:annotation>
        <xs:documentation>Toe-5th (Smallest)-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515091">
      <xs:annotation>
        <xs:documentation>Toe-5th (Smallest)-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515093">
      <xs:annotation>
        <xs:documentation>Wrist-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515095">
      <xs:annotation>
        <xs:documentation>Wrist-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515097">
      <xs:annotation>
        <xs:documentation>Arm-Whole Arm and Hand-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515099">
      <xs:annotation>
        <xs:documentation>Arm-Whole Arm and Hand-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515101">
      <xs:annotation>
        <xs:documentation>Hand-Whole Hand-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515103">
      <xs:annotation>
        <xs:documentation>Hand-Whole Hand-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515105">
      <xs:annotation>
        <xs:documentation>Leg-Whole Leg-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515107">
      <xs:annotation>
        <xs:documentation>Leg-Whole Leg-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515109">
      <xs:annotation>
        <xs:documentation>Foot-Whole Foot-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3515111">
      <xs:annotation>
        <xs:documentation>Foot-Whole Foot-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type ExtremitiesAssessment
Namespace http://www.nemsis.org
Annotations
The assessment of the patient's extremities.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3516001
Abrasion
enumeration 3516003
Amputation-Acute
enumeration 3516005
Amputation-Previous
enumeration 3516007
Avulsion
enumeration 3516009
Bleeding Controlled
enumeration 3516011
Bleeding Uncontrolled
enumeration 3516013
Burn-Blistering
enumeration 3516015
Burn-Charring
enumeration 3516017
Burn-Redness
enumeration 3516019
Burn-White/Waxy
enumeration 3516021
Clubbing (of fingers)
enumeration 3516023
Crush Injury
enumeration 3516025
Deformity
enumeration 3516027
Dislocation
enumeration 3516029
Edema
enumeration 3516031
Foreign Body
enumeration 3516033
Fracture-Closed
enumeration 3516035
Fracture-Open
enumeration 3516041
Laceration
enumeration 3516043
Motor Function-Abnormal/Weakness
enumeration 3516045
Motor Function-Absent
enumeration 3516047
Motor Function-Normal
enumeration 3516049
Normal
enumeration 3516051
Not Done
enumeration 3516053
Pain
enumeration 3516055
Paralysis
enumeration 3516057
Pulse-Abnormal
enumeration 3516059
Pulse-Absent
enumeration 3516061
Pulse-Normal
enumeration 3516063
Puncture/Stab Wound
enumeration 3516065
Sensation-Abnormal
enumeration 3516067
Sensation-Absent
enumeration 3516069
Sensation-Normal
enumeration 3516075
Tenderness
enumeration 3516077
Gunshot Wound
enumeration 3516079
Swelling
enumeration 3516081
Contusion
enumeration 3516083
Arm Drift
Used by
Source
<xs:simpleType name="ExtremitiesAssessment">
  <xs:annotation>
    <xs:documentation>The assessment of the patient's extremities.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3516001">
      <xs:annotation>
        <xs:documentation>Abrasion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516003">
      <xs:annotation>
        <xs:documentation>Amputation-Acute</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516005">
      <xs:annotation>
        <xs:documentation>Amputation-Previous</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516007">
      <xs:annotation>
        <xs:documentation>Avulsion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516009">
      <xs:annotation>
        <xs:documentation>Bleeding Controlled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516011">
      <xs:annotation>
        <xs:documentation>Bleeding Uncontrolled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516013">
      <xs:annotation>
        <xs:documentation>Burn-Blistering</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516015">
      <xs:annotation>
        <xs:documentation>Burn-Charring</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516017">
      <xs:annotation>
        <xs:documentation>Burn-Redness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516019">
      <xs:annotation>
        <xs:documentation>Burn-White/Waxy</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516021">
      <xs:annotation>
        <xs:documentation>Clubbing (of fingers)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516023">
      <xs:annotation>
        <xs:documentation>Crush Injury</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516025">
      <xs:annotation>
        <xs:documentation>Deformity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516027">
      <xs:annotation>
        <xs:documentation>Dislocation</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516029">
      <xs:annotation>
        <xs:documentation>Edema</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516031">
      <xs:annotation>
        <xs:documentation>Foreign Body</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516033">
      <xs:annotation>
        <xs:documentation>Fracture-Closed</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516035">
      <xs:annotation>
        <xs:documentation>Fracture-Open</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516041">
      <xs:annotation>
