Schema documentation for dPersonnel

Showing:

Annotations

Attributes

Diagrams

Facets

Instances

Model

Properties

Source

Used by

Included schema dPersonnel_v3.xsd

Namespace

http://www.nemsis.org

Properties

attribute form default	unqualified
element form default	qualified

Element dPersonnel / dPersonnel.PersonnelGroup

Namespace

http://www.nemsis.org

Annotations

Group tag to hold info about the personnel

Diagram

Properties

content	complex
minOccurs	0
maxOccurs	unbounded

Model

dPersonnel.NameGroup{0,1} , dPersonnel.AddressGroup{0,1} , dPersonnel.09* , dPersonnel.10* , dPersonnel.11{0,1} , dPersonnel.12{0,1} , dPersonnel.13* , dPersonnel.14{0,1} , dPersonnel.15{0,1} , dPersonnel.16* , dPersonnel.17* , dPersonnel.ImmunizationsGroup* , dPersonnel.20* , dPersonnel.21{0,1} , dPersonnel.LicensureGroup* , dPersonnel.28{0,1} , dPersonnel.29{0,1} , dPersonnel.30{0,1} , dPersonnel.31{0,1} , dPersonnel.32{0,1} , dPersonnel.33{0,1} , dPersonnel.34{0,1} , dPersonnel.35* , dPersonnel.36{0,1} , dPersonnel.37{0,1} , dPersonnel.CertificationLevelGroup*

Children

dPersonnel.09, dPersonnel.10, dPersonnel.11, dPersonnel.12, dPersonnel.13, dPersonnel.14, dPersonnel.15, dPersonnel.16, dPersonnel.17, dPersonnel.20, dPersonnel.21, dPersonnel.28, dPersonnel.29, dPersonnel.30, dPersonnel.31, dPersonnel.32, dPersonnel.33, dPersonnel.34, dPersonnel.35, dPersonnel.36, dPersonnel.37, dPersonnel.AddressGroup, dPersonnel.CertificationLevelGroup, dPersonnel.ImmunizationsGroup, dPersonnel.LicensureGroup, dPersonnel.NameGroup

Instance

<dPersonnel.PersonnelGroup CorrelationID="" UUID="" xmlns="http://www.nemsis.org">
  <dPersonnel.NameGroup>{0,1}</dPersonnel.NameGroup>
  <dPersonnel.AddressGroup>{0,1}</dPersonnel.AddressGroup>
  <dPersonnel.09 CorrelationID="" PhoneNumberType="">{0,unbounded}</dPersonnel.09>
  <dPersonnel.10 CorrelationID="" EmailAddressType="">{0,unbounded}</dPersonnel.10>
  <dPersonnel.11 NV="">{0,1}</dPersonnel.11>
  <dPersonnel.12 NV="">{0,1}</dPersonnel.12>
  <dPersonnel.13 CorrelationID="" NV="">{0,unbounded}</dPersonnel.13>
  <dPersonnel.14>{0,1}</dPersonnel.14>
  <dPersonnel.15>{0,1}</dPersonnel.15>
  <dPersonnel.16 CorrelationID="">{0,unbounded}</dPersonnel.16>
  <dPersonnel.17 CorrelationID="">{0,unbounded}</dPersonnel.17>
  <dPersonnel.ImmunizationsGroup CorrelationID="" UUID="">{0,unbounded}</dPersonnel.ImmunizationsGroup>
  <dPersonnel.20 CorrelationID="">{0,unbounded}</dPersonnel.20>
  <dPersonnel.21>{0,1}</dPersonnel.21>
  <dPersonnel.LicensureGroup CorrelationID="" UUID="">{0,unbounded}</dPersonnel.LicensureGroup>
  <dPersonnel.28>{0,1}</dPersonnel.28>
  <dPersonnel.29>{0,1}</dPersonnel.29>
  <dPersonnel.30>{0,1}</dPersonnel.30>
  <dPersonnel.31 NV="">{0,1}</dPersonnel.31>
  <dPersonnel.32 NV="">{0,1}</dPersonnel.32>
  <dPersonnel.33>{0,1}</dPersonnel.33>
  <dPersonnel.34 NV="">{0,1}</dPersonnel.34>
  <dPersonnel.35 CorrelationID="" NV="">{0,unbounded}</dPersonnel.35>
  <dPersonnel.36>{0,1}</dPersonnel.36>
  <dPersonnel.37>{0,1}</dPersonnel.37>
  <dPersonnel.CertificationLevelGroup CorrelationID="" UUID="">{0,unbounded}</dPersonnel.CertificationLevelGroup>
</dPersonnel.PersonnelGroup>

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional
UUID	UUID	required

Source

<xs:element name="dPersonnel.PersonnelGroup" id="dPersonnel.PersonnelGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group tag to hold info about the personnel</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="dPersonnel.NameGroup" id="dPersonnel.NameGroup" minOccurs="0">
        <xs:annotation>
          <xs:documentation>Group tag to hold info about the personnel's name</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="dPersonnel.01" nillable="true" id="dPersonnel.EMSPersonnelsLastName" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.01</number>
                    <name>EMS Personnel's Last Name</name>
                    <national>No</national>
                    <state>Yes</state>
                    <definition>The last name of the personnel.</definition>
                    <v2Number>D08_01</v2Number>
                    <usage>Recommended</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="PersonLastName">
                    <xs:attribute name="NV" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
            <xs:element name="dPersonnel.02" nillable="true" id="dPersonnel.EMSPersonnelsFirstName" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.02</number>
                    <name>EMS Personnel's First Name</name>
                    <national>No</national>
                    <state>Yes</state>
                    <definition>The first name of the personnel.</definition>
                    <v2Number>D08_03</v2Number>
                    <usage>Recommended</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="PersonFirstName">
                    <xs:attribute name="NV" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
            <xs:element name="dPersonnel.03" nillable="true" id="dPersonnel.EMSPersonnelsMiddleNameInitial" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.03</number>
                    <name>EMS Personnel's Middle Name/Initial</name>
                    <national>No</national>
                    <state>Yes</state>
                    <definition>The middle name or initial of the personnel.</definition>
                    <v2Number>D08_02</v2Number>
                    <usage>Recommended</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="PersonMiddleName">
                    <xs:attribute name="NV" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
          </xs:sequence>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.AddressGroup" id="dPersonnel.AddressGroup" minOccurs="0">
        <xs:annotation>
          <xs:documentation>Group tag to hold info about the personnel's mailing address</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="dPersonnel.04" id="dPersonnel.EMSPersonnelsMailingAddress" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.04</number>
                    <name>EMS Personnel's Mailing Address</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The Street or PO Box of the personnel's mailing address.</definition>
                    <v2Number>D08_04</v2Number>
                    <usage>Optional</usage>
                    <comment>For individuals living outside the USA the full address can be entered in the address line.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="StreetAddress">
                    <xs:attribute name="StreetAddress2" type="StreetAddress" use="optional"/>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
            <xs:element name="dPersonnel.05" type="CityGnisCode" id="dPersonnel.EMSPersonnelsCityofResidence" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.05</number>
                    <name>EMS Personnel's City of Residence</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The city of the personnel's mailing address.</definition>
                    <v2Number>D08_05</v2Number>
                    <usage>Optional</usage>
                    <comment>City codes are based on GNIS Feature Class. The primary Feature Class to use is "Civil" with "Populated Place" and "Military" code as additional options. <br/><br/>Definitions for each GNIS City Feature Class can be found on the GNIS Codes website. <br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm</a></comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="dPersonnel.06" type="ANSIStateCode" id="dPersonnel.EMSPersonnelsState" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.06</number>
                    <name>EMS Personnel's State</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The state of the personnel's mailing address.</definition>
                    <v2Number>D08_06</v2Number>
                    <usage>Optional</usage>
                    <comment>Based on ANSI Code.<br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm </a></comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="dPersonnel.07" type="ZIP" id="dPersonnel.EMSPersonnelsZIPCode" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.07</number>
                    <name>EMS Personnel's ZIP Code</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The ZIP code of the personnel's mailing address.</definition>
                    <v2Number>D08_07</v2Number>
                    <usage>Optional</usage>
                    <comment>Zip Codes Product Website: <a href="https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/" target="_blank">https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/</a> <br/>Product: USA - 5-digit ZIP Code Database, Commercial Edition</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="dPersonnel.08" type="ANSICountryCodesCAMXUS" id="dPersonnel.EMSPersonnelsCountry" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.08</number>
                    <name>EMS Personnel's Country</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The country of the personnel mailing address.</definition>
                    <usage>Optional</usage>
                    <comment>Based on ANSI Code.<br/><br/>ANSI Country Codes (ISO 3166) Website: <a href="https://www.iso.org/iso-3166-country-codes.html" target="_blank">https://www.iso.org/iso-3166-country-codes.html</a></comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
          </xs:sequence>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.09" id="dPersonnel.EMSPersonnelsPhoneNumber" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.09</number>
              <name>EMS Personnel's Phone Number</name>
              <national>No</national>
              <state>No</state>
              <definition>The phone number for the personnel.</definition>
              <v2Number>D08_08</v2Number>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="PhoneNumber">
              <xs:attribute name="PhoneNumberType" type="PhoneNumberType" use="optional"/>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.10" id="dPersonnel.EMSPersonnelsEmailAddress" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.10</number>
              <name>EMS Personnel's Email Address</name>
              <national>No</national>
              <state>No</state>
              <definition>The primary email address of the personnel.</definition>
              <v2Number>D08_10</v2Number>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="EmailAddress">
              <xs:attribute name="EmailAddressType" type="EmailAddressType" use="optional"/>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.11" nillable="true" id="dPersonnel.EMSPersonnelsDateofBirth" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.11</number>
              <name>EMS Personnel's Date of Birth</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The personnel's date of birth.</definition>
              <v2Number>D08_11</v2Number>
              <usage>Recommended</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="DateType">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.12" nillable="true" id="dPersonnel.EMSPersonnelsGender" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.12</number>
              <name>EMS Personnel's Gender</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The personnel's gender.</definition>
              <v2Number>D08_12</v2Number>
              <usage>Recommended</usage>
              <comment>Code list referenced from: <a href="https://www.healthit.gov/isa/sex-birth-sexual-orientation-and-gender-identity" target="_blank">https://www.healthit.gov/isa/sex-birth-sexual-orientation-and-gender-identity</a></comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="Gender">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.13" nillable="true" id="dPersonnel.EMSPersonnelsRace" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.13</number>
              <name>EMS Personnel's Race</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The personnel's race as defined by the OMB (US Office of Management and Budget).</definition>
              <v2Number>D08_13</v2Number>
              <usage>Recommended</usage>
              <comment>OMB requirements are provided at: <a href="https://www.federalregister.gov/d/2024-06469" target="_blank">https://www.federalregister.gov/d/2024-06469</a>. A single multiple choice question methodology is being implemented to improve the completion of ethnicity information. Ethnicity (Version 2.1.1: D08_14) has been merged with this data element and retired.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="DemographicRace">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.14" type="ANSICountryCode" id="dPersonnel.EMSPersonnelsCitizenship" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.14</number>
              <name>EMS Personnel's Citizenship</name>
              <national>No</national>
              <state>No</state>
              <definition>The documentation of the personnel's citizenship.</definition>
              <usage>Optional</usage>
              <comment>Website: <a href="https://www.iso.org/iso-3166-country-codes.html" target="_blank">https://www.iso.org/iso-3166-country-codes.html</a></comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.15" type="PersonnelHighestEducationalDegree" id="dPersonnel.EMSPersonnelsHighestEducationalDegree" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.15</number>
              <name>EMS Personnel's Highest Educational Degree</name>
              <national>No</national>
              <state>No</state>
              <definition>The highest educational degree completed by the personnel.</definition>
              <usage>Optional</usage>
              <comment>Based on Census 2000 Educational Attainment Question.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.16" id="dPersonnel.EMSPersonnelsDegreeSubjectFieldofStudy" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.16</number>
              <name>EMS Personnel's Degree Subject/Field of Study</name>
              <national>No</national>
              <state>No</state>
              <definition>The area of the personnel's post high-school (post-secondary) degree.</definition>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="PersonnelDegreeFieldofStudy">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.17" id="dPersonnel.EMSPersonnelsMotorVehicleLicenseType" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.17</number>
              <name>EMS Personnel's Motor Vehicle License Type</name>
              <national>No</national>
              <state>No</state>
              <definition>The type of motor vehicle license (i.e. Class A, B, Pilot, etc.) of the EMS personnel.</definition>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="PersonnelVehicleLicenseType">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.ImmunizationsGroup" id="dPersonnel.PersonnelImmunizationsGroup" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>Group Tag to hold Immunization type and date</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="dPersonnel.18" type="ImmunizationType" id="dPersonnel.EMSPersonnelsImmunizationStatus" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.18</number>
                    <name>EMS Personnel's Immunization Status</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The type of immunization status.</definition>
                    <usage>Optional</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="dPersonnel.19" type="Year" id="dPersonnel.EMSPersonnelsImmunizationYear" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.19</number>
                    <name>EMS Personnel's Immunization Year</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The year associated with each immunization type.</definition>
                    <usage>Optional</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
          </xs:sequence>
          <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
          <xs:attribute name="UUID" type="UUID" use="required"/>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.20" id="dPersonnel.EMSPersonnelsForeignLanguageAbility" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.20</number>
              <name>EMS Personnel's Foreign Language Ability</name>
              <national>No</national>
              <state>No</state>
              <definition>The languages spoken (other than English) by the personnel with at least an elementary level of proficiency.</definition>
              <usage>Optional</usage>
              <v3Changes>Added to better describe the EMS workforce.</v3Changes>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="PersonnelForeignLanguageAbility">
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.21" type="PersonnelAgencyIDNumber" id="dPersonnel.EMSPersonnelsAgencyIDNumber" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.21</number>
              <name>EMS Personnel's Agency ID Number</name>
              <national>No</national>
              <state>No</state>
              <definition>The local agency ID number for the personnel.</definition>
              <v2Number>D07_01</v2Number>
              <usage>Optional</usage>
              <comment>This is a local ID and not the ID associated with the state credential. This may be the same as the state credential ID depending on the state and local implementation. This should be a unique number and not reused.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.LicensureGroup" id="dPersonnel.LicensureGroup" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>Group to hold the licensure information</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="dPersonnel.22" nillable="true" id="dPersonnel.EMSPersonnelsStateofLicensure" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.22</number>
                    <name>EMS Personnel's State of Licensure</name>
                    <national>No</national>
                    <state>Yes</state>
                    <definition>The state of the certification/licensure ID number assigned to the personnel member.</definition>
                    <usage>Recommended</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="ANSIStateCode">
                    <xs:attribute name="NV" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
            <xs:element name="dPersonnel.23" nillable="true" id="dPersonnel.EMSPersonnelsStateLicensureIDNumber" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.23</number>
                    <name>EMS Personnel's State's Licensure ID Number</name>
                    <national>No</national>
                    <state>Yes</state>
                    <definition>The state's licensure/certification ID number for the personnel.</definition>
                    <v2Number>D07_02</v2Number>
                    <usage>Recommended</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="StateLicensureID">
                    <xs:attribute name="NV" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
            <xs:element name="dPersonnel.24" nillable="true" id="dPersonnel.EMSPersonnelsStateEMSCertificationLicensureLevel" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.24</number>
                    <name>EMS Personnel's State EMS Certification Licensure Level</name>
                    <national>No</national>
                    <state>Yes</state>
                    <definition>The personnel's state EMS certification level.</definition>
                    <v2Number>D08_15</v2Number>
                    <usage>Recommended</usage>
                    <comment>The category Emergency Medical Technician - Intermediate includes EMS professionals with an "85" or "99" certification level.<br/><br/>Some listed health care providers may not have an EMS certification/licensure number, however their level should be indicated from the list above and the state licensure number should be indicated in dPersonnel.23 - EMS Personnel's State's Licensure ID Number.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
              <xs:complexType>
                <xs:simpleContent>
                  <xs:extension base="MemberLevel">
                    <xs:attribute name="NV" use="optional">
                      <xs:simpleType>
                        <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                      </xs:simpleType>
                    </xs:attribute>
                  </xs:extension>
                </xs:simpleContent>
              </xs:complexType>
            </xs:element>
            <xs:element name="dPersonnel.25" type="DateType" id="dPersonnel.EMSPersonnelsStateEMSCurrentCertificationDate" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.25</number>
                    <name>EMS Personnel's State EMS Current Certification Date</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The date of the personnel's current EMS certification/licensure.</definition>
                    <v2Number>D08_17</v2Number>
                    <usage>Optional</usage>
                    <comment>Clarified as the current certification/licensure.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="dPersonnel.26" type="DateType" id="dPersonnel.EMSPersonnelsInitialStateLicensureIssueDate" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.26</number>
                    <name>EMS Personnel's Initial State's Licensure Issue Date</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The date on which the EMS personnel's state's EMS certification/licensure was originally issued. This is the date of the first certification/licensure for the EMS level.</definition>
                    <v2Number>D08_18</v2Number>
                    <usage>Optional</usage>
                    <comment>Clarified as the FIRST (original) certification/licensure date.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="dPersonnel.27" type="DateType" id="dPersonnel.EMSPersonnelsCurrentStateLicensureExpirationDate" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.27</number>
                    <name>EMS Personnel's Current State's Licensure Expiration Date</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The date on which the EMS personnel's (highest) state EMS certification/licensure expires.</definition>
                    <usage>Optional</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
          </xs:sequence>
          <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
          <xs:attribute name="UUID" type="UUID" use="required"/>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.28" type="NationalRegistryNumber" id="dPersonnel.NationalRegistryNumber" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.28</number>
              <name>EMS Personnel's National Registry Number</name>
              <national>No</national>
              <state>No</state>
              <definition>The National Registry number associated with the level of certification/licensure obtained through NREMT.</definition>
              <usage>Optional</usage>
              <performanceMeasures/>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.29" type="NationalRegistryCertificationLevel" id="dPersonnel.NationalRegistryCertificationLevel" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.29</number>
              <name>EMS Personnel's National Registry Certification Level</name>
              <national>No</national>
              <state>No</state>
              <definition>The level of the current National Registry of Emergency Medical Technicians (NREMT) certification.</definition>
              <usage>Optional</usage>
              <performanceMeasures/>
              <comment>The category EMT-Intermediate includes EMS professionals with an "85" or "99" certification level.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.30" type="DateType" id="dPersonnel.PersonnelsCurrentNationalCertificationExpirationDate" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.30</number>
              <name>EMS Personnel's Current National Registry Expiration Date</name>
              <national>No</national>
              <state>No</state>
              <definition>The date on which the EMS Personnel's National Registry of EMTs certification/licensure expires.</definition>
              <usage>Optional</usage>
              <performanceMeasures/>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.31" nillable="true" id="dPersonnel.EMSPersonnelsEmploymentStatus" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.31</number>
              <name>EMS Personnel's Employment Status</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The personnel's primary employment status for this agency.</definition>
              <v2Number>D07_03</v2Number>
              <usage>Recommended</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="EmploymentStatus">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.32" nillable="true" id="dPersonnel.EMSPersonnelsEmploymentStatusDate" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.32</number>
              <name>EMS Personnel's Employment Status Date</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The personnel's employment status date.</definition>
              <v2Number>D07_04</v2Number>
              <usage>Recommended</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="DateType">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.33" type="DateType" id="dPersonnel.EMSPersonnelsHireDate" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.33</number>
              <name>EMS Personnel's Hire Date</name>
              <national>No</national>
              <state>No</state>
              <definition>The date the employee was hired by the EMS agency for this current job.</definition>
              <usage>Optional</usage>
              <comment>This is intended to collect information based on the current employment/job. If the EMS personnel has a come and go status, this should reflect the most recent employment/job.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.34" nillable="true" id="dPersonnel.EMSPersonnelsPrimaryEMSJobRole" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.34</number>
              <name>EMS Personnel's Primary EMS Job Role</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The individuals primary/main EMS role at the EMS agency. This is the function which is performed the majority of the time for the EMS personnel.</definition>
              <usage>Recommended</usage>
              <comment>This is a single choice data element which should reflect the EMS Personnel's primary/main job role for which he/she functions. It is understood that most EMS personnel perform more than one role as a part of their position. Other roles should be documented in dPersonnel.35 (EMS Personnel's Other Job Responsibilities).</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="JobResponsibilities">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.35" nillable="true" id="dPersonnel.EMSPersonnelsOtherJobResponsibilities" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.35</number>
              <name>EMS Personnel's Other Job Responsibilities</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The EMS personnel's other job responsibilities at the agency beyond their primary role documented in dPersonnel.34 (EMS Personnel's Primary EMS Job Role).</definition>
              <usage>Recommended</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="JobResponsibilities">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.36" type="TotalService" id="dPersonnel.EMSPersonnelsTotalLengthofServiceinYears" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.36</number>
              <name>EMS Personnel's Total Length of Service in Years</name>
              <national>No</national>
              <state>No</state>
              <definition>The personnel's total length of EMS service at any level (years).</definition>
              <v2Number>D08_19</v2Number>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.37" type="DateType" id="dPersonnel.EMSPersonnelsDateLengthofServiceDocumented" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.37</number>
              <name>EMS Personnel's Date Length of Service Documented</name>
              <national>No</national>
              <state>No</state>
              <definition>The date which the length of EMS service was documented.</definition>
              <v2Number>D08_20</v2Number>
              <usage>Optional</usage>
              <comment>Associated with dPersonnel.37 (EMS Personnel's Total Length of Service in Years).</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.CertificationLevelGroup" id="dPersonnel.CertificationLevelGroup" minOccurs="0" maxOccurs="unbounded">
        <xs:annotation>
          <xs:documentation>Group to hold the certification information</xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:sequence>
            <xs:element name="dPersonnel.38" type="MemberLevel" id="dPersonnel.EMSPersonnelsPracticeLevel" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.38</number>
                    <name>EMS Personnel's Practice Level</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The EMS certification level at which the individual is providing patient care services for the EMS agency.</definition>
                    <v2Number>D07_05</v2Number>
                    <usage>Optional</usage>
                    <comment>The category EMT-Intermediate includes EMS professionals with an "85" or "99" certification level.</comment>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
            <xs:element name="dPersonnel.39" type="DateType" id="dPersonnel.DateofPersonnelsCertificationorLicensureforAgency" minOccurs="0">
              <xs:annotation>
                <xs:documentation>
                  <nemsisTacDoc>
                    <number>dPersonnel.39</number>
                    <name>Date of Personnel's Certification or Licensure for Agency</name>
                    <national>No</national>
                    <state>No</state>
                    <definition>The date that the Certification/Licensure was achieved for the local EMS agency.</definition>
                    <v2Number>D07_06</v2Number>
                    <usage>Optional</usage>
                  </nemsisTacDoc>
                </xs:documentation>
              </xs:annotation>
            </xs:element>
          </xs:sequence>
          <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
          <xs:attribute name="UUID" type="UUID" use="required"/>
        </xs:complexType>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
    <xs:attribute name="UUID" type="UUID" use="required"/>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.NameGroup