        <xs:documentation>Laceration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516043">
      <xs:annotation>
        <xs:documentation>Motor Function-Abnormal/Weakness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516045">
      <xs:annotation>
        <xs:documentation>Motor Function-Absent</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516047">
      <xs:annotation>
        <xs:documentation>Motor Function-Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516049">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516051">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516053">
      <xs:annotation>
        <xs:documentation>Pain</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516055">
      <xs:annotation>
        <xs:documentation>Paralysis</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516057">
      <xs:annotation>
        <xs:documentation>Pulse-Abnormal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516059">
      <xs:annotation>
        <xs:documentation>Pulse-Absent</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516061">
      <xs:annotation>
        <xs:documentation>Pulse-Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516063">
      <xs:annotation>
        <xs:documentation>Puncture/Stab Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516065">
      <xs:annotation>
        <xs:documentation>Sensation-Abnormal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516067">
      <xs:annotation>
        <xs:documentation>Sensation-Absent</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516069">
      <xs:annotation>
        <xs:documentation>Sensation-Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516075">
      <xs:annotation>
        <xs:documentation>Tenderness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516077">
      <xs:annotation>
        <xs:documentation>Gunshot Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516079">
      <xs:annotation>
        <xs:documentation>Swelling</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516081">
      <xs:annotation>
        <xs:documentation>Contusion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3516083">
      <xs:annotation>
        <xs:documentation>Arm Drift</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type EyesAssessmentLocation
Namespace http://www.nemsis.org
Annotations
The location of the eye exam findings (right, left, bilateral)
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3517001
Bilateral
enumeration 3517003
Left
enumeration 3517005
Right
Used by
Source
<xs:simpleType name="EyesAssessmentLocation">
  <xs:annotation>
    <xs:documentation>The location of the eye exam findings (right, left, bilateral)</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3517001">
      <xs:annotation>
        <xs:documentation>Bilateral</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3517003">
      <xs:annotation>
        <xs:documentation>Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3517005">
      <xs:annotation>
        <xs:documentation>Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type EyesAssessment
Namespace http://www.nemsis.org
Annotations
The assessment findings of the patient's eye examination.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3518001
1-mm
enumeration 3518003
2-mm
enumeration 3518005
3-mm
enumeration 3518007
4-mm
enumeration 3518009
5-mm
enumeration 3518011
6-mm
enumeration 3518013
7-mm
enumeration 3518015
8-mm or >
enumeration 3518017
Blind
enumeration 3518019
Cataract Present
enumeration 3518021
Clouded
enumeration 3518023
Deformity
enumeration 3518025
Dysconjugate Gaze
enumeration 3518027
Foreign Body
enumeration 3518029
Glaucoma Present
enumeration 3518031
Hyphema
enumeration 3518033
Jaundiced Sclera
enumeration 3518035
Missing
enumeration 3518037
Non-Reactive
enumeration 3518039
Not Done
enumeration 3518041
Non-Reactive Prosthetic
enumeration 3518043
Nystagmus Noted
enumeration 3518045
Open Globe
enumeration 3518047
PERRL
enumeration 3518049
Pupil-Irregular/Teardrop
enumeration 3518051
Reactive
enumeration 3518053
Sluggish
enumeration 3518055
Swelling
enumeration 3518057
Contusion
enumeration 3518059
Puncture/Stab Wound
enumeration 3518061
Dilated
enumeration 3518063
Pin Point
Used by
Source
<xs:simpleType name="EyesAssessment">
  <xs:annotation>
    <xs:documentation>The assessment findings of the patient's eye examination.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3518001">
      <xs:annotation>
        <xs:documentation>1-mm</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518003">
      <xs:annotation>
        <xs:documentation>2-mm</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518005">
      <xs:annotation>
        <xs:documentation>3-mm</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518007">
      <xs:annotation>
        <xs:documentation>4-mm</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518009">
      <xs:annotation>
        <xs:documentation>5-mm</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518011">
      <xs:annotation>
        <xs:documentation>6-mm</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518013">
      <xs:annotation>
        <xs:documentation>7-mm</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518015">
      <xs:annotation>
        <xs:documentation>8-mm or ></xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518017">