Namespace

http://www.nemsis.org

Annotations

Group tag to hold info about the personnel's name

Diagram

Properties

content	complex
minOccurs	0

Model

dPersonnel.01{0,1} , dPersonnel.02{0,1} , dPersonnel.03{0,1}

Children

dPersonnel.01, dPersonnel.02, dPersonnel.03

Instance

<dPersonnel.NameGroup xmlns="http://www.nemsis.org">
  <dPersonnel.01 NV="">{0,1}</dPersonnel.01>
  <dPersonnel.02 NV="">{0,1}</dPersonnel.02>
  <dPersonnel.03 NV="">{0,1}</dPersonnel.03>
</dPersonnel.NameGroup>

Source

<xs:element name="dPersonnel.NameGroup" id="dPersonnel.NameGroup" minOccurs="0">
  <xs:annotation>
    <xs:documentation>Group tag to hold info about the personnel's name</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="dPersonnel.01" nillable="true" id="dPersonnel.EMSPersonnelsLastName" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.01</number>
              <name>EMS Personnel's Last Name</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The last name of the personnel.</definition>
              <v2Number>D08_01</v2Number>
              <usage>Recommended</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="PersonLastName">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.02" nillable="true" id="dPersonnel.EMSPersonnelsFirstName" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.02</number>
              <name>EMS Personnel's First Name</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The first name of the personnel.</definition>
              <v2Number>D08_03</v2Number>
              <usage>Recommended</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="PersonFirstName">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.03" nillable="true" id="dPersonnel.EMSPersonnelsMiddleNameInitial" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.03</number>
              <name>EMS Personnel's Middle Name/Initial</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The middle name or initial of the personnel.</definition>
              <v2Number>D08_02</v2Number>
              <usage>Recommended</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="PersonMiddleName">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
    </xs:sequence>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.NameGroup / dPersonnel.01

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.01</number>
  <name>EMS Personnel's Last Name</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The last name of the personnel.</definition>
  <v2Number>D08_01</v2Number>
  <usage>Recommended</usage>
</nemsisTacDoc>

Diagram

Type

extension of PersonLastName

Type hierarchy

xs:string
- PersonLastName

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.01" nillable="true" id="dPersonnel.EMSPersonnelsLastName" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.01</number>
        <name>EMS Personnel's Last Name</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The last name of the personnel.</definition>
        <v2Number>D08_01</v2Number>
        <usage>Recommended</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="PersonLastName">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.NameGroup / dPersonnel.02

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.02</number>
  <name>EMS Personnel's First Name</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The first name of the personnel.</definition>
  <v2Number>D08_03</v2Number>
  <usage>Recommended</usage>
</nemsisTacDoc>

Diagram

Type

extension of PersonFirstName

Type hierarchy

xs:string
- PersonFirstName

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.02" nillable="true" id="dPersonnel.EMSPersonnelsFirstName" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.02</number>
        <name>EMS Personnel's First Name</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The first name of the personnel.</definition>
        <v2Number>D08_03</v2Number>
        <usage>Recommended</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="PersonFirstName">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.NameGroup / dPersonnel.03

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.03</number>
  <name>EMS Personnel's Middle Name/Initial</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The middle name or initial of the personnel.</definition>
  <v2Number>D08_02</v2Number>
  <usage>Recommended</usage>
</nemsisTacDoc>

Diagram

Type

extension of PersonMiddleName

Type hierarchy

xs:string
- PersonMiddleName

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.03" nillable="true" id="dPersonnel.EMSPersonnelsMiddleNameInitial" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.03</number>
        <name>EMS Personnel's Middle Name/Initial</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The middle name or initial of the personnel.</definition>
        <v2Number>D08_02</v2Number>
        <usage>Recommended</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="PersonMiddleName">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.AddressGroup

Namespace

http://www.nemsis.org

Annotations

Group tag to hold info about the personnel's mailing address

Diagram

Properties

content	complex
minOccurs	0

Model

dPersonnel.04{0,1} , dPersonnel.05{0,1} , dPersonnel.06{0,1} , dPersonnel.07{0,1} , dPersonnel.08{0,1}

Children

dPersonnel.04, dPersonnel.05, dPersonnel.06, dPersonnel.07, dPersonnel.08

Instance

<dPersonnel.AddressGroup xmlns="http://www.nemsis.org">
  <dPersonnel.04 StreetAddress2="">{0,1}</dPersonnel.04>
  <dPersonnel.05>{0,1}</dPersonnel.05>
  <dPersonnel.06>{0,1}</dPersonnel.06>
  <dPersonnel.07>{0,1}</dPersonnel.07>
  <dPersonnel.08>{0,1}</dPersonnel.08>
</dPersonnel.AddressGroup>

Source

<xs:element name="dPersonnel.AddressGroup" id="dPersonnel.AddressGroup" minOccurs="0">
  <xs:annotation>
    <xs:documentation>Group tag to hold info about the personnel's mailing address</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="dPersonnel.04" id="dPersonnel.EMSPersonnelsMailingAddress" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.04</number>
              <name>EMS Personnel's Mailing Address</name>
              <national>No</national>
              <state>No</state>
              <definition>The Street or PO Box of the personnel's mailing address.</definition>
              <v2Number>D08_04</v2Number>
              <usage>Optional</usage>
              <comment>For individuals living outside the USA the full address can be entered in the address line.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="StreetAddress">
              <xs:attribute name="StreetAddress2" type="StreetAddress" use="optional"/>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.05" type="CityGnisCode" id="dPersonnel.EMSPersonnelsCityofResidence" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.05</number>
              <name>EMS Personnel's City of Residence</name>
              <national>No</national>
              <state>No</state>
              <definition>The city of the personnel's mailing address.</definition>
              <v2Number>D08_05</v2Number>
              <usage>Optional</usage>
              <comment>City codes are based on GNIS Feature Class. The primary Feature Class to use is "Civil" with "Populated Place" and "Military" code as additional options. <br/><br/>Definitions for each GNIS City Feature Class can be found on the GNIS Codes website. <br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm</a></comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.06" type="ANSIStateCode" id="dPersonnel.EMSPersonnelsState" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.06</number>
              <name>EMS Personnel's State</name>
              <national>No</national>
              <state>No</state>
              <definition>The state of the personnel's mailing address.</definition>
              <v2Number>D08_06</v2Number>
              <usage>Optional</usage>
              <comment>Based on ANSI Code.<br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm </a></comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.07" type="ZIP" id="dPersonnel.EMSPersonnelsZIPCode" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.07</number>
              <name>EMS Personnel's ZIP Code</name>
              <national>No</national>
              <state>No</state>
              <definition>The ZIP code of the personnel's mailing address.</definition>
              <v2Number>D08_07</v2Number>
              <usage>Optional</usage>
              <comment>Zip Codes Product Website: <a href="https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/" target="_blank">https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/</a> <br/>Product: USA - 5-digit ZIP Code Database, Commercial Edition</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.08" type="ANSICountryCodesCAMXUS" id="dPersonnel.EMSPersonnelsCountry" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.08</number>
              <name>EMS Personnel's Country</name>
              <national>No</national>
              <state>No</state>
              <definition>The country of the personnel mailing address.</definition>
              <usage>Optional</usage>
              <comment>Based on ANSI Code.<br/><br/>ANSI Country Codes (ISO 3166) Website: <a href="https://www.iso.org/iso-3166-country-codes.html" target="_blank">https://www.iso.org/iso-3166-country-codes.html</a></comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
    </xs:sequence>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.AddressGroup / dPersonnel.04

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.04</number>
  <name>EMS Personnel's Mailing Address</name>
  <national>No</national>
  <state>No</state>
  <definition>The Street or PO Box of the personnel's mailing address.</definition>
  <v2Number>D08_04</v2Number>
  <usage>Optional</usage>
  <comment>For individuals living outside the USA the full address can be entered in the address line.</comment>
</nemsisTacDoc>

Diagram

Type

extension of StreetAddress

Type hierarchy

xs:string
- StreetAddress

Properties

content	complex
minOccurs	0

Attributes

QName	Type	Use
StreetAddress2	StreetAddress	optional

Source

<xs:element name="dPersonnel.04" id="dPersonnel.EMSPersonnelsMailingAddress" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.04</number>
        <name>EMS Personnel's Mailing Address</name>
        <national>No</national>
        <state>No</state>
        <definition>The Street or PO Box of the personnel's mailing address.</definition>
        <v2Number>D08_04</v2Number>
        <usage>Optional</usage>
        <comment>For individuals living outside the USA the full address can be entered in the address line.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="StreetAddress">
        <xs:attribute name="StreetAddress2" type="StreetAddress" use="optional"/>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.AddressGroup / dPersonnel.05

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.05</number>
  <name>EMS Personnel's City of Residence</name>
  <national>No</national>
  <state>No</state>
  <definition>The city of the personnel's mailing address.</definition>
  <v2Number>D08_05</v2Number>
  <usage>Optional</usage>
  <comment>City codes are based on GNIS Feature Class. The primary Feature Class to use is "Civil" with "Populated Place" and "Military" code as additional options. <br/><br/>Definitions for each GNIS City Feature Class can be found on the GNIS Codes website. <br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm</a></comment>
</nemsisTacDoc>

Diagram

Type

CityGnisCode

Properties

content	simple
minOccurs	0

Source

<xs:element name="dPersonnel.05" type="CityGnisCode" id="dPersonnel.EMSPersonnelsCityofResidence" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.05</number>
        <name>EMS Personnel's City of Residence</name>
        <national>No</national>
        <state>No</state>
        <definition>The city of the personnel's mailing address.</definition>
        <v2Number>D08_05</v2Number>
        <usage>Optional</usage>
        <comment>City codes are based on GNIS Feature Class. The primary Feature Class to use is "Civil" with "Populated Place" and "Military" code as additional options. <br/><br/>Definitions for each GNIS City Feature Class can be found on the GNIS Codes website. <br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm</a></comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.AddressGroup / dPersonnel.06

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.06</number>
  <name>EMS Personnel's State</name>
  <national>No</national>
  <state>No</state>
  <definition>The state of the personnel's mailing address.</definition>
  <v2Number>D08_06</v2Number>
  <usage>Optional</usage>
  <comment>Based on ANSI Code.<br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm </a></comment>
</nemsisTacDoc>

Diagram

Type

ANSIStateCode

Properties

content	simple
minOccurs	0

Facets

pattern

[0-9]{2}

Source

<xs:element name="dPersonnel.06" type="ANSIStateCode" id="dPersonnel.EMSPersonnelsState" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.06</number>
        <name>EMS Personnel's State</name>
        <national>No</national>
        <state>No</state>
        <definition>The state of the personnel's mailing address.</definition>
        <v2Number>D08_06</v2Number>
        <usage>Optional</usage>
        <comment>Based on ANSI Code.<br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm </a></comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.AddressGroup / dPersonnel.07

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.07</number>
  <name>EMS Personnel's ZIP Code</name>
  <national>No</national>
  <state>No</state>
  <definition>The ZIP code of the personnel's mailing address.</definition>
  <v2Number>D08_07</v2Number>
  <usage>Optional</usage>
  <comment>Zip Codes Product Website: <a href="https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/" target="_blank">https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/</a> <br/>Product: USA - 5-digit ZIP Code Database, Commercial Edition</comment>
</nemsisTacDoc>

Diagram

Type

ZIP

Properties

content	simple
minOccurs	0

Facets

pattern

[0-9]{5}|[0-9]{5}-[0-9]{4}|[0-9]{5}-[0-9]{5}|[A-Z][0-9][A-Z] [0-9][A-Z][0-9]

Source

<xs:element name="dPersonnel.07" type="ZIP" id="dPersonnel.EMSPersonnelsZIPCode" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.07</number>
        <name>EMS Personnel's ZIP Code</name>
        <national>No</national>
        <state>No</state>
        <definition>The ZIP code of the personnel's mailing address.</definition>
        <v2Number>D08_07</v2Number>
        <usage>Optional</usage>
        <comment>Zip Codes Product Website: <a href="https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/" target="_blank">https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/</a> <br/>Product: USA - 5-digit ZIP Code Database, Commercial Edition</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.AddressGroup / dPersonnel.08

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.08</number>
  <name>EMS Personnel's Country</name>
  <national>No</national>
  <state>No</state>
  <definition>The country of the personnel mailing address.</definition>
  <usage>Optional</usage>
  <comment>Based on ANSI Code.<br/><br/>ANSI Country Codes (ISO 3166) Website: <a href="https://www.iso.org/iso-3166-country-codes.html" target="_blank">https://www.iso.org/iso-3166-country-codes.html</a></comment>
</nemsisTacDoc>

Diagram

Type

ANSICountryCodesCAMXUS

Properties

content	simple
minOccurs	0

Facets

enumeration

Canada

enumeration

Mexico

enumeration

United States

Source

<xs:element name="dPersonnel.08" type="ANSICountryCodesCAMXUS" id="dPersonnel.EMSPersonnelsCountry" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.08</number>
        <name>EMS Personnel's Country</name>
        <national>No</national>
        <state>No</state>
        <definition>The country of the personnel mailing address.</definition>
        <usage>Optional</usage>
        <comment>Based on ANSI Code.<br/><br/>ANSI Country Codes (ISO 3166) Website: <a href="https://www.iso.org/iso-3166-country-codes.html" target="_blank">https://www.iso.org/iso-3166-country-codes.html</a></comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.09

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.09</number>
  <name>EMS Personnel's Phone Number</name>
  <national>No</national>
  <state>No</state>
  <definition>The phone number for the personnel.</definition>
  <v2Number>D08_08</v2Number>
  <usage>Optional</usage>
</nemsisTacDoc>

Diagram

Type

extension of PhoneNumber

Type hierarchy

xs:string
- PhoneNumber

Properties

content	complex
minOccurs	0
maxOccurs	unbounded

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional
PhoneNumberType	PhoneNumberType	optional

Source

<xs:element name="dPersonnel.09" id="dPersonnel.EMSPersonnelsPhoneNumber" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.09</number>
        <name>EMS Personnel's Phone Number</name>
        <national>No</national>
        <state>No</state>
        <definition>The phone number for the personnel.</definition>
        <v2Number>D08_08</v2Number>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="PhoneNumber">
        <xs:attribute name="PhoneNumberType" type="PhoneNumberType" use="optional"/>
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.10

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.10</number>
  <name>EMS Personnel's Email Address</name>
  <national>No</national>
  <state>No</state>
  <definition>The primary email address of the personnel.</definition>
  <v2Number>D08_10</v2Number>
  <usage>Optional</usage>
</nemsisTacDoc>

Diagram

Type

extension of EmailAddress

Type hierarchy

xs:string
- EmailAddress

Properties

content	complex
minOccurs	0
maxOccurs	unbounded

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional
EmailAddressType	EmailAddressType	optional

Source

<xs:element name="dPersonnel.10" id="dPersonnel.EMSPersonnelsEmailAddress" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.10</number>
        <name>EMS Personnel's Email Address</name>
        <national>No</national>
        <state>No</state>
        <definition>The primary email address of the personnel.</definition>
        <v2Number>D08_10</v2Number>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="EmailAddress">
        <xs:attribute name="EmailAddressType" type="EmailAddressType" use="optional"/>
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.11

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.11</number>
  <name>EMS Personnel's Date of Birth</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The personnel's date of birth.</definition>
  <v2Number>D08_11</v2Number>
  <usage>Recommended</usage>
</nemsisTacDoc>

Diagram

Type

extension of DateType

Type hierarchy

xs:date
- DateType

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.11" nillable="true" id="dPersonnel.EMSPersonnelsDateofBirth" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.11</number>
        <name>EMS Personnel's Date of Birth</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The personnel's date of birth.</definition>
        <v2Number>D08_11</v2Number>
        <usage>Recommended</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="DateType">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.12

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.12</number>
  <name>EMS Personnel's Gender</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The personnel's gender.</definition>
  <v2Number>D08_12</v2Number>
  <usage>Recommended</usage>
  <comment>Code list referenced from: <a href="https://www.healthit.gov/isa/sex-birth-sexual-orientation-and-gender-identity" target="_blank">https://www.healthit.gov/isa/sex-birth-sexual-orientation-and-gender-identity</a></comment>
</nemsisTacDoc>

Diagram

Type

extension of Gender

Type hierarchy

xs:string
- Gender

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.12" nillable="true" id="dPersonnel.EMSPersonnelsGender" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.12</number>
        <name>EMS Personnel's Gender</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The personnel's gender.</definition>
        <v2Number>D08_12</v2Number>
        <usage>Recommended</usage>
        <comment>Code list referenced from: <a href="https://www.healthit.gov/isa/sex-birth-sexual-orientation-and-gender-identity" target="_blank">https://www.healthit.gov/isa/sex-birth-sexual-orientation-and-gender-identity</a></comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="Gender">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.13

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.13</number>
  <name>EMS Personnel's Race</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The personnel's race as defined by the OMB (US Office of Management and Budget).</definition>
  <v2Number>D08_13</v2Number>
  <usage>Recommended</usage>
  <comment>OMB requirements are provided at: <a href="https://www.federalregister.gov/d/2024-06469" target="_blank">https://www.federalregister.gov/d/2024-06469</a>. A single multiple choice question methodology is being implemented to improve the completion of ethnicity information. Ethnicity (Version 2.1.1: D08_14) has been merged with this data element and retired.</comment>
</nemsisTacDoc>

Diagram

Type

extension of DemographicRace

Type hierarchy

xs:string
- DemographicRace

Properties

content	complex
minOccurs	0
maxOccurs	unbounded
nillable	true

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.13" nillable="true" id="dPersonnel.EMSPersonnelsRace" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.13</number>
        <name>EMS Personnel's Race</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The personnel's race as defined by the OMB (US Office of Management and Budget).</definition>
        <v2Number>D08_13</v2Number>
        <usage>Recommended</usage>
        <comment>OMB requirements are provided at: <a href="https://www.federalregister.gov/d/2024-06469" target="_blank">https://www.federalregister.gov/d/2024-06469</a>. A single multiple choice question methodology is being implemented to improve the completion of ethnicity information. Ethnicity (Version 2.1.1: D08_14) has been merged with this data element and retired.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="DemographicRace">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.14

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.14</number>
  <name>EMS Personnel's Citizenship</name>
  <national>No</national>
  <state>No</state>
  <definition>The documentation of the personnel's citizenship.</definition>
  <usage>Optional</usage>
  <comment>Website: <a href="https://www.iso.org/iso-3166-country-codes.html" target="_blank">https://www.iso.org/iso-3166-country-codes.html</a></comment>
</nemsisTacDoc>

Diagram

Type

ANSICountryCode

Properties

content	simple
minOccurs	0

Facets

length

Source

<xs:element name="dPersonnel.14" type="ANSICountryCode" id="dPersonnel.EMSPersonnelsCitizenship" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.14</number>
        <name>EMS Personnel's Citizenship</name>
        <national>No</national>
        <state>No</state>
        <definition>The documentation of the personnel's citizenship.</definition>
        <usage>Optional</usage>
        <comment>Website: <a href="https://www.iso.org/iso-3166-country-codes.html" target="_blank">https://www.iso.org/iso-3166-country-codes.html</a></comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.15

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.15</number>
  <name>EMS Personnel's Highest Educational Degree</name>
  <national>No</national>
  <state>No</state>
  <definition>The highest educational degree completed by the personnel.</definition>
  <usage>Optional</usage>
  <comment>Based on Census 2000 Educational Attainment Question.</comment>
</nemsisTacDoc>

Diagram

Type

PersonnelHighestEducationalDegree

Properties

content	simple
minOccurs	0

Facets

enumeration

1515001

No Schooling Completed

enumeration

1515003

Nursery School to 4th Grade

enumeration

1515005

5th Grade or 6th Grade

enumeration

1515007

7th Grade or 8th Grade

enumeration

1515009

9th Grade

enumeration

1515011

10th Grade

enumeration

1515013

11th Grade

enumeration

1515015

12th Grade, No Diploma

enumeration

1515017

High School Graduate-Diploma or the Equivalent (GED)

enumeration

1515019

Some College Credit, but Less than 1 Year

enumeration

1515021

1 or More Years of College, No Degree

enumeration

1515023

Associate Degree

enumeration

1515025

Bachelor's Degree

enumeration

1515027

Master's Degree

enumeration

1515029

Professional Degree (i.e. MD, DDS, DVM, LLB, JD)

enumeration

1515031

Doctorate Degree (i.e. PhD, EdD)

Source

<xs:element name="dPersonnel.15" type="PersonnelHighestEducationalDegree" id="dPersonnel.EMSPersonnelsHighestEducationalDegree" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.15</number>
        <name>EMS Personnel's Highest Educational Degree</name>
        <national>No</national>
        <state>No</state>
        <definition>The highest educational degree completed by the personnel.</definition>
        <usage>Optional</usage>
        <comment>Based on Census 2000 Educational Attainment Question.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.16

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.16</number>
  <name>EMS Personnel's Degree Subject/Field of Study</name>
  <national>No</national>
  <state>No</state>
  <definition>The area of the personnel's post high-school (post-secondary) degree.</definition>
  <usage>Optional</usage>
</nemsisTacDoc>

Diagram

Type

extension of PersonnelDegreeFieldofStudy

Type hierarchy

xs:string
- PersonnelDegreeFieldofStudy

Properties

content	complex
minOccurs	0
maxOccurs	unbounded

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional

Source

<xs:element name="dPersonnel.16" id="dPersonnel.EMSPersonnelsDegreeSubjectFieldofStudy" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.16</number>
        <name>EMS Personnel's Degree Subject/Field of Study</name>
        <national>No</national>
        <state>No</state>
        <definition>The area of the personnel's post high-school (post-secondary) degree.</definition>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="PersonnelDegreeFieldofStudy">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.17

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.17</number>
  <name>EMS Personnel's Motor Vehicle License Type</name>
  <national>No</national>
  <state>No</state>
  <definition>The type of motor vehicle license (i.e. Class A, B, Pilot, etc.) of the EMS personnel.</definition>
  <usage>Optional</usage>
</nemsisTacDoc>

Diagram

Type

extension of PersonnelVehicleLicenseType

Type hierarchy

xs:string
- PersonnelVehicleLicenseType

Properties

content	complex
minOccurs	0
maxOccurs	unbounded

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional

Source

<xs:element name="dPersonnel.17" id="dPersonnel.EMSPersonnelsMotorVehicleLicenseType" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.17</number>
        <name>EMS Personnel's Motor Vehicle License Type</name>
        <national>No</national>
        <state>No</state>
        <definition>The type of motor vehicle license (i.e. Class A, B, Pilot, etc.) of the EMS personnel.</definition>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="PersonnelVehicleLicenseType">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.ImmunizationsGroup

Namespace

http://www.nemsis.org

Annotations

Group Tag to hold Immunization type and date

Diagram

Properties

content	complex
minOccurs	0
maxOccurs	unbounded

Model

dPersonnel.18{0,1} , dPersonnel.19{0,1}

Children

dPersonnel.18, dPersonnel.19

Instance

<dPersonnel.ImmunizationsGroup CorrelationID="" UUID="" xmlns="http://www.nemsis.org">
  <dPersonnel.18>{0,1}</dPersonnel.18>
  <dPersonnel.19>{0,1}</dPersonnel.19>
</dPersonnel.ImmunizationsGroup>

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional
UUID	UUID	required

Source

<xs:element name="dPersonnel.ImmunizationsGroup" id="dPersonnel.PersonnelImmunizationsGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group Tag to hold Immunization type and date</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="dPersonnel.18" type="ImmunizationType" id="dPersonnel.EMSPersonnelsImmunizationStatus" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.18</number>
              <name>EMS Personnel's Immunization Status</name>
              <national>No</national>
              <state>No</state>
              <definition>The type of immunization status.</definition>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.19" type="Year" id="dPersonnel.EMSPersonnelsImmunizationYear" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.19</number>
              <name>EMS Personnel's Immunization Year</name>
              <national>No</national>
              <state>No</state>
              <definition>The year associated with each immunization type.</definition>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
    <xs:attribute name="UUID" type="UUID" use="required"/>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.ImmunizationsGroup / dPersonnel.18