      <xs:annotation>
        <xs:documentation>Blind</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518019">
      <xs:annotation>
        <xs:documentation>Cataract Present</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518021">
      <xs:annotation>
        <xs:documentation>Clouded</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518023">
      <xs:annotation>
        <xs:documentation>Deformity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518025">
      <xs:annotation>
        <xs:documentation>Dysconjugate Gaze</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518027">
      <xs:annotation>
        <xs:documentation>Foreign Body</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518029">
      <xs:annotation>
        <xs:documentation>Glaucoma Present</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518031">
      <xs:annotation>
        <xs:documentation>Hyphema</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518033">
      <xs:annotation>
        <xs:documentation>Jaundiced Sclera</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518035">
      <xs:annotation>
        <xs:documentation>Missing</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518037">
      <xs:annotation>
        <xs:documentation>Non-Reactive</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518039">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518041">
      <xs:annotation>
        <xs:documentation>Non-Reactive Prosthetic</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518043">
      <xs:annotation>
        <xs:documentation>Nystagmus Noted</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518045">
      <xs:annotation>
        <xs:documentation>Open Globe</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518047">
      <xs:annotation>
        <xs:documentation>PERRL</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518049">
      <xs:annotation>
        <xs:documentation>Pupil-Irregular/Teardrop</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518051">
      <xs:annotation>
        <xs:documentation>Reactive</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518053">
      <xs:annotation>
        <xs:documentation>Sluggish</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518055">
      <xs:annotation>
        <xs:documentation>Swelling</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518057">
      <xs:annotation>
        <xs:documentation>Contusion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518059">
      <xs:annotation>
        <xs:documentation>Puncture/Stab Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518061">
      <xs:annotation>
        <xs:documentation>Dilated</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3518063">
      <xs:annotation>
        <xs:documentation>Pin Point</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type LungAssessmentLocation
Namespace http://www.nemsis.org
Annotations
The location of the Lung Exam Finding.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3522001
Left
enumeration 3522003
Right
enumeration 3522005
Bilateral
Used by
Source
<xs:simpleType name="LungAssessmentLocation">
  <xs:annotation>
    <xs:documentation>The location of the Lung Exam Finding.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3522001">
      <xs:annotation>
        <xs:documentation>Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3522003">
      <xs:annotation>
        <xs:documentation>Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3522005">
      <xs:annotation>
        <xs:documentation>Bilateral</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type LungAssessment
Namespace http://www.nemsis.org
Annotations
The assessment of the patient's lungs on examination
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3523001
Breath Sounds-Absent
enumeration 3523003
Breath Sounds-Decreased
enumeration 3523005
Breath Sounds-Equal
enumeration 3523007
Breath Sounds-Normal
enumeration 3523009
Foreign Body
enumeration 3523011
Increased Respiratory Effort
enumeration 3523013
Normal
enumeration 3523015
Not Done
enumeration 3523017
Pain
enumeration 3523019
Pain with Inspiraton/Expiration
enumeration 3523021
Rales
enumeration 3523023
Rhonchi
enumeration 3523025
Rhonchi/Wheezing
enumeration 3523027
Stridor
enumeration 3523029
Wheezing-Expiratory
enumeration 3523031
Wheezing-Inspiratory
Used by
Source
<xs:simpleType name="LungAssessment">
  <xs:annotation>
    <xs:documentation>The assessment of the patient's lungs on examination</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3523001">
      <xs:annotation>
        <xs:documentation>Breath Sounds-Absent</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523003">
      <xs:annotation>
        <xs:documentation>Breath Sounds-Decreased</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523005">
      <xs:annotation>
        <xs:documentation>Breath Sounds-Equal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523007">
      <xs:annotation>
        <xs:documentation>Breath Sounds-Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523009">
      <xs:annotation>
        <xs:documentation>Foreign Body</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523011">
      <xs:annotation>
        <xs:documentation>Increased Respiratory Effort</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523013">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523015">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523017">