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.18</number>
  <name>EMS Personnel's Immunization Status</name>
  <national>No</national>
  <state>No</state>
  <definition>The type of immunization status.</definition>
  <usage>Optional</usage>
</nemsisTacDoc>

Diagram

Type

ImmunizationType

Properties

content	simple
minOccurs	0

Facets

enumeration

9910001

Anthrax

enumeration

9910003

Cholera

enumeration

9910005

DPT / TDaP (Diphtheria, Pertussis, Tetanus)

enumeration

9910007

Hemophilus Influenza B

enumeration

9910009

Hepatitis A

enumeration

9910011

Hepatitis B

enumeration

9910013

Human Papilloma Virus (HPV)

enumeration

9910015

Influenza-H1N1

enumeration

9910017

Influenza-Other

enumeration

9910019

Influenza-Seasonal (In past 12 months)

enumeration

9910021

Lyme Disease

enumeration

9910023

Meningococcus

enumeration

9910025

MMR (Measles, Mumps, Rubella)

enumeration

9910027

Other-Not Listed

enumeration

9910029

Plague

enumeration

9910031

Pneumococcal (Pneumonia)

enumeration

9910033

Polio

enumeration

9910035

Rabies

enumeration

9910037

Rotavirus

enumeration

9910039

Shingles

enumeration

9910041

Small Pox

enumeration

9910043

Tetanus

enumeration

9910045

Tuberculosis

enumeration

9910047

Typhoid

enumeration

9910049

Varicella (Chickenpox)

enumeration

9910051

Yellow Fever

enumeration

9910053

None

Source

<xs:element name="dPersonnel.18" type="ImmunizationType" id="dPersonnel.EMSPersonnelsImmunizationStatus" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.18</number>
        <name>EMS Personnel's Immunization Status</name>
        <national>No</national>
        <state>No</state>
        <definition>The type of immunization status.</definition>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.ImmunizationsGroup / dPersonnel.19

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.19</number>
  <name>EMS Personnel's Immunization Year</name>
  <national>No</national>
  <state>No</state>
  <definition>The year associated with each immunization type.</definition>
  <usage>Optional</usage>
</nemsisTacDoc>

Diagram

Type

Year

Properties

content	simple
minOccurs	0

Facets

maxInclusive	2050
minInclusive	1900

Source

<xs:element name="dPersonnel.19" type="Year" id="dPersonnel.EMSPersonnelsImmunizationYear" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.19</number>
        <name>EMS Personnel's Immunization Year</name>
        <national>No</national>
        <state>No</state>
        <definition>The year associated with each immunization type.</definition>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.20

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.20</number>
  <name>EMS Personnel's Foreign Language Ability</name>
  <national>No</national>
  <state>No</state>
  <definition>The languages spoken (other than English) by the personnel with at least an elementary level of proficiency.</definition>
  <usage>Optional</usage>
  <v3Changes>Added to better describe the EMS workforce.</v3Changes>
</nemsisTacDoc>

Diagram

Type

extension of PersonnelForeignLanguageAbility

Type hierarchy

xs:string
- PersonnelForeignLanguageAbility

Properties

content	complex
minOccurs	0
maxOccurs	unbounded

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional

Source

<xs:element name="dPersonnel.20" id="dPersonnel.EMSPersonnelsForeignLanguageAbility" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.20</number>
        <name>EMS Personnel's Foreign Language Ability</name>
        <national>No</national>
        <state>No</state>
        <definition>The languages spoken (other than English) by the personnel with at least an elementary level of proficiency.</definition>
        <usage>Optional</usage>
        <v3Changes>Added to better describe the EMS workforce.</v3Changes>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="PersonnelForeignLanguageAbility">
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.21

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.21</number>
  <name>EMS Personnel's Agency ID Number</name>
  <national>No</national>
  <state>No</state>
  <definition>The local agency ID number for the personnel.</definition>
  <v2Number>D07_01</v2Number>
  <usage>Optional</usage>
  <comment>This is a local ID and not the ID associated with the state credential. This may be the same as the state credential ID depending on the state and local implementation. This should be a unique number and not reused.</comment>
</nemsisTacDoc>

Diagram

Type

PersonnelAgencyIDNumber

Properties

content	simple
minOccurs	0

Facets

minLength	2
maxLength	50

Source

<xs:element name="dPersonnel.21" type="PersonnelAgencyIDNumber" id="dPersonnel.EMSPersonnelsAgencyIDNumber" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.21</number>
        <name>EMS Personnel's Agency ID Number</name>
        <national>No</national>
        <state>No</state>
        <definition>The local agency ID number for the personnel.</definition>
        <v2Number>D07_01</v2Number>
        <usage>Optional</usage>
        <comment>This is a local ID and not the ID associated with the state credential. This may be the same as the state credential ID depending on the state and local implementation. This should be a unique number and not reused.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup

Namespace

http://www.nemsis.org

Annotations

Group to hold the licensure information

Diagram

Properties

content	complex
minOccurs	0
maxOccurs	unbounded

Model

dPersonnel.22{0,1} , dPersonnel.23{0,1} , dPersonnel.24{0,1} , dPersonnel.25{0,1} , dPersonnel.26{0,1} , dPersonnel.27{0,1}

Children

dPersonnel.22, dPersonnel.23, dPersonnel.24, dPersonnel.25, dPersonnel.26, dPersonnel.27

Instance

<dPersonnel.LicensureGroup CorrelationID="" UUID="" xmlns="http://www.nemsis.org">
  <dPersonnel.22 NV="">{0,1}</dPersonnel.22>
  <dPersonnel.23 NV="">{0,1}</dPersonnel.23>
  <dPersonnel.24 NV="">{0,1}</dPersonnel.24>
  <dPersonnel.25>{0,1}</dPersonnel.25>
  <dPersonnel.26>{0,1}</dPersonnel.26>
  <dPersonnel.27>{0,1}</dPersonnel.27>
</dPersonnel.LicensureGroup>

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional
UUID	UUID	required

Source

<xs:element name="dPersonnel.LicensureGroup" id="dPersonnel.LicensureGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group to hold the licensure information</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="dPersonnel.22" nillable="true" id="dPersonnel.EMSPersonnelsStateofLicensure" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.22</number>
              <name>EMS Personnel's State of Licensure</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The state of the certification/licensure ID number assigned to the personnel member.</definition>
              <usage>Recommended</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="ANSIStateCode">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.23" nillable="true" id="dPersonnel.EMSPersonnelsStateLicensureIDNumber" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.23</number>
              <name>EMS Personnel's State's Licensure ID Number</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The state's licensure/certification ID number for the personnel.</definition>
              <v2Number>D07_02</v2Number>
              <usage>Recommended</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="StateLicensureID">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.24" nillable="true" id="dPersonnel.EMSPersonnelsStateEMSCertificationLicensureLevel" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.24</number>
              <name>EMS Personnel's State EMS Certification Licensure Level</name>
              <national>No</national>
              <state>Yes</state>
              <definition>The personnel's state EMS certification level.</definition>
              <v2Number>D08_15</v2Number>
              <usage>Recommended</usage>
              <comment>The category Emergency Medical Technician - Intermediate includes EMS professionals with an "85" or "99" certification level.<br/><br/>Some listed health care providers may not have an EMS certification/licensure number, however their level should be indicated from the list above and the state licensure number should be indicated in dPersonnel.23 - EMS Personnel's State's Licensure ID Number.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
        <xs:complexType>
          <xs:simpleContent>
            <xs:extension base="MemberLevel">
              <xs:attribute name="NV" use="optional">
                <xs:simpleType>
                  <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                </xs:simpleType>
              </xs:attribute>
            </xs:extension>
          </xs:simpleContent>
        </xs:complexType>
      </xs:element>
      <xs:element name="dPersonnel.25" type="DateType" id="dPersonnel.EMSPersonnelsStateEMSCurrentCertificationDate" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.25</number>
              <name>EMS Personnel's State EMS Current Certification Date</name>
              <national>No</national>
              <state>No</state>
              <definition>The date of the personnel's current EMS certification/licensure.</definition>
              <v2Number>D08_17</v2Number>
              <usage>Optional</usage>
              <comment>Clarified as the current certification/licensure.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.26" type="DateType" id="dPersonnel.EMSPersonnelsInitialStateLicensureIssueDate" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.26</number>
              <name>EMS Personnel's Initial State's Licensure Issue Date</name>
              <national>No</national>
              <state>No</state>
              <definition>The date on which the EMS personnel's state's EMS certification/licensure was originally issued. This is the date of the first certification/licensure for the EMS level.</definition>
              <v2Number>D08_18</v2Number>
              <usage>Optional</usage>
              <comment>Clarified as the FIRST (original) certification/licensure date.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.27" type="DateType" id="dPersonnel.EMSPersonnelsCurrentStateLicensureExpirationDate" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.27</number>
              <name>EMS Personnel's Current State's Licensure Expiration Date</name>
              <national>No</national>
              <state>No</state>
              <definition>The date on which the EMS personnel's (highest) state EMS certification/licensure expires.</definition>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
    <xs:attribute name="UUID" type="UUID" use="required"/>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / dPersonnel.22

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.22</number>
  <name>EMS Personnel's State of Licensure</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The state of the certification/licensure ID number assigned to the personnel member.</definition>
  <usage>Recommended</usage>
</nemsisTacDoc>

Diagram

Type

extension of ANSIStateCode

Type hierarchy

xs:string
- ANSIStateCode

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.22" nillable="true" id="dPersonnel.EMSPersonnelsStateofLicensure" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.22</number>
        <name>EMS Personnel's State of Licensure</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The state of the certification/licensure ID number assigned to the personnel member.</definition>
        <usage>Recommended</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="ANSIStateCode">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / dPersonnel.23

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.23</number>
  <name>EMS Personnel's State's Licensure ID Number</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The state's licensure/certification ID number for the personnel.</definition>
  <v2Number>D07_02</v2Number>
  <usage>Recommended</usage>
</nemsisTacDoc>

Diagram

Type

extension of StateLicensureID

Type hierarchy

xs:string
- StateLicensureID

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.23" nillable="true" id="dPersonnel.EMSPersonnelsStateLicensureIDNumber" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.23</number>
        <name>EMS Personnel's State's Licensure ID Number</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The state's licensure/certification ID number for the personnel.</definition>
        <v2Number>D07_02</v2Number>
        <usage>Recommended</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="StateLicensureID">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / dPersonnel.24

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.24</number>
  <name>EMS Personnel's State EMS Certification Licensure Level</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The personnel's state EMS certification level.</definition>
  <v2Number>D08_15</v2Number>
  <usage>Recommended</usage>
  <comment>The category Emergency Medical Technician - Intermediate includes EMS professionals with an "85" or "99" certification level.<br/><br/>Some listed health care providers may not have an EMS certification/licensure number, however their level should be indicated from the list above and the state licensure number should be indicated in dPersonnel.23 - EMS Personnel's State's Licensure ID Number.</comment>
</nemsisTacDoc>

Diagram

Type

extension of MemberLevel

Type hierarchy

xs:string
- MemberLevel

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.24" nillable="true" id="dPersonnel.EMSPersonnelsStateEMSCertificationLicensureLevel" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.24</number>
        <name>EMS Personnel's State EMS Certification Licensure Level</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The personnel's state EMS certification level.</definition>
        <v2Number>D08_15</v2Number>
        <usage>Recommended</usage>
        <comment>The category Emergency Medical Technician - Intermediate includes EMS professionals with an "85" or "99" certification level.<br/><br/>Some listed health care providers may not have an EMS certification/licensure number, however their level should be indicated from the list above and the state licensure number should be indicated in dPersonnel.23 - EMS Personnel's State's Licensure ID Number.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="MemberLevel">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / dPersonnel.25

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.25</number>
  <name>EMS Personnel's State EMS Current Certification Date</name>
  <national>No</national>
  <state>No</state>
  <definition>The date of the personnel's current EMS certification/licensure.</definition>
  <v2Number>D08_17</v2Number>
  <usage>Optional</usage>
  <comment>Clarified as the current certification/licensure.</comment>
</nemsisTacDoc>

Diagram

Type

DateType

Properties

content	simple
minOccurs	0

Facets

maxInclusive	2050-01-01
minInclusive	1900-01-01

Source

<xs:element name="dPersonnel.25" type="DateType" id="dPersonnel.EMSPersonnelsStateEMSCurrentCertificationDate" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.25</number>
        <name>EMS Personnel's State EMS Current Certification Date</name>
        <national>No</national>
        <state>No</state>
        <definition>The date of the personnel's current EMS certification/licensure.</definition>
        <v2Number>D08_17</v2Number>
        <usage>Optional</usage>
        <comment>Clarified as the current certification/licensure.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / dPersonnel.26

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.26</number>
  <name>EMS Personnel's Initial State's Licensure Issue Date</name>
  <national>No</national>
  <state>No</state>
  <definition>The date on which the EMS personnel's state's EMS certification/licensure was originally issued. This is the date of the first certification/licensure for the EMS level.</definition>
  <v2Number>D08_18</v2Number>
  <usage>Optional</usage>
  <comment>Clarified as the FIRST (original) certification/licensure date.</comment>
</nemsisTacDoc>

Diagram

Type

DateType

Properties

content	simple
minOccurs	0

Facets

maxInclusive	2050-01-01
minInclusive	1900-01-01

Source

<xs:element name="dPersonnel.26" type="DateType" id="dPersonnel.EMSPersonnelsInitialStateLicensureIssueDate" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.26</number>
        <name>EMS Personnel's Initial State's Licensure Issue Date</name>
        <national>No</national>
        <state>No</state>
        <definition>The date on which the EMS personnel's state's EMS certification/licensure was originally issued. This is the date of the first certification/licensure for the EMS level.</definition>
        <v2Number>D08_18</v2Number>
        <usage>Optional</usage>
        <comment>Clarified as the FIRST (original) certification/licensure date.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / dPersonnel.27

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.27</number>
  <name>EMS Personnel's Current State's Licensure Expiration Date</name>
  <national>No</national>
  <state>No</state>
  <definition>The date on which the EMS personnel's (highest) state EMS certification/licensure expires.</definition>
  <usage>Optional</usage>
</nemsisTacDoc>

Diagram

Type

DateType

Properties

content	simple
minOccurs	0

Facets

maxInclusive	2050-01-01
minInclusive	1900-01-01

Source

<xs:element name="dPersonnel.27" type="DateType" id="dPersonnel.EMSPersonnelsCurrentStateLicensureExpirationDate" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.27</number>
        <name>EMS Personnel's Current State's Licensure Expiration Date</name>
        <national>No</national>
        <state>No</state>
        <definition>The date on which the EMS personnel's (highest) state EMS certification/licensure expires.</definition>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.28

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.28</number>
  <name>EMS Personnel's National Registry Number</name>
  <national>No</national>
  <state>No</state>
  <definition>The National Registry number associated with the level of certification/licensure obtained through NREMT.</definition>
  <usage>Optional</usage>
  <performanceMeasures/>
</nemsisTacDoc>

Diagram

Type

NationalRegistryNumber

Properties

content	simple
minOccurs	0

Facets

pattern

[A-Z][A-Z0-9][0-9]{6}

Source

<xs:element name="dPersonnel.28" type="NationalRegistryNumber" id="dPersonnel.NationalRegistryNumber" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.28</number>
        <name>EMS Personnel's National Registry Number</name>
        <national>No</national>
        <state>No</state>
        <definition>The National Registry number associated with the level of certification/licensure obtained through NREMT.</definition>
        <usage>Optional</usage>
        <performanceMeasures/>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.29

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.29</number>
  <name>EMS Personnel's National Registry Certification Level</name>
  <national>No</national>
  <state>No</state>
  <definition>The level of the current National Registry of Emergency Medical Technicians (NREMT) certification.</definition>
  <usage>Optional</usage>
  <performanceMeasures/>
  <comment>The category EMT-Intermediate includes EMS professionals with an "85" or "99" certification level.</comment>
</nemsisTacDoc>

Diagram

Type

NationalRegistryCertificationLevel

Properties

content	simple
minOccurs	0

Facets

enumeration

1529001

Advanced Emergency Medical Technician (AEMT)

enumeration

1529002

Emergency Medical Technician - Intermediate

enumeration

1529003

Emergency Medical Responder (EMR)

enumeration

1529005

Emergency Medical Technician (EMT)

enumeration

1529007

Paramedic

Source

<xs:element name="dPersonnel.29" type="NationalRegistryCertificationLevel" id="dPersonnel.NationalRegistryCertificationLevel" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.29</number>
        <name>EMS Personnel's National Registry Certification Level</name>
        <national>No</national>
        <state>No</state>
        <definition>The level of the current National Registry of Emergency Medical Technicians (NREMT) certification.</definition>
        <usage>Optional</usage>
        <performanceMeasures/>
        <comment>The category EMT-Intermediate includes EMS professionals with an "85" or "99" certification level.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.30

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.30</number>
  <name>EMS Personnel's Current National Registry Expiration Date</name>
  <national>No</national>
  <state>No</state>
  <definition>The date on which the EMS Personnel's National Registry of EMTs certification/licensure expires.</definition>
  <usage>Optional</usage>
  <performanceMeasures/>
</nemsisTacDoc>

Diagram

Type

DateType

Properties

content	simple
minOccurs	0

Facets

maxInclusive	2050-01-01
minInclusive	1900-01-01

Source

<xs:element name="dPersonnel.30" type="DateType" id="dPersonnel.PersonnelsCurrentNationalCertificationExpirationDate" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.30</number>
        <name>EMS Personnel's Current National Registry Expiration Date</name>
        <national>No</national>
        <state>No</state>
        <definition>The date on which the EMS Personnel's National Registry of EMTs certification/licensure expires.</definition>
        <usage>Optional</usage>
        <performanceMeasures/>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.31

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.31</number>
  <name>EMS Personnel's Employment Status</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The personnel's primary employment status for this agency.</definition>
  <v2Number>D07_03</v2Number>
  <usage>Recommended</usage>
</nemsisTacDoc>

Diagram

Type

extension of EmploymentStatus

Type hierarchy

xs:string
- EmploymentStatus

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.31" nillable="true" id="dPersonnel.EMSPersonnelsEmploymentStatus" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.31</number>
        <name>EMS Personnel's Employment Status</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The personnel's primary employment status for this agency.</definition>
        <v2Number>D07_03</v2Number>
        <usage>Recommended</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="EmploymentStatus">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.32

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.32</number>
  <name>EMS Personnel's Employment Status Date</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The personnel's employment status date.</definition>
  <v2Number>D07_04</v2Number>
  <usage>Recommended</usage>
</nemsisTacDoc>

Diagram

Type

extension of DateType

Type hierarchy

xs:date
- DateType

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.32" nillable="true" id="dPersonnel.EMSPersonnelsEmploymentStatusDate" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.32</number>
        <name>EMS Personnel's Employment Status Date</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The personnel's employment status date.</definition>
        <v2Number>D07_04</v2Number>
        <usage>Recommended</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="DateType">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.33

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.33</number>
  <name>EMS Personnel's Hire Date</name>
  <national>No</national>
  <state>No</state>
  <definition>The date the employee was hired by the EMS agency for this current job.</definition>
  <usage>Optional</usage>
  <comment>This is intended to collect information based on the current employment/job. If the EMS personnel has a come and go status, this should reflect the most recent employment/job.</comment>
</nemsisTacDoc>

Diagram

Type

DateType

Properties

content	simple
minOccurs	0

Facets

maxInclusive	2050-01-01
minInclusive	1900-01-01

Source

<xs:element name="dPersonnel.33" type="DateType" id="dPersonnel.EMSPersonnelsHireDate" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.33</number>
        <name>EMS Personnel's Hire Date</name>
        <national>No</national>
        <state>No</state>
        <definition>The date the employee was hired by the EMS agency for this current job.</definition>
        <usage>Optional</usage>
        <comment>This is intended to collect information based on the current employment/job. If the EMS personnel has a come and go status, this should reflect the most recent employment/job.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.34

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.34</number>
  <name>EMS Personnel's Primary EMS Job Role</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The individuals primary/main EMS role at the EMS agency. This is the function which is performed the majority of the time for the EMS personnel.</definition>
  <usage>Recommended</usage>
  <comment>This is a single choice data element which should reflect the EMS Personnel's primary/main job role for which he/she functions. It is understood that most EMS personnel perform more than one role as a part of their position. Other roles should be documented in dPersonnel.35 (EMS Personnel's Other Job Responsibilities).</comment>
</nemsisTacDoc>

Diagram

Type

extension of JobResponsibilities

Type hierarchy

xs:string
- JobResponsibilities

Properties

content	complex
minOccurs	0
nillable	true

Attributes

QName	Type	Use
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.34" nillable="true" id="dPersonnel.EMSPersonnelsPrimaryEMSJobRole" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.34</number>
        <name>EMS Personnel's Primary EMS Job Role</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The individuals primary/main EMS role at the EMS agency. This is the function which is performed the majority of the time for the EMS personnel.</definition>
        <usage>Recommended</usage>
        <comment>This is a single choice data element which should reflect the EMS Personnel's primary/main job role for which he/she functions. It is understood that most EMS personnel perform more than one role as a part of their position. Other roles should be documented in dPersonnel.35 (EMS Personnel's Other Job Responsibilities).</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="JobResponsibilities">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.35

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.35</number>
  <name>EMS Personnel's Other Job Responsibilities</name>
  <national>No</national>
  <state>Yes</state>
  <definition>The EMS personnel's other job responsibilities at the agency beyond their primary role documented in dPersonnel.34 (EMS Personnel's Primary EMS Job Role).</definition>
  <usage>Recommended</usage>
</nemsisTacDoc>

Diagram

Type

extension of JobResponsibilities

Type hierarchy

xs:string
- JobResponsibilities

Properties

content	complex
minOccurs	0
maxOccurs	unbounded
nillable	true

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional
NV	union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)	optional

Source

<xs:element name="dPersonnel.35" nillable="true" id="dPersonnel.EMSPersonnelsOtherJobResponsibilities" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.35</number>
        <name>EMS Personnel's Other Job Responsibilities</name>
        <national>No</national>
        <state>Yes</state>
        <definition>The EMS personnel's other job responsibilities at the agency beyond their primary role documented in dPersonnel.34 (EMS Personnel's Primary EMS Job Role).</definition>
        <usage>Recommended</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:simpleContent>
      <xs:extension base="JobResponsibilities">
        <xs:attribute name="NV" use="optional">
          <xs:simpleType>
            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
          </xs:simpleType>
        </xs:attribute>
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
      </xs:extension>
    </xs:simpleContent>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.36

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.36</number>
  <name>EMS Personnel's Total Length of Service in Years</name>
  <national>No</national>
  <state>No</state>
  <definition>The personnel's total length of EMS service at any level (years).</definition>
  <v2Number>D08_19</v2Number>
  <usage>Optional</usage>
</nemsisTacDoc>

Diagram

Type

TotalService

Properties

content	simple
minOccurs	0

Facets

maxInclusive	80
minInclusive	0

Source

<xs:element name="dPersonnel.36" type="TotalService" id="dPersonnel.EMSPersonnelsTotalLengthofServiceinYears" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.36</number>
        <name>EMS Personnel's Total Length of Service in Years</name>
        <national>No</national>
        <state>No</state>
        <definition>The personnel's total length of EMS service at any level (years).</definition>
        <v2Number>D08_19</v2Number>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.37

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.37</number>
  <name>EMS Personnel's Date Length of Service Documented</name>
  <national>No</national>
  <state>No</state>
  <definition>The date which the length of EMS service was documented.</definition>
  <v2Number>D08_20</v2Number>
  <usage>Optional</usage>
  <comment>Associated with dPersonnel.37 (EMS Personnel's Total Length of Service in Years).</comment>
</nemsisTacDoc>

Diagram

Type

DateType

Properties

content	simple
minOccurs	0

Facets

maxInclusive	2050-01-01
minInclusive	1900-01-01

Source

<xs:element name="dPersonnel.37" type="DateType" id="dPersonnel.EMSPersonnelsDateLengthofServiceDocumented" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.37</number>
        <name>EMS Personnel's Date Length of Service Documented</name>
        <national>No</national>
        <state>No</state>
        <definition>The date which the length of EMS service was documented.</definition>
        <v2Number>D08_20</v2Number>
        <usage>Optional</usage>
        <comment>Associated with dPersonnel.37 (EMS Personnel's Total Length of Service in Years).</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.CertificationLevelGroup

Namespace

http://www.nemsis.org

Annotations

Group to hold the certification information

Diagram

Properties

content	complex
minOccurs	0
maxOccurs	unbounded

Model

dPersonnel.38{0,1} , dPersonnel.39{0,1}

Children

dPersonnel.38, dPersonnel.39

Instance

<dPersonnel.CertificationLevelGroup CorrelationID="" UUID="" xmlns="http://www.nemsis.org">
  <dPersonnel.38>{0,1}</dPersonnel.38>
  <dPersonnel.39>{0,1}</dPersonnel.39>
</dPersonnel.CertificationLevelGroup>

Attributes

QName	Type	Use
CorrelationID	CorrelationID	optional
UUID	UUID	required

Source

<xs:element name="dPersonnel.CertificationLevelGroup" id="dPersonnel.CertificationLevelGroup" minOccurs="0" maxOccurs="unbounded">
  <xs:annotation>
    <xs:documentation>Group to hold the certification information</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="dPersonnel.38" type="MemberLevel" id="dPersonnel.EMSPersonnelsPracticeLevel" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.38</number>
              <name>EMS Personnel's Practice Level</name>
              <national>No</national>
              <state>No</state>
              <definition>The EMS certification level at which the individual is providing patient care services for the EMS agency.</definition>
              <v2Number>D07_05</v2Number>
              <usage>Optional</usage>
              <comment>The category EMT-Intermediate includes EMS professionals with an "85" or "99" certification level.</comment>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
      <xs:element name="dPersonnel.39" type="DateType" id="dPersonnel.DateofPersonnelsCertificationorLicensureforAgency" minOccurs="0">
        <xs:annotation>
          <xs:documentation>
            <nemsisTacDoc>
              <number>dPersonnel.39</number>
              <name>Date of Personnel's Certification or Licensure for Agency</name>
              <national>No</national>
              <state>No</state>
              <definition>The date that the Certification/Licensure was achieved for the local EMS agency.</definition>
              <v2Number>D07_06</v2Number>
              <usage>Optional</usage>
            </nemsisTacDoc>
          </xs:documentation>
        </xs:annotation>
      </xs:element>
    </xs:sequence>
    <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
    <xs:attribute name="UUID" type="UUID" use="required"/>
  </xs:complexType>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.CertificationLevelGroup / dPersonnel.38

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.38</number>
  <name>EMS Personnel's Practice Level</name>
  <national>No</national>
  <state>No</state>
  <definition>The EMS certification level at which the individual is providing patient care services for the EMS agency.</definition>
  <v2Number>D07_05</v2Number>
  <usage>Optional</usage>
  <comment>The category EMT-Intermediate includes EMS professionals with an "85" or "99" certification level.</comment>
</nemsisTacDoc>

Diagram

Type

MemberLevel

Properties

content	simple
minOccurs	0

Facets

enumeration

9925001

Advanced Emergency Medical Technician (AEMT)

enumeration

9925002

Emergency Medical Technician - Intermediate

enumeration

9925003

Emergency Medical Responder (EMR)

enumeration

9925005

Emergency Medical Technician (EMT)

enumeration

9925007

Paramedic

enumeration

9925023

Other Healthcare Professional

enumeration

9925025

Other Non-Healthcare Professional

enumeration

9925027

Physician

enumeration

9925029

Respiratory Therapist

enumeration

9925031

Student

enumeration

9925033

Critical Care Paramedic

enumeration

9925035

Community Paramedicine

enumeration

9925037

Nurse Practitioner

enumeration

9925039

Physician Assistant

enumeration

9925041

Licensed Practical Nurse (LPN)

enumeration

9925043

Registered Nurse

Source

<xs:element name="dPersonnel.38" type="MemberLevel" id="dPersonnel.EMSPersonnelsPracticeLevel" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.38</number>
        <name>EMS Personnel's Practice Level</name>
        <national>No</national>
        <state>No</state>
        <definition>The EMS certification level at which the individual is providing patient care services for the EMS agency.</definition>
        <v2Number>D07_05</v2Number>
        <usage>Optional</usage>
        <comment>The category EMT-Intermediate includes EMS professionals with an "85" or "99" certification level.</comment>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Element dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.CertificationLevelGroup / dPersonnel.39

Namespace

http://www.nemsis.org

Annotations

<nemsisTacDoc>
  <number>dPersonnel.39</number>
  <name>Date of Personnel's Certification or Licensure for Agency</name>
  <national>No</national>
  <state>No</state>
  <definition>The date that the Certification/Licensure was achieved for the local EMS agency.</definition>
  <v2Number>D07_06</v2Number>
  <usage>Optional</usage>
</nemsisTacDoc>

Diagram

Type

DateType

Properties

content	simple
minOccurs	0

Facets

maxInclusive	2050-01-01
minInclusive	1900-01-01

Source

<xs:element name="dPersonnel.39" type="DateType" id="dPersonnel.DateofPersonnelsCertificationorLicensureforAgency" minOccurs="0">
  <xs:annotation>
    <xs:documentation>
      <nemsisTacDoc>
        <number>dPersonnel.39</number>
        <name>Date of Personnel's Certification or Licensure for Agency</name>
        <national>No</national>
        <state>No</state>
        <definition>The date that the Certification/Licensure was achieved for the local EMS agency.</definition>
        <v2Number>D07_06</v2Number>
        <usage>Optional</usage>
      </nemsisTacDoc>
    </xs:documentation>
  </xs:annotation>
</xs:element>