      <xs:annotation>
        <xs:documentation>Pain</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523019">
      <xs:annotation>
        <xs:documentation>Pain with Inspiraton/Expiration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523021">
      <xs:annotation>
        <xs:documentation>Rales</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523023">
      <xs:annotation>
        <xs:documentation>Rhonchi</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523025">
      <xs:annotation>
        <xs:documentation>Rhonchi/Wheezing</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523027">
      <xs:annotation>
        <xs:documentation>Stridor</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523029">
      <xs:annotation>
        <xs:documentation>Wheezing-Expiratory</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3523031">
      <xs:annotation>
        <xs:documentation>Wheezing-Inspiratory</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type ChestAssessmentLocation
Namespace http://www.nemsis.org
Annotations
The location of the Chest Exam Finding.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3524001
Left - Anterior
enumeration 3524003
Left - Posterior
enumeration 3524005
Right - Anterior
enumeration 3524007
Right - Posterior
enumeration 3524009
General - Anterior
enumeration 3524011
General - Posterior
enumeration 3524013
Left - Side
enumeration 3524015
Right - Side
Used by
Source
<xs:simpleType name="ChestAssessmentLocation">
  <xs:annotation>
    <xs:documentation>The location of the Chest Exam Finding.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3524001">
      <xs:annotation>
        <xs:documentation>Left - Anterior</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3524003">
      <xs:annotation>
        <xs:documentation>Left - Posterior</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3524005">
      <xs:annotation>
        <xs:documentation>Right - Anterior</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3524007">
      <xs:annotation>
        <xs:documentation>Right - Posterior</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3524009">
      <xs:annotation>
        <xs:documentation>General - Anterior</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3524011">
      <xs:annotation>
        <xs:documentation>General - Posterior</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3524013">
      <xs:annotation>
        <xs:documentation>Left - Side</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3524015">
      <xs:annotation>
        <xs:documentation>Right - Side</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type ChestAssessment
Namespace http://www.nemsis.org
Annotations
The assessment of the patient's chest on examination
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3525001
Abrasion
enumeration 3525003
Avulsion
enumeration 3525005
Accessory Muscles Used with Breathing
enumeration 3525007
Bleeding Controlled
enumeration 3525009
Bleeding Uncontrolled
enumeration 3525011
Burn-Blistering
enumeration 3525013
Burn-Charing
enumeration 3525015
Burn-Redness
enumeration 3525017
Burn-White/Waxy
enumeration 3525019
Crush Injury
enumeration 3525021
Deformity
enumeration 3525023
Flail Segment
enumeration 3525025
Implanted Device
enumeration 3525027
Laceration
enumeration 3525029
Normal
enumeration 3525031
Not Done
enumeration 3525033
Pain
enumeration 3525035
Pain with Inspiration/Expiration
enumeration 3525037
Puncture/Stab Wound
enumeration 3525039
Retraction
enumeration 3525041
Tenderness
enumeration 3525043
Gunshot Wound
enumeration 3525045
Swelling
enumeration 3525047
Contusion
enumeration 3525049
Tenderness-General
Used by
Source
<xs:simpleType name="ChestAssessment">
  <xs:annotation>
    <xs:documentation>The assessment of the patient's chest on examination</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3525001">
      <xs:annotation>
        <xs:documentation>Abrasion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525003">
      <xs:annotation>
        <xs:documentation>Avulsion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525005">
      <xs:annotation>
        <xs:documentation>Accessory Muscles Used with Breathing</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525007">
      <xs:annotation>
        <xs:documentation>Bleeding Controlled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525009">
      <xs:annotation>
        <xs:documentation>Bleeding Uncontrolled</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525011">
      <xs:annotation>
        <xs:documentation>Burn-Blistering</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525013">
      <xs:annotation>
        <xs:documentation>Burn-Charing</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525015">
      <xs:annotation>
        <xs:documentation>Burn-Redness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525017">
      <xs:annotation>
        <xs:documentation>Burn-White/Waxy</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525019">
      <xs:annotation>
        <xs:documentation>Crush Injury</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525021">
      <xs:annotation>
        <xs:documentation>Deformity</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525023">
      <xs:annotation>
        <xs:documentation>Flail Segment</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525025">
      <xs:annotation>
        <xs:documentation>Implanted Device</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525027">
      <xs:annotation>
        <xs:documentation>Laceration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525029">
      <xs:annotation>
        <xs:documentation>Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525031">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525033">
      <xs:annotation>
        <xs:documentation>Pain</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525035">
      <xs:annotation>
        <xs:documentation>Pain with Inspiration/Expiration</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525037">
      <xs:annotation>
        <xs:documentation>Puncture/Stab Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525039">
      <xs:annotation>
        <xs:documentation>Retraction</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525041">
      <xs:annotation>
        <xs:documentation>Tenderness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525043">
      <xs:annotation>
        <xs:documentation>Gunshot Wound</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525045">
      <xs:annotation>
        <xs:documentation>Swelling</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525047">
      <xs:annotation>
        <xs:documentation>Contusion</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3525049">
      <xs:annotation>
        <xs:documentation>Tenderness-General</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type MentalStatusAssessment
Namespace http://www.nemsis.org
Annotations
The assessment of the patient's mental status
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3519001
Combative
enumeration 3519003
Confused
enumeration 3519005
Hallucinations
enumeration 3519007
Normal Baseline for Patient
enumeration 3519009
Not Done
enumeration 3519011
Oriented-Person
enumeration 3519013
Oriented-Place
enumeration 3519015
Oriented-Event
enumeration 3519017
Oriented-Time
enumeration 3519021
Unresponsive
enumeration 3519023
Agitation
enumeration 3519025
Somnolent
enumeration 3519027
Stupor
enumeration 3519029
Altered mental status, unspecified
enumeration 3519031
Developmentally Impaired
enumeration 3519033
Disorientation, unspecified
enumeration 3519035
Pharmacologically Paralyzed
enumeration 3519037
Pharmacologically Sedated
enumeration 3519039
Psychologically Impaired
enumeration 3519041
Slowness and poor responsiveness
enumeration 3519043
State of emotional shock and stress, unspecified
enumeration 3519045
Strange and inexplicable behavior
enumeration 3519047
Uncooperative
enumeration 3519049
Unspecified coma
Used by
Source
<xs:simpleType name="MentalStatusAssessment">
  <xs:annotation>
    <xs:documentation>The assessment of the patient's mental status</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3519001">
      <xs:annotation>
        <xs:documentation>Combative</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519003">
      <xs:annotation>
        <xs:documentation>Confused</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519005">
      <xs:annotation>
        <xs:documentation>Hallucinations</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519007">
      <xs:annotation>
        <xs:documentation>Normal Baseline for Patient</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519009">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519011">
      <xs:annotation>
        <xs:documentation>Oriented-Person</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519013">
      <xs:annotation>
        <xs:documentation>Oriented-Place</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519015">
      <xs:annotation>
        <xs:documentation>Oriented-Event</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519017">
      <xs:annotation>
        <xs:documentation>Oriented-Time</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519021">
      <xs:annotation>
        <xs:documentation>Unresponsive</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519023">
      <xs:annotation>
        <xs:documentation>Agitation</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519025">
      <xs:annotation>
        <xs:documentation>Somnolent</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519027">
      <xs:annotation>
        <xs:documentation>Stupor</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519029">
      <xs:annotation>
        <xs:documentation>Altered mental status, unspecified</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519031">
      <xs:annotation>
        <xs:documentation>Developmentally Impaired</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519033">
      <xs:annotation>
        <xs:documentation>Disorientation, unspecified</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519035">
      <xs:annotation>
        <xs:documentation>Pharmacologically Paralyzed</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519037">
      <xs:annotation>
        <xs:documentation>Pharmacologically Sedated</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519039">
      <xs:annotation>
        <xs:documentation>Psychologically Impaired</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519041">
      <xs:annotation>
        <xs:documentation>Slowness and poor responsiveness</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519043">