Complex Type dPersonnel

Namespace

http://www.nemsis.org

Diagram

Used by

Element

DEMDataSet/DemographicReport/dPersonnel

Model

dPersonnel.PersonnelGroup*

Children

dPersonnel.PersonnelGroup

Source

<xs:complexType name="dPersonnel" id="dPersonnel.GeneralPersonnelInformation">
  <xs:sequence>
    <xs:element name="dPersonnel.PersonnelGroup" id="dPersonnel.PersonnelGroup" minOccurs="0" maxOccurs="unbounded">
      <xs:annotation>
        <xs:documentation>Group tag to hold info about the personnel</xs:documentation>
      </xs:annotation>
      <xs:complexType>
        <xs:sequence>
          <xs:element name="dPersonnel.NameGroup" id="dPersonnel.NameGroup" minOccurs="0">
            <xs:annotation>
              <xs:documentation>Group tag to hold info about the personnel's name</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="dPersonnel.01" nillable="true" id="dPersonnel.EMSPersonnelsLastName" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.01</number>
                        <name>EMS Personnel's Last Name</name>
                        <national>No</national>
                        <state>Yes</state>
                        <definition>The last name of the personnel.</definition>
                        <v2Number>D08_01</v2Number>
                        <usage>Recommended</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="PersonLastName">
                        <xs:attribute name="NV" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
                <xs:element name="dPersonnel.02" nillable="true" id="dPersonnel.EMSPersonnelsFirstName" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.02</number>
                        <name>EMS Personnel's First Name</name>
                        <national>No</national>
                        <state>Yes</state>
                        <definition>The first name of the personnel.</definition>
                        <v2Number>D08_03</v2Number>
                        <usage>Recommended</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="PersonFirstName">
                        <xs:attribute name="NV" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
                <xs:element name="dPersonnel.03" nillable="true" id="dPersonnel.EMSPersonnelsMiddleNameInitial" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.03</number>
                        <name>EMS Personnel's Middle Name/Initial</name>
                        <national>No</national>
                        <state>Yes</state>
                        <definition>The middle name or initial of the personnel.</definition>
                        <v2Number>D08_02</v2Number>
                        <usage>Recommended</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="PersonMiddleName">
                        <xs:attribute name="NV" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
              </xs:sequence>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.AddressGroup" id="dPersonnel.AddressGroup" minOccurs="0">
            <xs:annotation>
              <xs:documentation>Group tag to hold info about the personnel's mailing address</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="dPersonnel.04" id="dPersonnel.EMSPersonnelsMailingAddress" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.04</number>
                        <name>EMS Personnel's Mailing Address</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The Street or PO Box of the personnel's mailing address.</definition>
                        <v2Number>D08_04</v2Number>
                        <usage>Optional</usage>
                        <comment>For individuals living outside the USA the full address can be entered in the address line.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="StreetAddress">
                        <xs:attribute name="StreetAddress2" type="StreetAddress" use="optional"/>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
                <xs:element name="dPersonnel.05" type="CityGnisCode" id="dPersonnel.EMSPersonnelsCityofResidence" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.05</number>
                        <name>EMS Personnel's City of Residence</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The city of the personnel's mailing address.</definition>
                        <v2Number>D08_05</v2Number>
                        <usage>Optional</usage>
                        <comment>City codes are based on GNIS Feature Class. The primary Feature Class to use is "Civil" with "Populated Place" and "Military" code as additional options. <br/><br/>Definitions for each GNIS City Feature Class can be found on the GNIS Codes website. <br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm</a></comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="dPersonnel.06" type="ANSIStateCode" id="dPersonnel.EMSPersonnelsState" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.06</number>
                        <name>EMS Personnel's State</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The state of the personnel's mailing address.</definition>
                        <v2Number>D08_06</v2Number>
                        <usage>Optional</usage>
                        <comment>Based on ANSI Code.<br/><br/>GNIS Codes Website: <a href="http://geonames.usgs.gov/domestic/download_data.htm" target="_blank">http://geonames.usgs.gov/domestic/download_data.htm </a></comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="dPersonnel.07" type="ZIP" id="dPersonnel.EMSPersonnelsZIPCode" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.07</number>
                        <name>EMS Personnel's ZIP Code</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The ZIP code of the personnel's mailing address.</definition>
                        <v2Number>D08_07</v2Number>
                        <usage>Optional</usage>
                        <comment>Zip Codes Product Website: <a href="https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/" target="_blank">https://www.zipcodedownload.com/Products/Product/Z5Commercial/Standard/Overview/</a> <br/>Product: USA - 5-digit ZIP Code Database, Commercial Edition</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="dPersonnel.08" type="ANSICountryCodesCAMXUS" id="dPersonnel.EMSPersonnelsCountry" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.08</number>
                        <name>EMS Personnel's Country</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The country of the personnel mailing address.</definition>
                        <usage>Optional</usage>
                        <comment>Based on ANSI Code.<br/><br/>ANSI Country Codes (ISO 3166) Website: <a href="https://www.iso.org/iso-3166-country-codes.html" target="_blank">https://www.iso.org/iso-3166-country-codes.html</a></comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
              </xs:sequence>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.09" id="dPersonnel.EMSPersonnelsPhoneNumber" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.09</number>
                  <name>EMS Personnel's Phone Number</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The phone number for the personnel.</definition>
                  <v2Number>D08_08</v2Number>
                  <usage>Optional</usage>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="PhoneNumber">
                  <xs:attribute name="PhoneNumberType" type="PhoneNumberType" use="optional"/>
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.10" id="dPersonnel.EMSPersonnelsEmailAddress" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.10</number>
                  <name>EMS Personnel's Email Address</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The primary email address of the personnel.</definition>
                  <v2Number>D08_10</v2Number>
                  <usage>Optional</usage>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="EmailAddress">
                  <xs:attribute name="EmailAddressType" type="EmailAddressType" use="optional"/>
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.11" nillable="true" id="dPersonnel.EMSPersonnelsDateofBirth" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.11</number>
                  <name>EMS Personnel's Date of Birth</name>
                  <national>No</national>
                  <state>Yes</state>
                  <definition>The personnel's date of birth.</definition>
                  <v2Number>D08_11</v2Number>
                  <usage>Recommended</usage>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="DateType">
                  <xs:attribute name="NV" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.12" nillable="true" id="dPersonnel.EMSPersonnelsGender" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.12</number>
                  <name>EMS Personnel's Gender</name>
                  <national>No</national>
                  <state>Yes</state>
                  <definition>The personnel's gender.</definition>
                  <v2Number>D08_12</v2Number>
                  <usage>Recommended</usage>
                  <comment>Code list referenced from: <a href="https://www.healthit.gov/isa/sex-birth-sexual-orientation-and-gender-identity" target="_blank">https://www.healthit.gov/isa/sex-birth-sexual-orientation-and-gender-identity</a></comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="Gender">
                  <xs:attribute name="NV" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.13" nillable="true" id="dPersonnel.EMSPersonnelsRace" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.13</number>
                  <name>EMS Personnel's Race</name>
                  <national>No</national>
                  <state>Yes</state>
                  <definition>The personnel's race as defined by the OMB (US Office of Management and Budget).</definition>
                  <v2Number>D08_13</v2Number>
                  <usage>Recommended</usage>
                  <comment>OMB requirements are provided at: <a href="https://www.federalregister.gov/d/2024-06469" target="_blank">https://www.federalregister.gov/d/2024-06469</a>. A single multiple choice question methodology is being implemented to improve the completion of ethnicity information. Ethnicity (Version 2.1.1: D08_14) has been merged with this data element and retired.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="DemographicRace">
                  <xs:attribute name="NV" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                    </xs:simpleType>
                  </xs:attribute>
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.14" type="ANSICountryCode" id="dPersonnel.EMSPersonnelsCitizenship" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.14</number>
                  <name>EMS Personnel's Citizenship</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The documentation of the personnel's citizenship.</definition>
                  <usage>Optional</usage>
                  <comment>Website: <a href="https://www.iso.org/iso-3166-country-codes.html" target="_blank">https://www.iso.org/iso-3166-country-codes.html</a></comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
          </xs:element>
          <xs:element name="dPersonnel.15" type="PersonnelHighestEducationalDegree" id="dPersonnel.EMSPersonnelsHighestEducationalDegree" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.15</number>
                  <name>EMS Personnel's Highest Educational Degree</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The highest educational degree completed by the personnel.</definition>
                  <usage>Optional</usage>
                  <comment>Based on Census 2000 Educational Attainment Question.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
          </xs:element>
          <xs:element name="dPersonnel.16" id="dPersonnel.EMSPersonnelsDegreeSubjectFieldofStudy" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.16</number>
                  <name>EMS Personnel's Degree Subject/Field of Study</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The area of the personnel's post high-school (post-secondary) degree.</definition>
                  <usage>Optional</usage>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="PersonnelDegreeFieldofStudy">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.17" id="dPersonnel.EMSPersonnelsMotorVehicleLicenseType" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.17</number>
                  <name>EMS Personnel's Motor Vehicle License Type</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The type of motor vehicle license (i.e. Class A, B, Pilot, etc.) of the EMS personnel.</definition>
                  <usage>Optional</usage>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="PersonnelVehicleLicenseType">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.ImmunizationsGroup" id="dPersonnel.PersonnelImmunizationsGroup" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>Group Tag to hold Immunization type and date</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="dPersonnel.18" type="ImmunizationType" id="dPersonnel.EMSPersonnelsImmunizationStatus" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.18</number>
                        <name>EMS Personnel's Immunization Status</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The type of immunization status.</definition>
                        <usage>Optional</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="dPersonnel.19" type="Year" id="dPersonnel.EMSPersonnelsImmunizationYear" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.19</number>
                        <name>EMS Personnel's Immunization Year</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The year associated with each immunization type.</definition>
                        <usage>Optional</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
              </xs:sequence>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="UUID" type="UUID" use="required"/>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.20" id="dPersonnel.EMSPersonnelsForeignLanguageAbility" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.20</number>
                  <name>EMS Personnel's Foreign Language Ability</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The languages spoken (other than English) by the personnel with at least an elementary level of proficiency.</definition>
                  <usage>Optional</usage>
                  <v3Changes>Added to better describe the EMS workforce.</v3Changes>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="PersonnelForeignLanguageAbility">
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.21" type="PersonnelAgencyIDNumber" id="dPersonnel.EMSPersonnelsAgencyIDNumber" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.21</number>
                  <name>EMS Personnel's Agency ID Number</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The local agency ID number for the personnel.</definition>
                  <v2Number>D07_01</v2Number>
                  <usage>Optional</usage>
                  <comment>This is a local ID and not the ID associated with the state credential. This may be the same as the state credential ID depending on the state and local implementation. This should be a unique number and not reused.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
          </xs:element>
          <xs:element name="dPersonnel.LicensureGroup" id="dPersonnel.LicensureGroup" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>Group to hold the licensure information</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="dPersonnel.22" nillable="true" id="dPersonnel.EMSPersonnelsStateofLicensure" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.22</number>
                        <name>EMS Personnel's State of Licensure</name>
                        <national>No</national>
                        <state>Yes</state>
                        <definition>The state of the certification/licensure ID number assigned to the personnel member.</definition>
                        <usage>Recommended</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="ANSIStateCode">
                        <xs:attribute name="NV" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
                <xs:element name="dPersonnel.23" nillable="true" id="dPersonnel.EMSPersonnelsStateLicensureIDNumber" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.23</number>
                        <name>EMS Personnel's State's Licensure ID Number</name>
                        <national>No</national>
                        <state>Yes</state>
                        <definition>The state's licensure/certification ID number for the personnel.</definition>
                        <v2Number>D07_02</v2Number>
                        <usage>Recommended</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="StateLicensureID">
                        <xs:attribute name="NV" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
                <xs:element name="dPersonnel.24" nillable="true" id="dPersonnel.EMSPersonnelsStateEMSCertificationLicensureLevel" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.24</number>
                        <name>EMS Personnel's State EMS Certification Licensure Level</name>
                        <national>No</national>
                        <state>Yes</state>
                        <definition>The personnel's state EMS certification level.</definition>
                        <v2Number>D08_15</v2Number>
                        <usage>Recommended</usage>
                        <comment>The category Emergency Medical Technician - Intermediate includes EMS professionals with an "85" or "99" certification level.<br/><br/>Some listed health care providers may not have an EMS certification/licensure number, however their level should be indicated from the list above and the state licensure number should be indicated in dPersonnel.23 - EMS Personnel's State's Licensure ID Number.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                  <xs:complexType>
                    <xs:simpleContent>
                      <xs:extension base="MemberLevel">
                        <xs:attribute name="NV" use="optional">
                          <xs:simpleType>
                            <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                          </xs:simpleType>
                        </xs:attribute>
                      </xs:extension>
                    </xs:simpleContent>
                  </xs:complexType>
                </xs:element>
                <xs:element name="dPersonnel.25" type="DateType" id="dPersonnel.EMSPersonnelsStateEMSCurrentCertificationDate" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.25</number>
                        <name>EMS Personnel's State EMS Current Certification Date</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The date of the personnel's current EMS certification/licensure.</definition>
                        <v2Number>D08_17</v2Number>
                        <usage>Optional</usage>
                        <comment>Clarified as the current certification/licensure.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="dPersonnel.26" type="DateType" id="dPersonnel.EMSPersonnelsInitialStateLicensureIssueDate" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.26</number>
                        <name>EMS Personnel's Initial State's Licensure Issue Date</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The date on which the EMS personnel's state's EMS certification/licensure was originally issued. This is the date of the first certification/licensure for the EMS level.</definition>
                        <v2Number>D08_18</v2Number>
                        <usage>Optional</usage>
                        <comment>Clarified as the FIRST (original) certification/licensure date.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="dPersonnel.27" type="DateType" id="dPersonnel.EMSPersonnelsCurrentStateLicensureExpirationDate" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.27</number>
                        <name>EMS Personnel's Current State's Licensure Expiration Date</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The date on which the EMS personnel's (highest) state EMS certification/licensure expires.</definition>
                        <usage>Optional</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
              </xs:sequence>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="UUID" type="UUID" use="required"/>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.28" type="NationalRegistryNumber" id="dPersonnel.NationalRegistryNumber" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.28</number>
                  <name>EMS Personnel's National Registry Number</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The National Registry number associated with the level of certification/licensure obtained through NREMT.</definition>
                  <usage>Optional</usage>
                  <performanceMeasures/>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
          </xs:element>
          <xs:element name="dPersonnel.29" type="NationalRegistryCertificationLevel" id="dPersonnel.NationalRegistryCertificationLevel" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.29</number>
                  <name>EMS Personnel's National Registry Certification Level</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The level of the current National Registry of Emergency Medical Technicians (NREMT) certification.</definition>
                  <usage>Optional</usage>
                  <performanceMeasures/>
                  <comment>The category EMT-Intermediate includes EMS professionals with an "85" or "99" certification level.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
          </xs:element>
          <xs:element name="dPersonnel.30" type="DateType" id="dPersonnel.PersonnelsCurrentNationalCertificationExpirationDate" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.30</number>
                  <name>EMS Personnel's Current National Registry Expiration Date</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The date on which the EMS Personnel's National Registry of EMTs certification/licensure expires.</definition>
                  <usage>Optional</usage>
                  <performanceMeasures/>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
          </xs:element>
          <xs:element name="dPersonnel.31" nillable="true" id="dPersonnel.EMSPersonnelsEmploymentStatus" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.31</number>
                  <name>EMS Personnel's Employment Status</name>
                  <national>No</national>
                  <state>Yes</state>
                  <definition>The personnel's primary employment status for this agency.</definition>
                  <v2Number>D07_03</v2Number>
                  <usage>Recommended</usage>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="EmploymentStatus">
                  <xs:attribute name="NV" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.32" nillable="true" id="dPersonnel.EMSPersonnelsEmploymentStatusDate" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.32</number>
                  <name>EMS Personnel's Employment Status Date</name>
                  <national>No</national>
                  <state>Yes</state>
                  <definition>The personnel's employment status date.</definition>
                  <v2Number>D07_04</v2Number>
                  <usage>Recommended</usage>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="DateType">
                  <xs:attribute name="NV" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.33" type="DateType" id="dPersonnel.EMSPersonnelsHireDate" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.33</number>
                  <name>EMS Personnel's Hire Date</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The date the employee was hired by the EMS agency for this current job.</definition>
                  <usage>Optional</usage>
                  <comment>This is intended to collect information based on the current employment/job. If the EMS personnel has a come and go status, this should reflect the most recent employment/job.</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
          </xs:element>
          <xs:element name="dPersonnel.34" nillable="true" id="dPersonnel.EMSPersonnelsPrimaryEMSJobRole" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.34</number>
                  <name>EMS Personnel's Primary EMS Job Role</name>
                  <national>No</national>
                  <state>Yes</state>
                  <definition>The individuals primary/main EMS role at the EMS agency. This is the function which is performed the majority of the time for the EMS personnel.</definition>
                  <usage>Recommended</usage>
                  <comment>This is a single choice data element which should reflect the EMS Personnel's primary/main job role for which he/she functions. It is understood that most EMS personnel perform more than one role as a part of their position. Other roles should be documented in dPersonnel.35 (EMS Personnel's Other Job Responsibilities).</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="JobResponsibilities">
                  <xs:attribute name="NV" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                    </xs:simpleType>
                  </xs:attribute>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.35" nillable="true" id="dPersonnel.EMSPersonnelsOtherJobResponsibilities" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.35</number>
                  <name>EMS Personnel's Other Job Responsibilities</name>
                  <national>No</national>
                  <state>Yes</state>
                  <definition>The EMS personnel's other job responsibilities at the agency beyond their primary role documented in dPersonnel.34 (EMS Personnel's Primary EMS Job Role).</definition>
                  <usage>Recommended</usage>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:simpleContent>
                <xs:extension base="JobResponsibilities">
                  <xs:attribute name="NV" use="optional">
                    <xs:simpleType>
                      <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
                    </xs:simpleType>
                  </xs:attribute>
                  <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
                </xs:extension>
              </xs:simpleContent>
            </xs:complexType>
          </xs:element>
          <xs:element name="dPersonnel.36" type="TotalService" id="dPersonnel.EMSPersonnelsTotalLengthofServiceinYears" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.36</number>
                  <name>EMS Personnel's Total Length of Service in Years</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The personnel's total length of EMS service at any level (years).</definition>
                  <v2Number>D08_19</v2Number>
                  <usage>Optional</usage>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
          </xs:element>
          <xs:element name="dPersonnel.37" type="DateType" id="dPersonnel.EMSPersonnelsDateLengthofServiceDocumented" minOccurs="0">
            <xs:annotation>
              <xs:documentation>
                <nemsisTacDoc>
                  <number>dPersonnel.37</number>
                  <name>EMS Personnel's Date Length of Service Documented</name>
                  <national>No</national>
                  <state>No</state>
                  <definition>The date which the length of EMS service was documented.</definition>
                  <v2Number>D08_20</v2Number>
                  <usage>Optional</usage>
                  <comment>Associated with dPersonnel.37 (EMS Personnel's Total Length of Service in Years).</comment>
                </nemsisTacDoc>
              </xs:documentation>
            </xs:annotation>
          </xs:element>
          <xs:element name="dPersonnel.CertificationLevelGroup" id="dPersonnel.CertificationLevelGroup" minOccurs="0" maxOccurs="unbounded">
            <xs:annotation>
              <xs:documentation>Group to hold the certification information</xs:documentation>
            </xs:annotation>
            <xs:complexType>
              <xs:sequence>
                <xs:element name="dPersonnel.38" type="MemberLevel" id="dPersonnel.EMSPersonnelsPracticeLevel" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.38</number>
                        <name>EMS Personnel's Practice Level</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The EMS certification level at which the individual is providing patient care services for the EMS agency.</definition>
                        <v2Number>D07_05</v2Number>
                        <usage>Optional</usage>
                        <comment>The category EMT-Intermediate includes EMS professionals with an "85" or "99" certification level.</comment>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
                <xs:element name="dPersonnel.39" type="DateType" id="dPersonnel.DateofPersonnelsCertificationorLicensureforAgency" minOccurs="0">
                  <xs:annotation>
                    <xs:documentation>
                      <nemsisTacDoc>
                        <number>dPersonnel.39</number>
                        <name>Date of Personnel's Certification or Licensure for Agency</name>
                        <national>No</national>
                        <state>No</state>
                        <definition>The date that the Certification/Licensure was achieved for the local EMS agency.</definition>
                        <v2Number>D07_06</v2Number>
                        <usage>Optional</usage>
                      </nemsisTacDoc>
                    </xs:documentation>
                  </xs:annotation>
                </xs:element>
              </xs:sequence>
              <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
              <xs:attribute name="UUID" type="UUID" use="required"/>
            </xs:complexType>
          </xs:element>
        </xs:sequence>
        <xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>
        <xs:attribute name="UUID" type="UUID" use="required"/>
      </xs:complexType>
    </xs:element>
  </xs:sequence>
</xs:complexType>