      <xs:annotation>
        <xs:documentation>State of emotional shock and stress, unspecified</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519045">
      <xs:annotation>
        <xs:documentation>Strange and inexplicable behavior</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519047">
      <xs:annotation>
        <xs:documentation>Uncooperative</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3519049">
      <xs:annotation>
        <xs:documentation>Unspecified coma</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type NeurologicalAssessment
Namespace http://www.nemsis.org
Annotations
The assessment of the patient's neurological status on examination
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3520001
Aphagia
enumeration 3520003
Aphasia
enumeration 3520005
Cerebellar Function-Abnormal
enumeration 3520007
Cerebellar Function-Normal
enumeration 3520009
Decerebrate Posturing
enumeration 3520011
Decorticate Posturing
enumeration 3520013
Gait-Abnormal
enumeration 3520015
Gait-Normal
enumeration 3520017
Hemiplegia-Left
enumeration 3520019
Hemiplegia-Right
enumeration 3520021
Normal Baseline for Patient
enumeration 3520023
Not Done
enumeration 3520026
Status Seizure
enumeration 3520055
Other Seizures
enumeration 3520027
Speech Normal
enumeration 3520029
Speech Slurring
enumeration 3520031
Strength-Asymmetric
enumeration 3520033
Strength-Normal
enumeration 3520035
Strength-Symmetric
enumeration 3520037
Tremors
enumeration 3520039
Weakness-Facial Droop-Left
enumeration 3520041
Weakness-Facial Droop-Right
enumeration 3520043
Weakness-Left Sided
enumeration 3520045
Weakness-Right Sided
enumeration 3520051
Arm Drift-Left
enumeration 3520053
Arm Drift-Right
Used by
Source
<xs:simpleType name="NeurologicalAssessment">
  <xs:annotation>
    <xs:documentation>The assessment of the patient's neurological status on examination</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3520001">
      <xs:annotation>
        <xs:documentation>Aphagia</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520003">
      <xs:annotation>
        <xs:documentation>Aphasia</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520005">
      <xs:annotation>
        <xs:documentation>Cerebellar Function-Abnormal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520007">
      <xs:annotation>
        <xs:documentation>Cerebellar Function-Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520009">
      <xs:annotation>
        <xs:documentation>Decerebrate Posturing</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520011">
      <xs:annotation>
        <xs:documentation>Decorticate Posturing</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520013">
      <xs:annotation>
        <xs:documentation>Gait-Abnormal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520015">
      <xs:annotation>
        <xs:documentation>Gait-Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520017">
      <xs:annotation>
        <xs:documentation>Hemiplegia-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520019">
      <xs:annotation>
        <xs:documentation>Hemiplegia-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520021">
      <xs:annotation>
        <xs:documentation>Normal Baseline for Patient</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520023">
      <xs:annotation>
        <xs:documentation>Not Done</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520026">
      <xs:annotation>
        <xs:documentation>Status Seizure</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520055">
      <xs:annotation>
        <xs:documentation>Other Seizures</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520027">
      <xs:annotation>
        <xs:documentation>Speech Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520029">
      <xs:annotation>
        <xs:documentation>Speech Slurring</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520031">
      <xs:annotation>
        <xs:documentation>Strength-Asymmetric</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520033">
      <xs:annotation>
        <xs:documentation>Strength-Normal</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520035">
      <xs:annotation>
        <xs:documentation>Strength-Symmetric</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520037">
      <xs:annotation>
        <xs:documentation>Tremors</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520039">
      <xs:annotation>
        <xs:documentation>Weakness-Facial Droop-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520041">
      <xs:annotation>
        <xs:documentation>Weakness-Facial Droop-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520043">
      <xs:annotation>
        <xs:documentation>Weakness-Left Sided</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520045">
      <xs:annotation>
        <xs:documentation>Weakness-Right Sided</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520051">
      <xs:annotation>
        <xs:documentation>Arm Drift-Left</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3520053">
      <xs:annotation>
        <xs:documentation>Arm Drift-Right</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Simple Type StrokeCVASymptomsResolved
Namespace http://www.nemsis.org
Annotations
Indication if the Stroke/CVA Symptoms resolved and when.