Simple Type DemographicRace

Namespace

http://www.nemsis.org

Annotations

The patient's race as defined by the OMB (US Office of Management and Budget)

Diagram

Type

restriction of xs:string

Facets

enumeration

1513001

American Indian or Alaska Native

enumeration

1513003

Asian

enumeration

1513005

Black or African American

enumeration

1513007

Hispanic or Latino

enumeration

1513009

Native Hawaiian or Other Pacific Islander

enumeration

1513011

White

enumeration

1513013

Middle Eastern or North African

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.13

Source

<xs:simpleType name="DemographicRace">
  <xs:annotation>
    <xs:documentation>The patient's race as defined by the OMB (US Office of Management and Budget)</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="1513001">
      <xs:annotation>
        <xs:documentation>American Indian or Alaska Native</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1513003">
      <xs:annotation>
        <xs:documentation>Asian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1513005">
      <xs:annotation>
        <xs:documentation>Black or African American</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1513007">
      <xs:annotation>
        <xs:documentation>Hispanic or Latino</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1513009">
      <xs:annotation>
        <xs:documentation>Native Hawaiian or Other Pacific Islander</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1513011">
      <xs:annotation>
        <xs:documentation>White</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1513013">
      <xs:annotation>
        <xs:documentation>Middle Eastern or North African</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>

Simple Type PersonnelHighestEducationalDegree

Namespace

http://www.nemsis.org

Annotations

The EMS Personnel's ethnicity as defined by the OMB (US Office of Management and Budget).

Diagram

Type

restriction of xs:string

Facets

enumeration

1515001

No Schooling Completed

enumeration

1515003

Nursery School to 4th Grade

enumeration

1515005

5th Grade or 6th Grade

enumeration

1515007

7th Grade or 8th Grade

enumeration

1515009

9th Grade

enumeration

1515011

10th Grade

enumeration

1515013

11th Grade

enumeration

1515015

12th Grade, No Diploma

enumeration

1515017

High School Graduate-Diploma or the Equivalent (GED)

enumeration

1515019

Some College Credit, but Less than 1 Year

enumeration

1515021

1 or More Years of College, No Degree

enumeration

1515023

Associate Degree

enumeration

1515025

Bachelor's Degree

enumeration

1515027

Master's Degree

enumeration

1515029

Professional Degree (i.e. MD, DDS, DVM, LLB, JD)

enumeration

1515031

Doctorate Degree (i.e. PhD, EdD)

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.15

Source

<xs:simpleType name="PersonnelHighestEducationalDegree">
  <xs:annotation>
    <xs:documentation>The EMS Personnel's ethnicity as defined by the OMB (US Office of Management and Budget).</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="1515001">
      <xs:annotation>
        <xs:documentation>No Schooling Completed</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515003">
      <xs:annotation>
        <xs:documentation>Nursery School to 4th Grade</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515005">
      <xs:annotation>
        <xs:documentation>5th Grade or 6th Grade</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515007">
      <xs:annotation>
        <xs:documentation>7th Grade or 8th Grade</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515009">
      <xs:annotation>
        <xs:documentation>9th Grade</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515011">
      <xs:annotation>
        <xs:documentation>10th Grade</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515013">
      <xs:annotation>
        <xs:documentation>11th Grade</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515015">
      <xs:annotation>
        <xs:documentation>12th Grade, No Diploma</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515017">
      <xs:annotation>
        <xs:documentation>High School Graduate-Diploma or the Equivalent (GED)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515019">
      <xs:annotation>
        <xs:documentation>Some College Credit, but Less than 1 Year</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515021">
      <xs:annotation>
        <xs:documentation>1 or More Years of College, No Degree</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515023">
      <xs:annotation>
        <xs:documentation>Associate Degree</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515025">
      <xs:annotation>
        <xs:documentation>Bachelor's Degree</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515027">
      <xs:annotation>
        <xs:documentation>Master's Degree</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515029">
      <xs:annotation>
        <xs:documentation>Professional Degree (i.e. MD, DDS, DVM, LLB, JD)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1515031">
      <xs:annotation>
        <xs:documentation>Doctorate Degree (i.e. PhD, EdD)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>

Simple Type PersonnelDegreeFieldofStudy

Namespace

http://www.nemsis.org

Annotations

The EMS Personnel's ethnicity as defined by the OMB (US Office of Management and Budget).

Diagram

Type

restriction of xs:string

Facets

enumeration

1516001

Agriculture and Natural Resources

enumeration

1516003

Architecture and Related Services

enumeration

1516005

Area, Ethnic, Cultural, and Gender Studies

enumeration

1516007

Biological and Biomedical Sciences

enumeration

1516009

Business

enumeration

1516011

Communication, Journalism, and Related Programs

enumeration

1516013

Communications Technologies

enumeration

1516015

Computer and Information Sciences

enumeration

1516017

Education

enumeration

1516019

Emergency Medical Services

enumeration

1516021

Engineering

enumeration

1516023

Engineering Technologies

enumeration

1516025

English Language and Literature/Letters

enumeration

1516027

Family and Consumer Sciences/Human Sciences

enumeration

1516029

Fire Science

enumeration

1516031

Foreign Languages, Literatures, and Linguistics

enumeration

1516033

Health Professions and Related Clinical Sciences, Not Including Emergency Medical Services

enumeration

1516035

Legal Professions and Studies

enumeration

1516037

Liberal Arts and Sciences, General Studies, and Humanities

enumeration

1516039

Library Science

enumeration

1516041

Mathematics and Statistics

enumeration

1516043

Military Technologies

enumeration

1516045

Multi/Interdisciplinary Studies

enumeration

1516047

Not Classified by Field of Study

enumeration

1516049

None

enumeration

1516051

Parks, Recreation, Leisure and Fitness Studies

enumeration

1516053

Philosophy and Religious Studies

enumeration

1516055

Physical Sciences and Science Technologies

enumeration

1516057

Precision Production

enumeration

1516059

Psychology

enumeration

1516061

Public Administration and Social Services

enumeration

1516063

Security and Protective Services, Not Including Fire Science

enumeration

1516065

Social Sciences and History

enumeration

1516067

Theology and Religious Vocations

enumeration

1516069

Transportation and Materials Moving

enumeration

1516071

Visual and Performing Arts

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.16

Source

<xs:simpleType name="PersonnelDegreeFieldofStudy">
  <xs:annotation>
    <xs:documentation>The EMS Personnel's ethnicity as defined by the OMB (US Office of Management and Budget).</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="1516001">
      <xs:annotation>
        <xs:documentation>Agriculture and Natural Resources</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516003">
      <xs:annotation>
        <xs:documentation>Architecture and Related Services</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516005">
      <xs:annotation>
        <xs:documentation>Area, Ethnic, Cultural, and Gender Studies</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516007">
      <xs:annotation>
        <xs:documentation>Biological and Biomedical Sciences</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516009">
      <xs:annotation>
        <xs:documentation>Business</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516011">
      <xs:annotation>
        <xs:documentation>Communication, Journalism, and Related Programs</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516013">
      <xs:annotation>
        <xs:documentation>Communications Technologies</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516015">
      <xs:annotation>
        <xs:documentation>Computer and Information Sciences</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516017">
      <xs:annotation>
        <xs:documentation>Education</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516019">
      <xs:annotation>
        <xs:documentation>Emergency Medical Services</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516021">
      <xs:annotation>
        <xs:documentation>Engineering</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516023">
      <xs:annotation>
        <xs:documentation>Engineering Technologies</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516025">
      <xs:annotation>
        <xs:documentation>English Language and Literature/Letters</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516027">
      <xs:annotation>
        <xs:documentation>Family and Consumer Sciences/Human Sciences</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516029">
      <xs:annotation>
        <xs:documentation>Fire Science</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516031">
      <xs:annotation>
        <xs:documentation>Foreign Languages, Literatures, and Linguistics</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516033">
      <xs:annotation>
        <xs:documentation>Health Professions and Related Clinical Sciences, Not Including Emergency Medical Services</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516035">
      <xs:annotation>
        <xs:documentation>Legal Professions and Studies</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516037">
      <xs:annotation>
        <xs:documentation>Liberal Arts and Sciences, General Studies, and Humanities</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516039">
      <xs:annotation>
        <xs:documentation>Library Science</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516041">
      <xs:annotation>
        <xs:documentation>Mathematics and Statistics</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516043">
      <xs:annotation>
        <xs:documentation>Military Technologies</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516045">
      <xs:annotation>
        <xs:documentation>Multi/Interdisciplinary Studies</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516047">
      <xs:annotation>
        <xs:documentation>Not Classified by Field of Study</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516049">
      <xs:annotation>
        <xs:documentation>None</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516051">
      <xs:annotation>
        <xs:documentation>Parks, Recreation, Leisure and Fitness Studies</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516053">
      <xs:annotation>
        <xs:documentation>Philosophy and Religious Studies</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516055">
      <xs:annotation>
        <xs:documentation>Physical Sciences and Science Technologies</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516057">
      <xs:annotation>
        <xs:documentation>Precision Production</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516059">
      <xs:annotation>
        <xs:documentation>Psychology</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516061">
      <xs:annotation>
        <xs:documentation>Public Administration and Social Services</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516063">
      <xs:annotation>
        <xs:documentation>Security and Protective Services, Not Including Fire Science</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516065">
      <xs:annotation>
        <xs:documentation>Social Sciences and History</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516067">
      <xs:annotation>
        <xs:documentation>Theology and Religious Vocations</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516069">
      <xs:annotation>
        <xs:documentation>Transportation and Materials Moving</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1516071">
      <xs:annotation>
        <xs:documentation>Visual and Performing Arts</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>

Simple Type PersonnelVehicleLicenseType

Namespace

http://www.nemsis.org

Annotations

The EMS Personnel's ethnicity as defined by the OMB (US Office of Management and Budget).

Diagram

Type

restriction of xs:string

Facets

enumeration

1517001

All-Terrain Vehicle (ATV)

enumeration

1517003

Commercial Class A

enumeration

1517005

Commercial Class B

enumeration

1517007

Commercial Class C

enumeration

1517009

Motorcycle-Class M

enumeration

1517011

None

enumeration

1517013

Operator Class D (Normal)

enumeration

1517015

Other

enumeration

1517017

Pilot-Rotor Wing Air

enumeration

1517019

Pilot-Fixed Wing Air

enumeration

1517021

Snowmobile

enumeration

1517023

Taxi and Livery Class E

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.17

Source

<xs:simpleType name="PersonnelVehicleLicenseType">
  <xs:annotation>
    <xs:documentation>The EMS Personnel's ethnicity as defined by the OMB (US Office of Management and Budget).</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="1517001">
      <xs:annotation>
        <xs:documentation>All-Terrain Vehicle (ATV)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517003">
      <xs:annotation>
        <xs:documentation>Commercial Class A</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517005">
      <xs:annotation>
        <xs:documentation>Commercial Class B</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517007">
      <xs:annotation>
        <xs:documentation>Commercial Class C</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517009">
      <xs:annotation>
        <xs:documentation>Motorcycle-Class M</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517011">
      <xs:annotation>
        <xs:documentation>None</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517013">
      <xs:annotation>
        <xs:documentation>Operator Class D (Normal)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517015">
      <xs:annotation>
        <xs:documentation>Other</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517017">
      <xs:annotation>
        <xs:documentation>Pilot-Rotor Wing Air</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517019">
      <xs:annotation>
        <xs:documentation>Pilot-Fixed Wing Air</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517021">
      <xs:annotation>
        <xs:documentation>Snowmobile</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1517023">
      <xs:annotation>
        <xs:documentation>Taxi and Livery Class E</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>

Simple Type PersonnelForeignLanguageAbility

Namespace

http://www.nemsis.org

Annotations

The EMS Personnel's ethnicity as defined by the OMB (US Office of Management and Budget)

Diagram

Type

restriction of xs:string

Facets

enumeration

amh

Amharic

enumeration

ara

Arabic

enumeration

arm

Armenian

enumeration

ben

Bengali

enumeration

crp

Cajun (Creole and Pidgins)

enumeration

chi

Chinese

enumeration

hrv

Croatian

enumeration

cze

Czech

enumeration

dan

Danish

enumeration

dut

Dutch

enumeration

fin

Finnish

enumeration

tai

Formosan

enumeration

fre

French

enumeration

cpf

French Creole

enumeration

ger

German

enumeration

gre

Greek

enumeration

guj

Gujarati

enumeration

heb

Hebrew

enumeration

hin

Hindi (Urdu)

enumeration

hun

Hungarian

enumeration

ilo

Ilocano

enumeration

itl

Italian

enumeration

jpn

Japanese

enumeration

kor

Korean

enumeration

kro

Kru

enumeration

lit

Lithuanian

enumeration

mal

Malayalam

enumeration

hmn

Miao (Hmong)

enumeration

mkh

Mon-Khmer (Cambodian)

enumeration

nav

Navaho

enumeration

nno

Norwegian

enumeration

pan

Panjabi

enumeration

gem

Pennsylvania Dutch (Germanic Other)

enumeration

per

Persian

enumeration

pol

Polish

enumeration

por

Portuguese

enumeration

rum

Romanian

enumeration

rus

Russian

enumeration

sgn

Sign Languages

enumeration

smo

Samoan

enumeration

srp

Serbo-Croatian

enumeration

slo

Slovak

enumeration

spa

Spanish

enumeration

swe

Swedish

enumeration

syr

Syriac

enumeration

tgl

Tagalog

enumeration

tha

Thai (Laotian)

enumeration

tur

Turkish

enumeration

ukr

Ukrainian

enumeration

vie

Vietnamese

enumeration

yid

Yiddish

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.20

Source

<xs:simpleType name="PersonnelForeignLanguageAbility">
  <xs:annotation>
    <xs:documentation>The EMS Personnel's ethnicity as defined by the OMB (US Office of Management and Budget)</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="amh">
      <xs:annotation>
        <xs:documentation>Amharic</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="ara">
      <xs:annotation>
        <xs:documentation>Arabic</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="arm">
      <xs:annotation>
        <xs:documentation>Armenian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="ben">
      <xs:annotation>
        <xs:documentation>Bengali</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="crp">
      <xs:annotation>
        <xs:documentation>Cajun (Creole and Pidgins)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="chi">
      <xs:annotation>
        <xs:documentation>Chinese</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="hrv">
      <xs:annotation>
        <xs:documentation>Croatian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="cze">
      <xs:annotation>
        <xs:documentation>Czech</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="dan">
      <xs:annotation>
        <xs:documentation>Danish</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="dut">
      <xs:annotation>
        <xs:documentation>Dutch</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="fin">
      <xs:annotation>
        <xs:documentation>Finnish</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="tai">
      <xs:annotation>
        <xs:documentation>Formosan</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="fre">
      <xs:annotation>
        <xs:documentation>French</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="cpf">
      <xs:annotation>
        <xs:documentation>French Creole</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="ger">
      <xs:annotation>
        <xs:documentation>German</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="gre">
      <xs:annotation>
        <xs:documentation>Greek</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="guj">
      <xs:annotation>
        <xs:documentation>Gujarati</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="heb">
      <xs:annotation>
        <xs:documentation>Hebrew</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="hin">
      <xs:annotation>
        <xs:documentation>Hindi (Urdu)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="hun">
      <xs:annotation>
        <xs:documentation>Hungarian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="ilo">
      <xs:annotation>
        <xs:documentation>Ilocano</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="itl">
      <xs:annotation>
        <xs:documentation>Italian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="jpn">
      <xs:annotation>
        <xs:documentation>Japanese</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="kor">
      <xs:annotation>
        <xs:documentation>Korean</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="kro">
      <xs:annotation>
        <xs:documentation>Kru</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="lit">
      <xs:annotation>
        <xs:documentation>Lithuanian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="mal">
      <xs:annotation>
        <xs:documentation>Malayalam</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="hmn">
      <xs:annotation>
        <xs:documentation>Miao (Hmong)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="mkh">
      <xs:annotation>
        <xs:documentation>Mon-Khmer (Cambodian)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="nav">
      <xs:annotation>
        <xs:documentation>Navaho</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="nno">
      <xs:annotation>
        <xs:documentation>Norwegian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="pan">
      <xs:annotation>
        <xs:documentation>Panjabi</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="gem">
      <xs:annotation>
        <xs:documentation>Pennsylvania Dutch (Germanic Other)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="per">
      <xs:annotation>
        <xs:documentation>Persian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="pol">
      <xs:annotation>
        <xs:documentation>Polish</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="por">
      <xs:annotation>
        <xs:documentation>Portuguese</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="rum">
      <xs:annotation>
        <xs:documentation>Romanian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="rus">
      <xs:annotation>
        <xs:documentation>Russian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="sgn">
      <xs:annotation>
        <xs:documentation>Sign Languages</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="smo">
      <xs:annotation>
        <xs:documentation>Samoan</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="srp">
      <xs:annotation>
        <xs:documentation>Serbo-Croatian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="slo">
      <xs:annotation>
        <xs:documentation>Slovak</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="spa">
      <xs:annotation>
        <xs:documentation>Spanish</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="swe">
      <xs:annotation>
        <xs:documentation>Swedish</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="syr">
      <xs:annotation>
        <xs:documentation>Syriac</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="tgl">
      <xs:annotation>
        <xs:documentation>Tagalog</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="tha">
      <xs:annotation>
        <xs:documentation>Thai (Laotian)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="tur">
      <xs:annotation>
        <xs:documentation>Turkish</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="ukr">
      <xs:annotation>
        <xs:documentation>Ukrainian</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="vie">
      <xs:annotation>
        <xs:documentation>Vietnamese</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="yid">
      <xs:annotation>
        <xs:documentation>Yiddish</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>

Simple Type PersonnelAgencyIDNumber

Namespace

http://www.nemsis.org

Annotations

Local agency name number for personnel.

Diagram

Type

restriction of xs:string

Facets

minLength	2
maxLength	50

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.21

Source

<xs:simpleType name="PersonnelAgencyIDNumber">
  <xs:annotation>
    <xs:documentation>Local agency name number for personnel.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:minLength value="2"/>
    <xs:maxLength value="50"/>
  </xs:restriction>
</xs:simpleType>

Simple Type StateLicensureID

Namespace

http://www.nemsis.org

Annotations

The state certification/licensure name number assigned to the crew member.

Diagram

Type

restriction of xs:string

Facets

minLength	2
maxLength	50

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.LicensureGroup/dPersonnel.23

Source

<xs:simpleType name="StateLicensureID">
  <xs:annotation>
    <xs:documentation>The state certification/licensure name number assigned to the crew member.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:minLength value="2"/>
    <xs:maxLength value="50"/>
  </xs:restriction>
</xs:simpleType>

Simple Type NationalRegistryNumber

Namespace

http://www.nemsis.org

Annotations

Level of the current National Registry of Emergency Medical Technicians (NREMT) certification.

Diagram

Type

restriction of xs:string

Facets

pattern

[A-Z][A-Z0-9][0-9]{6}

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.28

Source

<xs:simpleType name="NationalRegistryNumber">
  <xs:annotation>
    <xs:documentation>Level of the current National Registry of Emergency Medical Technicians (NREMT) certification.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:pattern value="[A-Z][A-Z0-9][0-9]{6}"/>
  </xs:restriction>
</xs:simpleType>

Simple Type NationalRegistryCertificationLevel

Namespace

http://www.nemsis.org

Annotations

The national registration number associated with the level of certification/licensure obtained through NREMT

Diagram

Type

restriction of xs:string

Facets

enumeration

1529001

Advanced Emergency Medical Technician (AEMT)

enumeration

1529002

Emergency Medical Technician - Intermediate

enumeration

1529003

Emergency Medical Responder (EMR)

enumeration

1529005

Emergency Medical Technician (EMT)

enumeration

1529007

Paramedic

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.29

Source

<xs:simpleType name="NationalRegistryCertificationLevel">
  <xs:annotation>
    <xs:documentation>The national registration number associated with the level of certification/licensure obtained through NREMT</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="1529001">
      <xs:annotation>
        <xs:documentation>Advanced Emergency Medical Technician (AEMT)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1529002">
      <xs:annotation>
        <xs:documentation>Emergency Medical Technician - Intermediate</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1529003">
      <xs:annotation>
        <xs:documentation>Emergency Medical Responder (EMR)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1529005">
      <xs:annotation>
        <xs:documentation>Emergency Medical Technician (EMT)</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1529007">
      <xs:annotation>
        <xs:documentation>Paramedic</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>

Simple Type EmploymentStatus

Namespace

http://www.nemsis.org

Annotations

Personnel's Employment Status for this Agency.

Diagram

Type

restriction of xs:string

Facets

enumeration

1531001

Full Time Paid Employee

enumeration

1531003

Part Time Paid Employee

enumeration

1531005

Volunteer

enumeration

1531007

Neither an Employee Nor a Volunteer

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.31

Source

<xs:simpleType name="EmploymentStatus">
  <xs:annotation>
    <xs:documentation>Personnel's Employment Status for this Agency.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="1531001">
      <xs:annotation>
        <xs:documentation>Full Time Paid Employee</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1531003">
      <xs:annotation>
        <xs:documentation>Part Time Paid Employee</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1531005">
      <xs:annotation>
        <xs:documentation>Volunteer</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1531007">
      <xs:annotation>
        <xs:documentation>Neither an Employee Nor a Volunteer</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>

Simple Type JobResponsibilities

Namespace

http://www.nemsis.org

Annotations

The individuals primary/main EMS role at the EMS Agency. This is the function which is performed the majority of the time for the EMS professional.

Diagram

Type

restriction of xs:string

Facets

enumeration

1534001

Administrator/Manager

enumeration

1534003

Driver/Pilot

enumeration

1534005

Educator/Preceptor

enumeration

1534007

Fire Suppression

enumeration

1534009

First-Line Supervisor

enumeration

1534011

Law Enforcement

enumeration

1534013

Other

enumeration

1534015

Patient Care Provider

enumeration

1534017

Rescue

Used by

Elements

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.34, dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.35

Source

<xs:simpleType name="JobResponsibilities">
  <xs:annotation>
    <xs:documentation>The individuals primary/main EMS role at the EMS Agency. This is the function which is performed the majority of the time for the EMS professional.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:string">
    <xs:enumeration value="1534001">
      <xs:annotation>
        <xs:documentation>Administrator/Manager</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1534003">
      <xs:annotation>
        <xs:documentation>Driver/Pilot</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1534005">
      <xs:annotation>
        <xs:documentation>Educator/Preceptor</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1534007">
      <xs:annotation>
        <xs:documentation>Fire Suppression</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1534009">
      <xs:annotation>
        <xs:documentation>First-Line Supervisor</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1534011">
      <xs:annotation>
        <xs:documentation>Law Enforcement</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1534013">
      <xs:annotation>
        <xs:documentation>Other</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1534015">
      <xs:annotation>
        <xs:documentation>Patient Care Provider</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
    <xs:enumeration value="1534017">
      <xs:annotation>
        <xs:documentation>Rescue</xs:documentation>
      </xs:annotation>
    </xs:enumeration>
  </xs:restriction>
</xs:simpleType>

Simple Type TotalService

Namespace

http://www.nemsis.org

Annotations

The personnel's total length of EMS service at any level.

Diagram

Type

restriction of xs:integer

Facets

maxInclusive	80
minInclusive	0

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.36

Source

<xs:simpleType name="TotalService">
  <xs:annotation>
    <xs:documentation>The personnel's total length of EMS service at any level.</xs:documentation>
  </xs:annotation>
  <xs:restriction base="xs:integer">
    <xs:minInclusive value="0"/>
    <xs:maxInclusive value="80"/>
  </xs:restriction>
</xs:simpleType>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.NameGroup / dPersonnel.01 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.NameGroup/dPersonnel.01

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.NameGroup / dPersonnel.02 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.NameGroup/dPersonnel.02

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.NameGroup / dPersonnel.03 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.NameGroup/dPersonnel.03

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.AddressGroup / dPersonnel.04 / @StreetAddress2

Namespace

No namespace

Type

StreetAddress

Properties

use	optional

Facets

minLength	1
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.AddressGroup/dPersonnel.04

Source

<xs:attribute name="StreetAddress2" type="StreetAddress" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.09 / @PhoneNumberType

Namespace

No namespace

Type

PhoneNumberType

Properties

use	optional

Facets

enumeration

9913001

Fax

enumeration

9913003

Home

enumeration

9913005

Mobile

enumeration

9913007

Pager

enumeration

9913009

Work

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.09

Source

<xs:attribute name="PhoneNumberType" type="PhoneNumberType" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.09 / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.09

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.10 / @EmailAddressType

Namespace

No namespace

Type

EmailAddressType

Properties

use	optional

Facets

enumeration

9904001

Personal

enumeration

9904003

Work

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.10

Source

<xs:attribute name="EmailAddressType" type="EmailAddressType" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.10 / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.10

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.11 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.11

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.12 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.12

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.13 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.13

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.13 / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.13

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.16 / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.16

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.17 / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.17

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.ImmunizationsGroup / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.ImmunizationsGroup

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.ImmunizationsGroup / @UUID

Namespace

No namespace

Type

UUID

Properties

use	required

Facets

pattern

[a-fA-F0-9]{8}-[a-fA-F0-9]{4}-[1-5][a-fA-F0-9]{3}-[89abAB][a-fA-F0-9]{3}-[a-fA-F0-9]{12}

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.ImmunizationsGroup

Source

<xs:attribute name="UUID" type="UUID" use="required"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.20 / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.20

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / dPersonnel.22 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.LicensureGroup/dPersonnel.22

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / dPersonnel.23 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.LicensureGroup/dPersonnel.23

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / dPersonnel.24 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.LicensureGroup/dPersonnel.24

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.LicensureGroup

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.LicensureGroup / @UUID

Namespace

No namespace

Type

UUID

Properties

use	required

Facets

pattern

[a-fA-F0-9]{8}-[a-fA-F0-9]{4}-[1-5][a-fA-F0-9]{3}-[89abAB][a-fA-F0-9]{3}-[a-fA-F0-9]{12}

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.LicensureGroup

Source

<xs:attribute name="UUID" type="UUID" use="required"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.31 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.31

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.32 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.32

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.34 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.34

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.35 / @NV

Namespace

No namespace

Type

union of(NV.NotApplicable, NV.NotRecorded, NV.NotReporting)

Properties

use	optional

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.35

Source

<xs:attribute name="NV" use="optional">
  <xs:simpleType>
    <xs:union memberTypes="NV.NotApplicable NV.NotRecorded NV.NotReporting"/>
  </xs:simpleType>
</xs:attribute>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.35 / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.35

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.CertificationLevelGroup / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.CertificationLevelGroup

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / dPersonnel.CertificationLevelGroup / @UUID

Namespace

No namespace

Type

UUID

Properties

use	required

Facets

pattern

[a-fA-F0-9]{8}-[a-fA-F0-9]{4}-[1-5][a-fA-F0-9]{3}-[89abAB][a-fA-F0-9]{3}-[a-fA-F0-9]{12}

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup/dPersonnel.CertificationLevelGroup

Source

<xs:attribute name="UUID" type="UUID" use="required"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / @CorrelationID

Namespace

No namespace

Type

CorrelationID

Properties

use	optional

Facets

minLength	2
maxLength	255

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup

Source

<xs:attribute name="CorrelationID" type="CorrelationID" use="optional"/>

Attribute dPersonnel / dPersonnel.PersonnelGroup / @UUID

Namespace

No namespace

Type

UUID

Properties

use	required

Facets

pattern

[a-fA-F0-9]{8}-[a-fA-F0-9]{4}-[1-5][a-fA-F0-9]{3}-[89abAB][a-fA-F0-9]{3}-[a-fA-F0-9]{12}

Used by

Element

dPersonnel/dPersonnel.PersonnelGroup

Source

<xs:attribute name="UUID" type="UUID" use="required"/>