Diagram
Diagram
Type restriction of xs:string
Facets
enumeration 3521001
No
enumeration 3521003
Yes-Resolved Prior to EMS Arrival
enumeration 3521005
Yes-Resolved in EMS Presence
Used by
Element eExam/eExam.21
Source
<xs:simpleType name="StrokeCVASymptomsResolved">
  <xs:annotation>
    <xs:documentation>Indication if the Stroke/CVA Symptoms resolved and when.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="3521001">
      <xs:annotation>
        <xs:documentation>No</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3521003">
      <xs:annotation>
        <xs:documentation>Yes-Resolved Prior to EMS Arrival</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="3521005">
      <xs:annotation>
        <xs:documentation>Yes-Resolved in EMS Presence</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>
Attribute eExam / eExam.01 / @NV
Namespace No namespace
Type union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)
Properties
use optional
Used by
Element eExam/eExam.01
Source
<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.01 / @PN
Namespace No namespace
Type union of(PN.UnableToComplete)
Properties
use optional
Used by
Element eExam/eExam.01
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.UnableToComplete"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.02 / @NV
Namespace No namespace
Type union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)
Properties
use optional
Used by
Element eExam/eExam.02
Source
<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.02 / @PN
Namespace No namespace
Type union of(PN.Refused, PN.UnableToComplete)
Properties
use optional
Used by
Element eExam/eExam.02
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.Refused PN.UnableToComplete"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.04 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.04 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.05 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.05 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.06 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.06 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.07 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.07 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.09 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.09 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.AbdomenGroup / eExam.11 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.AbdomenGroup / eExam.11 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.AbdomenGroup / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.12 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.12 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.SpineGroup / eExam.14 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.SpineGroup / eExam.14 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.SpineGroup / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.ExtremityGroup / eExam.16 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.ExtremityGroup / eExam.16 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.ExtremityGroup / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.EyeGroup / eExam.18 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.EyeGroup / eExam.18 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.EyeGroup / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.LungGroup / eExam.23 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.LungGroup / eExam.23 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.LungGroup / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.ChestGroup / eExam.25 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.ChestGroup / eExam.25 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.ChestGroup / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.19 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.19 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / eExam.20 / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.AssessmentGroup / eExam.20 / @PN
Namespace No namespace
Type union of(PN.ExamFindingNotPresent)
Properties
use optional
Used by
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.ExamFindingNotPresent"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.AssessmentGroup / @CorrelationID
Namespace No namespace
Type CorrelationID
Properties
use optional
Facets
minLength 2
maxLength 255
Used by
Source
<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
Attribute eExam / eExam.21 / @PN
Namespace No namespace
Type union of(PN.UnableToComplete)
Properties
use optional
Used by
Element eExam/eExam.21
Source
<xs:attribute name="PN" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="PN.UnableToComplete"/>
  </xs:simpleType>
</xs:attribute>
Attribute eExam / eExam.21 / @NV
Namespace No namespace
Type union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)
Properties
use optional
Used by
Element eExam/eExam.21
Source
<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>
